Troubleshooting

4.23 Refrigerant Shortage

U0
Remote
Controller
Display
Method of Refrigerant shortage detection I:
Malfunction Refrigerant shortage is detected by checking the input current value and the compressor output
frequency. If the refrigerant is short, the input current is smaller than the normal value.
Detection
Refrigerant shortage detection II:
Refrigerant shortage is detected by checking the discharge pipe temperature and the opening of
the electronic expansion valve. If the refrigerant is short, the discharge pipe temperature tends
to rise.
Malfunction Refrigerant shortage detection I:
Decision The following conditions continue for 7 minutes.
Conditions
Refrigerant shortage detection II:
The following conditions continue for 80 seconds.
Supposed
Causes
90
DC current ≤
× Output frequency +
Output frequency >
(–) (A)
18/1000 0.7
Target opening of the electronic expansion valve ≥
Discharge pipe temperature >
(pulse)
50 class 480
60 class 480
If the error repeats 4 times, the system is shut down.
Reset condition: Continuous run for about 60 minutes without any other error
Disconnection of the discharge pipe thermistor, indoor or outdoor heat exchanger thermistor,
room or outdoor temperature thermistor
Closed stop valve
Refrigerant shortage (refrigerant leakage)
Poor compression performance of compressor
Defective electronic expansion valve
(Hz)
55
× target discharge pipe temperature +
(°C)
(–)
128/128 Cooling: 20, Heating: 45
128/128 Cooling: 60, Heating: 45
SiBE07-618_C
Service Diagnosis
