Yes, you can.
®
Invacare® G50
Power Wheelchair
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Invacare G50

Summary of Contents for Invacare G50

  • Page 1 Yes, you can. ® Invacare® G50 Power Wheelchair User Manual...
  • Page 3 How can you get in touch with Invacare®? If you have any questions or need support, please contact your authorised Invacare® Dealer, who has the necessary know-how and equipment plus the special knowledge concerning your Invacare® product, and can offer you all-round satisfactory service. Should you wish to contact Invacare® directly, you can reach us in Europe at the following addresses and phone numbers.
  • Page 4 +44 (0)1656 77 62 20 Pencoed uk@invacare.com Bridgend CF35 5AQ WWW: www.invacare.co.uk United Kingdom Invacare Mecc San s.r.l. +39 0445 38 00 59 Via dei Pini, 62 Fax: +39 0445 38 00 34 I - 36016 Thiene (VI) italia@invacare.com ITALIA WWW: www.invacare.it...
  • Page 5 +46 (0)8 761 81 08 Fagerstagatan 9 sweden@invacare.com S-163 91 Spånga finland@invacare.com Sverige WWW: www.invacare.se Tillverkare: MÖLNDAL Invacare® Deutschland GmbH  : +46 (0)31 86 36 00 Kleiststraße 49 Fax: +46 (0)31 86 36 06 D-32457 Porta Westfalica ginvacare@invacare.com Deutschland LANDSKRONA ...

  • Page 6: Table Of Contents

    Table of Contents Chapter Page Introduction Important symbols in this manual ..................12 Important symbols found on the vehicle ................14 Type classification and permissible use................16 Indications..........................16 Usability............................17 Warranty ...........................18 Life expectancy........................18 Safety notes General safety notes .......................19 Safety information with regard to care and maintenance ...........22 Safety information on electromagnetic interference ............23 Safety information on driving and freewheel mode.............24 Safety information regarding changes and modifications to the mobility device....26...
  • Page 7 5.2.1 Maximum obstacle height .....................34 5.2.2 Safety information when ascending obstacles .............34 5.2.3 The correct way to overcome obstacles ...............35 Driving up and down gradients....................36 Parking and stationary......................37 5.4.1 Parking brake........................37 Use on public roads ........................38 Pushing the wheelchair in freewheel mode Disengaging Motors ........................38 Disengaging the steering wheels ..................40 Remotes...
  • Page 8 8.5.1 Types of postural belts....................58 8.5.2 Adjusting the postural belt correctly................59 Adjusting and removing the tray ...................60 8.6.1 Laterally adjusting the tray....................60 8.6.2 Adjusting the depth of the tray / removing the tray............61 8.6.3 Swinging the tray away to the side ................61 Using the KLICKfix adapter ....................62 Adjusting the footrests and the legrests Firmly mounted legrests......................64...
  • Page 9 9.2.2.5 Adjusting the depth of the calf plate ................87 9.2.2.6 Adjusting the height of the calf pad .................88 9.2.2.7 Unlocking and swivelling the calf plate backward when alighting ......89 9.2.2.8 Adjusting the angle adjustable foot plate..............90 9.2.2.9 Adjusting the angle and depth adjustable foot plate ..........91 9.2.3 Manually height adjustable legrest 80°...
  • Page 10 10.2.1.4 How to disconnect the batteries after charging .............112 10.2.2 Storage and Maintenance...................113 10.2.3 Instructions on using the batteries................113 10.2.4 Transporting batteries....................115 10.2.5 Handling batteries.......................115 10.2.5.1 General instructions on handling the batteries ............115 10.2.5.2 How to handle damaged batteries correctly ............115 10.2.5.3 Tilting the seating system forward .................117 10.2.5.4...

  • Page 11: Introduction

    The decision whether the model is suitable for the user may only be taken by medical specialists with appropriate expertise. Invacare® or their statutory representatives can accept no liability in cases in which the wheelchair has not been adapted to suit the users’ handicaps.

  • Page 12: Important Symbols In This Manual

    This manual contains copyrighted information. This manual may not be reproduced or reprinted either partly or completely without previous written consent from Invacare® or its statutory representatives. We reserve the right to make any necessary alterations on the grounds of technical improvements.
  • Page 13 RISK OF CRUSHING! This symbol warns of a risk of crushing caused by being careless with heavy components. • Always follow the instructions to avoid injury to the user or damage to the product. Wear eye protection This symbol refers to the requirement for wearing eye protection, for example when working with batteries.

  • Page 14: Important Symbols Found On The Vehicle

    Important symbols found on the vehicle DO NOT APPLY HEAVY WEIGHT TO THIS AREA! Danger of damage to the vehicle! • Never apply pressure or heavy weight to areas marked with this symbol! This product has been supplied from an environmentally aware manufacturer. This product may contain substances that could be harmful to the environment if disposed of in places (landfills) that are not appropriate according to legislation.
  • Page 15 This symbol indicates the position of an anchor point when using a lashing system during transport. If the symbol appears on a bright yellow sticker, the anchoring point is suitable for fixation of the wheelchair in a vehicle for use as a vehicle seat. This wheelchair may not be used as a vehicle seat! •...

  • Page 16: Type Classification And Permissible Use

    Type classification and permissible use This vehicle was designed for persons whose ability to walk is impaired, but who are still physically and mentally able to operate an electric vehicle. It has been classified according to EN 12184 as a class B and C mobility product (for indoor/outdoor and outdoor usage, depending on the configuration).

  • Page 17: Usability

    • You should immediately stop using your power wheelchair if its usability is restricted due to: - brake failure • You should immediately contact an authorised Invacare® dealer if the usability of your power wheelchair is restricted due to: - the lighting system failing or being defective...

  • Page 18: Warranty

    - the wheelchair drifting when braking - the wheelchair pulling to one side when moving - unusual sounds developing or occurring Or if you have the feeling that something is wrong with your wheelchair. Warranty The terms and conditions of the warranty are part of the general terms and conditions particular to the individual countries in which this product is sold.

  • Page 19: Safety Notes

    Safety notes READ WELL BEFORE OPERATION! General safety notes Danger of injury if mobility device is used in any other way than the purpose described in this manual! • Only ever use the mobility device in accordance with the instructions in this User's Manual (see chapter "Type classification and permissible use"...
  • Page 20 Danger of injury if the mobility device is switched off while driving, for example by pressing the On/Off Button or disconnecting a cable, due to it coming to an abrupt, sharp stop! • If you have to brake in an emergency, simply release the joystick which will bring you to a halt. (refer to the joystick operating manual for more information).
  • Page 21 Danger of fire or breaking down due to electric devices being connected! • Do not connect any electric devices to your mobility device that are not expressly certified by Invacare® for this purpose. Have all electrical installations done by your authorised Invacare® Dealer.

  • Page 22: Safety Information With Regard To Care And Maintenance

    Safety information with regard to care and maintenance Danger of accident and loss of guarantee if maintenance is insufficient! • For reasons of safety and in order to avoid accidents which result from unnoticed wear, it is important that this electric mobility product undergoes an inspection once every year under normal operating conditions (see inspection plan contained in service instructions).

  • Page 23: Safety Information On Electromagnetic Interference

    Safety information on electromagnetic interference This electric vehicle was successfully tested in accordance with International standards as to its compliance with Electromagnetic Interference (EMI) regulations. However, electromagnetic fields, such as those generated by radio and television transmitters, and cellular phones can influence the functions of electric vehicles.

  • Page 24: Safety Information On Driving And Freewheel Mode

    Safety information on driving and freewheel mode Danger of injury if the wheelchair tips over! • Inclines and declines can only be travelled up to the maximum safe slope (see chapter "Technical specifications" from page 140). • Always return the backrest of your seat or the seat tilt to an upright position before ascending slopes.
  • Page 25 Danger of breaking down in adverse weather conditions, i.e. extreme cold, in an isolated area! • If you are a user with severely limited mobility, we advise that in the case of adverse weather conditions DO NOT attempt a journey without an accompanying attendant! Danger of injury if your foot slides off the footrest and gets caught underneath the wheelchair when it is in motion! •...

  • Page 26: Safety Information Regarding Changes And Modifications To The Mobility Device

    EEC / MPG (Medical Devices Act) and only applies to the complete product. The CE marking is invalidated if components or accessories are replaced or added that have not been approved for this product by Invacare. In this case, the company that adds or replaces the components or accessories is responsible for the conformity assessment/ CE marking or for registering the wheelchair as a special design and for the relevant documentation.
  • Page 27 • Only use seating systems that have been approved by Invacare® for this power wheelchair. Electrical and electronic components which have not been approved by Invacare® for use with this mobility aid can cause fire hazards and lead to electromagnetic damage! •...

  • Page 28: Safety Information For Using The Wheelchair As A Vehicle Seat

    Safety information for using the wheelchair as a vehicle seat Danger of injury in the event of the wheelchair being used as a vehicle seat. • Never use the wheelchair as a vehicle seat. • Only ever transport the wheelchair without occupants. •...

  • Page 29: Key Features

    Key features 1) Sliding handle 7) Light/indicators/hazard indicators 2) Backrest 8) Legrests 3) Steering wheels 9) Parking brake 4) Drive wheels 10) Disengaging lever (drive) 5) Armrest 11) Disengaging lever (rear steering) (behind the faceplate) 6) Remote...

  • Page 30: Getting In And Out Of The Wheelchair

    Getting in and out of the wheelchair Danger of injury if legrests break due to use as a stepping board! • Do not use the legrests as a stepping board when getting in and out of the wheelchair! Important information when side transferring in and out of the wheelchair In order to side transfer it is necessary for the armrest to either be raised or removed completely depending on the model.

  • Page 31: Raise The Parallel Sliding Armrest / Remove The Skirtguard (Optional)

    Raise the parallel sliding armrest / remove the skirtguard (optional) Swivelling the armrest up • Swivel the armrest up to access from the side. Remove the clothes guard (option) for access • Disengage the release handle (1). • Pull the clothes guard out of the receptacle.
  • Page 32 Getting into the wheelchair: • Position your wheelchair as close as possible to your seat. This might have to be done by an attendant. • Switch your wheelchair off. • Apply the manual wheel lock of your wheelchair (if existing). •...

  • Page 33: Driving

    Driving NOTE The maximum load capacity that is stated in the technical data only states that the system is designed for this mass in total. However, this does not mean that one can sit a person with this body weight in the wheelchair without restrictions. Attention must be paid to the body proportions, such as height, weight distribution, abdominal girth, leg and calf girth and seat depth.

  • Page 34: Taking Obstacles

    • The rear mirror (if installed) is adjusted so you can look behind at all times without having to bend forward or shift your seating position. Taking Obstacles 5.2.1 Maximum obstacle height You can find information about maximum obstacle heights in the chapter entitled "Technical specifications"...

  • Page 35: The Correct Way To Overcome Obstacles

    5.2.3 The correct way to overcome obstacles Climbing up • Approach the obstacle or kerbstone at an angle of around 15°. • Shortly before the front wheels touch the obstacle, slightly increase the speed and only reduce it once the rear wheels have climbed the obstacle.

  • Page 36: Driving Up And Down Gradients

    Driving up and down gradients For information concerning the maximum safe slope, please see chapter "Technical specifications" starting on page 140. WARNING: Danger of tipping over! • Only ever drive downhill at a maximum of 2/3 of the top speed. Avoid sudden changes of direction or abrupt braking when driving on slopes.

  • Page 37: Parking And Stationary

    Parking and stationary When parking your vehicle or if your vehicle is stationary for a prolonged period: • Switch the vehicle's power system off (ON-/OFF key). • Activate your anti-theft lock, if existing. 5.4.1 Parking brake Please note In an emergency the parking brake can be used to slow the vehicle down. The brake lever is to be found on the left side.

  • Page 38: Use On Public Roads

    If you wish to use your wheelchair on public roads and lighting is required by national legislation, then your wheelchair needs to be equipped with an appropriate lighting system. Please contact your Invacare ® dealer if you have any questions. Pushing the wheelchair in freewheel mode...
  • Page 39 Disengaging the motors: • Switch off the remote. • Pull the release pin (1) upward. • Push the release lever (2) forward. Engaging the motors: • Switch off the remote. • Push the release lever backward.

  • Page 40: Disengaging The Steering Wheels

    Disengaging the steering wheels The disengaging lever of the steering mechanism is to be found at the rear of the wheelchair underneath the plastic apron. NOTE: The motors may only be disengaged by an attendant, not by the user! This ensures that the motors are only disengaged if an attendant is available to secure the wheelchair and prevent unintended rolling.

  • Page 41: Remotes

    Remotes Your wheelchair may be equipped with one of several different remotes. For information on the different functions and how to operate a particular remote, please see its corresponding User Manual (enclosed). Adjusting the wheelchair to the user's seating posture This chapter discusses different ways to adapt the wheelchair to the seating posture of the user.

  • Page 42: Adjusting The Armrests And The Control Panel

    Adjusting the armrests and the control panel 8.2.1 Adapting the remote to the arm length of the user 8.2.1.1 Sliding armrest Pre-requisites: • 1x 3 mm Allen key • Use the Allen key to loosen the screw (1). • Set the remote to the desired length. •...

  • Page 43: Transparent Side Section With Boarding Aid

    8.2.1.2 Transparent side section with boarding aid Pre-requisites: • 1x 3 mm Allen key • Use the Allen key to loosen the screw (1). • Set the remote to the desired length. • Re-tighten the screw. 8.2.1.3 Standard side section •...

  • Page 44: Adjusting The Height Of The Remote (Lowerable Remote Holder)

    8.2.2 Adjusting the height of the remote (lowerable remote holder) • Loosen the wing screw (1). • Set the remote to the desired height. • Re-tighten the wing screw.

  • Page 45: Adjusting The Height Of The Armrests

    8.2.3 Adjusting the height of the armrests 8.2.3.1 Sliding armrest Requirements: • Allen key 2 mm • Use the Allen key to loosen the screws (1) mm on both sides of the spindle. • Turn the spindle in a clockwise direction (A). The armrest is raised.

  • Page 46: Transparent Side Section With Boarding Aid

    8.2.3.2 Transparent side section with boarding aid Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the screw (1). • Set the armrest at the desired height. • Re-tighten the screw. 8.2.3.3 Standard side section •...

  • Page 47: Adjusting The Angle Of The Armpad On The Parallel Sliding Armrests

    8.2.4 Adjusting the angle of the armpad on the parallel sliding armrests Requirements: • Allen key 4 mm • Open-end spanner 10 mm • Loosen the screw (1, on the inner side of the armrest), which allows adjustment of the angle of the armpad, while countering the nut (2, outer side of the armrest) with the...

  • Page 48: Adjusting The Width Of The Armrests

    8.2.5 Adjusting the width of the armrests The space between the side sections can be adjusted 2 cm on both sides (4 cm total). Requirements: • Allen key 8 mm Where to find the adjustment screws The picture below shows the position of the screws that enable adjustment to the width of the armrests.
  • Page 49 Doing the adjustment • Loosen the screw (1). • Set the armrest in the desired position. • Re-tighten the screw. • Check that the armrest is fastened firmly. • Repeat the procedure for the other armrest.

  • Page 50: Adjusting The Backrest

    Adjusting the backrest 8.3.1 Flex and Contour seats • Set the angle by turning the hand wheel (1).

  • Page 51: Manually Adjusting The Seat Tilt

    Manually adjusting the seat tilt Note! The seat can be raised in the front to allow inspection of the components beneath it, such as batteries or the main fuse. However, maintenance work should not be carried out when the seat is in this position.
  • Page 52 The seat release button is to be found at the front underneath the edge of the seat (2). WARNING: Damage to the wheelchair is possible! • When tipping the seat backward, make sure the fixation brackets of the backrest do not damage the side or rear cowlings!
  • Page 53 • Press the release button and tip the seat backward carefully. The seat locks into place in this position.
  • Page 54 • Carefully pull the seat upward and to the front. Depending on the position of the tilt of the seat, this will remain in the position shown on the right or it will swivel further to the front.
  • Page 55 The picture below shows the position of the rod that enables adjustment to the angle of the seat.
  • Page 56 • Remove the SL locking device from the bolt using the flat screwdriver. • Remove the bolt. • Set the desired seat angle. • Re-insert the bolt and secure using the SL locking device. • Return the seat to the sitting position. •...
  • Page 57 • To lower the seat completely again, secure the seat with one hand to make sure it does not fall down and release the locking mechanism (1) with the other hand by pushing it back. The seat is now released and can be lowered carefully.

  • Page 58: Postural Belts

    Postural belts A postural belt is an option which can either be fixed to the wheelchair ex-works or can be retrofitted by your specialist dealer. If your wheelchair is fitted with a postural belt, your specialist dealer will have informed you about fitting and usage. The postural belt is used to help the wheelchair user keep an optimum sitting position.

  • Page 59: Adjusting The Postural Belt Correctly

    If the belt is only fastened with a bolted connection, ensure that the connection has not loosened or undone. You can find more information about maintenance work on belts in the service manual, which is available from Invacare®.

  • Page 60: Adjusting And Removing The Tray

    Adjusting and removing the tray CAUTION: Injury hazard or material damage if a power wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair. 8.6.1 Laterally adjusting the tray •...

  • Page 61: Adjusting The Depth Of The Tray / Removing The Tray

    8.6.2 Adjusting the depth of the tray / removing the tray • Loosen the wing-screw (1). • Adjust the table to the desired depth (or remove it entirely). • Re-tighten the screw. 8.6.3 Swinging the tray away to the side CAUTION! Risk of injury! When the tray is raised it does not lock in place in this position! •...

  • Page 62: Using The Klickfix Adapter

    Your wheelchair can be fitted with the mini-adapter from the Rixen + Kaul KLICKfix system. To this you can attach various accessories such as the cellphone case supplied by Invacare, which you can use to transport your cellphone, sports glasses etc.
  • Page 63 The adapter can turn in 90° steps, allowing you to attach an accessory from any of four different ® directions. Please refer to the installation instructions which are available from your Invacare ® dealer or directly from Invacare More information on the KLICKfix system is available at http://www.klickfix.com.

  • Page 64: Adjusting The Footrests And The Legrests

    Adjusting the footrests and the legrests Firmly mounted legrests 9.1.1 Standard legrests 9.1.1.1 Setting the calf plate (standard and electrically adjustable legrests) Requirements: • Phillips screwdriver • Loosen the screws (1). • Move the calf plate to the desired position. •...

  • Page 65: Adjusting The Length Of The Legrests (Standard And Electrically Adjustable Legrests)65

    9.1.1.2 Adjusting the length of the legrests (Standard and electrically adjustable legrests) Requirements: • Open-end spanner 10 mm • Loosen the screw (1). • Set the foot plate at the desired height. • Re-tighten the screw.

  • Page 66: Manually Adjustable Legrests

    9.1.2 Manually adjustable legrests 9.1.2.1 Adjusting the angle Upward • Pull the legrest upward until the desired angle has been achieved. The legrest locks in place automatically. Downward • Press the releave lever (1) downward. The legrest can now be moved downward.

  • Page 67: Adjusting The Calf Support (Manually Adjustable Legrests)

    9.1.2.2 Adjusting the calf support (manually adjustable legrests) The calf support on manually adjustable legrests is held by a clamp, and has two possible height settings Requirements: • Open-end spanner 13 mm • Allen key 6 mm Upward • Remove the plastic cap from the nut (lower side of the calf plate, not seen in the picture).

  • Page 68: Adjusting The Length Of The Legrest (Manually Adjustable Legrests)

    9.1.2.3 Adjusting the length of the legrest (manually adjustable legrests) The lower leg support tube is held by a clamp. Requirements: • Open-end spanner 13 mm • Use the open-ended spanner to loosen the screw (1). • Set the foot plate at the desired height. •...

  • Page 69: Electrically Adjustable Legrests

    9.1.3 Electrically adjustable legrests 9.1.3.1 Adjusting the angle Please consult the user manual for your remote for information about electrical adjustment. 9.1.3.2 Setting the calf plate (standard and electrically adjustable legrests) Requirements: • Phillips screwdriver • Loosen the screws (1). •...

  • Page 70: Adjusting The Length Of The Legrests (Standard And Electrically Adjustable Legrests)70

    9.1.3.3 Adjusting the length of the legrests (Standard and electrically adjustable legrests) Requirements: • Open-end spanner 10 mm • Loosen the screw (1). • Set the foot plate at the desired height. • Re-tighten the screw.

  • Page 71: Lowerable Legrests

    Lowerable legrests 9.2.1 Standard footrest with pre-set angle 9.2.1.1 Swivelling the footrest outward and/or removing The small unlocking button is located on the upper section of the footrest. When the footrest is unlocked, it can be swivelled inward or outward when getting into the wheelchair as well as being removed completely.

  • Page 72: Setting The Angle

    9.2.1.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...
  • Page 73 • Loosen the screw (1) using the Allen key. • Set the desired angle. • Re-tighten the screw.

  • Page 74: Setting The End Stop Of The Footrest

    9.2.1.3 Setting the end stop of the footrest Pre-requisites: • 1x 6 mm Allen key • 1x 10 mm open-ended spanner The end position of the footrest is determined by means of a rubber stop (1). The rubber stop can be screwed in or out (A) or pushed up or down (B).
  • Page 75 • Use the Allen key to loosen the screw (1) and swivel the footrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
  • Page 76 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the footrest to the desired position. • Re-tighten the screw.

  • Page 77: Adjusting The Length Of The Footrest

    9.2.1.4 Adjusting the length of the footrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...

  • Page 78: Manually Height Adjustable Legrest 90° - 0

    9.2.2 Manually height adjustable legrest 90° - 0° 9.2.2.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 79: Setting The Angle

    9.2.2.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! •...
  • Page 80 • Hit the knob to release the locking mechanism. • Set the desired angle.
  • Page 81 • Turn the knob clockwise to tighten it.

  • Page 82: Setting The End Stop Of The Legrest

    9.2.2.3 Setting the end stop of the legrest Pre-requisites: • 1x 10 mm open-ended spanner The end position of the legrest is determined by means of a rubber stop (A). The rubber stop can be screwed in or out (A) or pushed up or down (B).
  • Page 83 • Loosen the locking knob (1) counter-clockwise at least one turn. • Hit the knob to release the locking mechanism.
  • Page 84 • Swivel the legrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
  • Page 85 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the legrest to the desired position. • Re-tighten the locking knob.

  • Page 86: Adjusting The Length Of The Legrest

    9.2.2.4 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...

  • Page 87: Adjusting The Depth Of The Calf Plate

    9.2.2.5 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 88: Adjusting The Height Of The Calf Pad

    9.2.2.6 Adjusting the height of the calf pad Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 89: Unlocking And Swivelling The Calf Plate Backward When Alighting

    9.2.2.7 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 90: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 9.2.2.8 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 91: Adjusting The Angle And Depth Adjustable Foot Plate

    9.2.2.9 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 92: Manually Height Adjustable Legrest 80° - 0° With Ergonomic Length Adjustment

    9.2.3 Manually height adjustable legrest 80° - 0° with ergonomic length adjustment 9.2.3.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 93: Setting The Angle

    9.2.3.2 Setting the angle PLEASE NOTE: Danger of crushing! • Do not reach inside the swivelling range of the legrest! PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! •...
  • Page 94 • Lowering: Keep the legrest in the foot plate area, pull the lateral adjusting lever (1) and lower the legrest slowly.

  • Page 95: Adjusting The Length Of The Legrest

    9.2.3.3 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...

  • Page 96: Adjusting The Depth Of The Calf Plate

    9.2.3.4 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 97: Adjusting The Height Of The Calf Pad

    9.2.3.5 Adjusting the height of the calf pad Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 98: Unlocking And Swivelling The Calf Plate Backward When Alighting

    9.2.3.6 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 99: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 9.2.3.7 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 100: Adjusting The Angle And Depth Adjustable Foot Plate

    9.2.3.8 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 101: Electrically Height Adjustable Legrest 80° - 0° With Ergonomic Length Adjustment

    9.2.4 Electrically height adjustable legrest 80° - 0° with ergonomic length adjustment 9.2.4.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 102: Setting The Angle

    9.2.4.2 Setting the angle PLEASE NOTE: Danger of crushing! • Do not reach inside the swivelling range of the legrest! PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! The electrically height adjustable legrest is operated via the remote.

  • Page 103: Adjusting The Length Of The Legrest

    9.2.4.3 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that the legrests contact neither the castor wheels nor the ground! Pre-requisites: •...

  • Page 104: Adjusting The Depth Of The Calf Plate

    9.2.4.4 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 105: Adjusting The Height Of The Calf Pad

    9.2.4.5 Adjusting the height of the calf pad Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 106: Unlocking And Swivelling The Calf Plate Backward When Alighting

    9.2.4.6 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 107: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 9.2.4.7 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 108: Adjusting The Angle And Depth Adjustable Foot Plate

    9.2.4.8 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 109: Electrical System

    Electrical system 10.1 Electronics protection system The vehicle drive electronics is fitted with an overload protection. If the drive is severely overloaded over a long period (e.g. during steep climbs) and, above all, at simultaneous high external temperatures, the electronic system can overheat. In this case, the vehicle performance is gradually reduced until it comes to a standstill.

  • Page 110: The Main Fuse

    NOTE A defective main fuse may be replaced only after checking the entire electric system. An Invacare® specialised dealer must perform the replacement. You can find information on the fuse type in chapter "Technical specifications" starting on page 140. 10.2 Batteries Power is supplied by two 12 V batteries.

  • Page 111: How To Charge The Batteries

    10 °C. • Use only charging devices in Class 2. This class of chargers may be left unattended during charging. All charging devices which are supplied by Invacare® comply with these requirements.

  • Page 112: How To Disconnect The Batteries After Charging

    Risk of explosion and destruction of batteries if the wrong battery charger is used! • Only ever use the battery charger supplied with your vehicle, or a charger that has been approved by Invacare®. Risk of electric shock and damage to the battery charger if it gets wet! •...

  • Page 113: Storage And Maintenance

    10.2.2 Storage and Maintenance Follow the instructions listed below to ensure safe use and longevity of the batteries: • Always store the batteries fully charged. • Do not leave the batteries in a low state of charge for an extended length of time. Charge a discharged battery as soon as possible.
  • Page 114 • Driving with blinking red LED’s means an extreme stress for the battery and should be avoided under normal circumstances. • When only one red LED is blinking, the Battery Safe feature is enabled. From this time, speed and acceleration is reduced drastically. It will allow you to move the mobility device slowly out of a dangerous situation before the electronic finally cuts off.

  • Page 115: Transporting Batteries

    10.2.4 Transporting batteries The batteries supplied with your electric vehicle are not hazardous goods. This classification is based on the German GGVS Hazardous Goods Road Transport Ordinances, and the IATA/DGR Hazardous Goods Rail Transport / Air Transport Ordinances. Batteries may be transported without restrictions, whether by road, rail or by air.
  • Page 116 • Only ever transport damaged batteries in an appropriate acid-resistant receptacle. • Wash all objects that have come into contact with acid with lots of water. Disposing of dead or damaged batteries correctly Dead or damaged batteries can be given back to your dealer or directly to Invacare®.

  • Page 117: Tilting The Seating System Forward

    10.2.5.3 Tilting the seating system forward Note! The seat can be raised in the front to allow inspection of the components beneath it, such as batteries or the main fuse. However, maintenance work should not be carried out when the seat is in this position.
  • Page 118 The seat release button is to be found at the front underneath the edge of the seat (2). WARNING: Damage to the wheelchair is possible! • When tipping the seat backward, make sure the fixation brackets of the backrest do not damage the side or rear cowlings!
  • Page 119 • Press the release button and tip the seat backward carefully. The seat locks into place in this position.
  • Page 120 • Carefully pull the seat upward and to the front. Depending on the position of the tilt of the seat, this will remain in the position shown on the right or it will swivel further to the front.

  • Page 121: Removing The Batteries

    10.2.5.4 Removing the batteries • Remove the insulation shoe on the cable bridge with the fuse (1) at the negative terminal (blue cable). • Loosen battery clamp with spanner and remove screw. • Remove the insulation shoe on the cable bridge at the positive terminal (red cable).
  • Page 122 • Open the battery fixing strap. • Remove both batteries from the wheelchair frame using the carrying straps.

  • Page 123: Connecting The New Batteries

    10.2.5.5 Connecting the New Batteries • Place the batteries in the wheelchair frames with the battery terminals facing one another. • Connect the cables to the batteries in the reverse order to that detailed in section "Removing the batteries" on page 121. •...
  • Page 124 • Return the seat to the sitting position. • Re-position the retaining screws (1) and tighten firmly. • To lower the seat completely again, secure the seat with one hand to make sure it does not fall down and release the locking mechanism (1) with the other hand by pushing it back.

  • Page 125: Care And Maintenance

    Care and maintenance NOTE: Have your vehicle checked once a year by an authorised Invacare® dealer in order to maintain it's driving safety and roadworthiness. Cleaning the vehicle When cleaning the vehicle, pay attention to the following points: • Only use a damp cloth and gentle detergent.
  • Page 126 Maintenance Jobs Seat and backrest padding: - Check for perfect condition. Side part and armrest: - Are all fastening elements installed? - Can armrests / side parts be removed and installed without too much physical effort? - Are armrests secured in their positions? Legrests: - Do legrests lock into place without any problem? (Only applies to detachable legrests)
  • Page 127 Maintenance Jobs Electronics / Electrical System: - Check all plug connections for condition and firm seat. - Have all batteries been fully charged before the daily operation? Before every trip - Are all holders, screws firmly fixed, tight and safe? - Are all electric bulbs of the lighting system (if applicable) in working Before each trip order?

  • Page 128: Repair Instructions

    "Technical specifications" on page 140, or consult the Service Manual, available from Invacare® (in this connection please see the addresses and phone numbers in section "How can you get in touch with Invacare®?" on page 3). In case you require assistance, please contact your Invacare® Dealer.

  • Page 129: Repairing A Flat Tyre (Type 4.00-8" Pneumatic Tyres)

    12.1.1 Repairing a flat tyre (type 4.00-8" pneumatic tyres) Pre-requisites: • Torx TX-40 spanner • 5 mm Allen key • Repair kit for tyres with inner tube or a new hose. • Talcum powder Removing the wheel • Jack up the vehicle (place a piece of wood under the frame).
  • Page 130 Repairing a flat tyre • Unscrew the valve cap. • Let the air out of the tyre completely by pressing the pin in the centre of the valve in. • Use the Allen key to remove the 5 cheese-head screws (rear side of the wheel, 2).

  • Page 131: Repairing A Flat Tyre (Type 4.1/3.5-6 Pneumatic Tyres)

    12.1.2 Repairing a flat tyre (type 4.1/3.5-6 pneumatic tyres) Pre-requisites: • Flat screwdriver • 10 mm Allen key • 24 mm open-ended spanner • Repair kit for tyres with inner tube or a new hose. • Talcum powder Removing the wheel •...
  • Page 132 • Use the Allen key to secure the axle (2) and loosen the nut on the inner side of the rocker (covered) with the open-ended spanner. • Pull off the wheel and the axle in an outward direction. PLEASE NOTE Assembly is carried out in the reverse order.
  • Page 133 Repairing a flat tyre • Unscrew the valve cap. • Let the air out of the tyre completely by pressing the pin in the centre of the valve in. • Use the Allen key to remove the 5 cheese-head screws (rear side of the wheel, 2).

  • Page 134: Transport

    Transport CAUTION: Injury hazard or material damage if a power wheelchair which is fitted with a table is transported in a vehicle! • If a table is fitted, always remove it before transporting the wheelchair. 13.1 Transferring the wheelchair to a vehicle WARNING: The wheelchair is in danger of tipping over if it is transferred to a vehicle while the driver is still seated in the wheelchair! •...

  • Page 135: Securing The Wheelchair For Transport

    CAUTION: Injury hazard! ® • If you are unable to fasten your electric wheelchair securely in a transport vehicle, Invacare recommends that you do not transport it! • Before transporting your wheelchair, make sure the motors are engaged and that the Joystick Box is switched off.

  • Page 136: Refurbishment

    • With some seating systems and seat depths, the position of the seat needs to be moved backward! If necessary, a new seat frame that allows two different seat positions will need to be obtained from Invacare (available as a spare part)! Note!
  • Page 137 • Seat in the rear position = use the rear holes (1) to mount the seat plate. • Seat in the front position = use the front holes (2) to mount the seat plate. Note! When the seat is in the rear position, the short light fixation brackets (1) must be used to hold the headlights, when the seat is in the front position, long light fixation brackets (2) must be used (can be obtained as spare parts).

  • Page 138: Configuration Table

    14.1.1 Configuration table Seating Seat depth Position of the seat Wheel weights Puncture proof system tyres in the rear Standard Rear Front Front Contour Rear Necessary Necessary Rear Necessary Front Flex Rear Necessary Necessary Rear Necessary Necessary Rear Necessary Recaro Front...

  • Page 139: Disposal

    • Electric components and printed circuit boards are disposed of as electronic scrap. • Exhausted or damaged batteries can be returned to your medical equipment supplier or Invacare®. • Disposal must be carried out in accordance with the respective national legal provisions.

  • Page 140: Technical Specifications

    Permissible operating and storage conditions Temperature range for operation according to ISO 7176-9: • -25° … +50 °C Temperature range for storage according to ISO 7176-9: • -40° … +65 °C Invacare® BAT-GC0812 charger Output current • 8A Output voltage • 24V Input voltage •...
  • Page 141 Electric System 6 km/h version 10 km/h version Batteries • 2 x 12V, 47.4 Ah (5h) / 60 Ah (20h) • 2 x 12V, 63 Ah (5h) / 73.6 Ah (20h) • 2 x 12V, 80.5 Ah (5h) / 97.6 Ah (20h) (Recommended charger: Powercharge®...
  • Page 142 Dimensions Standard Kontur Flex Recaro Total length (incl. • 1240 mm standard legrests) Total length (excl. • 1030 mm legrests) Seat height **** • 510 mm Seat width (adjustable • 430 mm • 430 mm • 380 mm • 360/520 range of the armrests in (440 - 480 (440 - 480...
  • Page 143 **** Measured without seat cushion ***** The actual kerb weight depends on the fittings your mobility aid has been supplied with. Every Invacare® mobility aid is weighed when leaving the works. Please refer to the nameplate for the kerb weight (including batteries) measured.

  • Page 144: Inspections Performed

    It is confirmed by stamp and signature that all jobs listed in the inspection schedule of the Service and Repair Instructions have been properly performed. The list of the inspection jobs to be performed can be found in the Service Manual which is available through Invacare®. Delivery Inspection...

Table of Contents
