Final Driving Mechanism - Sym GTS 250 Service Manual

Mechanism Diagram ···························· 9-1
Precautions in Operation ······················ 9-2
Trouble Diagnosis ······························· 9-2
Disassembly of Final Driving Mechanism 9-3
Mechanism Diagram
Counter gear
Drive shaft
Home page
Inspection of Final Driving Mechanism ······ 9-4
Bearing Replacement ······························ 9-5
Re-Assembly of Final Driving Mechanism ·· 9-8
Final shaft
Counter shaft
Contents

9. Final Driving Mechanism

Final gear
9
9-1
