Page 1 HDX series Installation manual R5905032/00 01/06/2011...
Page 2 Barco nv Media & Entertainment Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86 Support: www.barco.com/esupport Visit us at the web: www.barco.com Printed in Belgium...
Page 3 GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged.
Page 5: Table Of Contents
Input menu overview ....................... . 94 R5905032 HDX SERIES 01/06/2011...
Page 6 12.1 Alignment menu overview ......................186 R5905032 HDX SERIES 01/06/2011...
Page 7 14.10 Save Custom Settings......................287 R5905032 HDX SERIES 01/06/2011...
Page 8 Index........................341 R5905032 HDX SERIES 01/06/2011...
Page 9: Safety
HDX projector. After this chapter, addi- tional “warnings” and “cautions” are given depending on the installation procedure. Read and follow these “warnings” and “cautions” as well. R5905032 HDX SERIES 01/06/2011...
Page 10: General Considerations
• Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualiﬁed Barco personnel or by authorized Barco service deal- ers. • All warnings on the projector and in the documentation manuals should be adhered to.
Page 11: Important Safety Instructions
0,1 micro-watts per square centimeters of effective UV radiation. An evaluation of the workplace is advised to assure employees are not exposed to cumulative radiation levels exceeding these government guidelines. The exposer of this UV radiation is allowed for only 1 hour per day for maintenance and service persons. R5905032 HDX SERIES 01/06/2011...
Page 12 ﬁre extinguishers. Never use water on an electrical ﬁre. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
Page 13 If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitu- tions may result in degraded performance and reliability, ﬁre, electric shock or other hazards.
Page 14: Important Warnings Concerning Hdx Flight Cases
In the event of a wheel breaking, ﬂight cases must be rigidly strapped tight to prevent a stack collapsing. • Use an appropriate forklift to raise ﬂight cases and take the necessary precautions to avoid personnel injury. R5905032 HDX SERIES 01/06/2011...
Page 15: General
• Installation process overview Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guar- antee. Observing the speciﬁcation mentioned in this chapter is critical for projector performance. Neglecting this can result in loss of warranty.
Page 16: Installation Requirements
Do not underestimate the weight of the HDX projector. The projector weights about ±50 kg (±111 lb.) without lens. Be sure that the pedestal on which the projector has to be installed is capable of handling ﬁve (5) times the complete load of the system. R5905032 HDX SERIES 01/06/2011...
Page 17: Unpacking The Projector
2. Remove the small box on top of the projector. This box contains the accessories such as manuals, remote control, etc. Image 2-2 Remove carton and foam rubber 3. Take out the foam rubber. 4. Take out the projector. R5905032 HDX SERIES 01/06/2011...
Page 18 A rubber foam inside a plastic bag is placed into the lens opening of the projector. It’s recommended to reuse this foam and plastic back each time you transport the projector. This to prevent intrusion of dust and foreign particles. The lens is delivered in a separate box. R5905032 HDX SERIES 01/06/2011...
Page 19: Initial Inspection
This check should conﬁrm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service ofﬁce should be notiﬁed as soon as possible if this is not the case.
Page 20: Hdx Flight Case
The dimensions of the ﬂight case are optimal for maximum utilization of the ﬂoor area of a truck. The cover of the FLM light case has 4 stacking dishes, which allows to stack the ﬂight cases. ARNING Maximum stack two (2) HDX ﬂight cases high. Never higher. R5905032 HDX SERIES 01/06/2011...
Page 21: Rear Projection
AUDIENCE FLOOR Image 2-5 Front projection, Ceiling mounted, in table position Rear projection The projector is installed, either in a table mount or ceiling mount conﬁguration, at the other side of the screen opposite the audience. R5905032 HDX SERIES 01/06/2011...
Page 22 2. General AUDIENCE BACKSTAGE FLOOR Image 2-6 Rear projection AUDIENCE BACKSTAGE FLOOR Image 2-7 Rear projection, ceiling mounted in table position R5905032 HDX SERIES 01/06/2011...
Page 23: Positioning The Projector
ﬁeld of view (F) as illustrated below. Within these shift ranges the projector and lens perform excellently. Conﬁguring the projector outside these shift ranges will result in a slight decline of image quality. R5905032 HDX SERIES 01/06/2011...
Page 24 15° 15° Image 2-10 Tilting allowed without problems No tilting allowed in this area Tilting allowed but lamp ﬂicker possible Projector lamp will not start up when out of tilt range due to build-in tilt sensor. R5905032 HDX SERIES 01/06/2011...
Page 25: Projector Air Inlets And Outlets
Image 2-11 The HDX projector has 3 air inlet channel and 3 air outlet. The air outlets are located at the rear of the projector. The air inlets are located at the front of the projector. R5905032 HDX SERIES 01/06/2011...
Page 26: Free Download Of Projector Toolset
Projector Toolset is only available in a download version, no CD can be ordered. Where to ﬁnd the download ﬁle(s) The program and all necessary plug-ins, as well as the Reference manual can be downloaded for free from Barco’s Partnerzone, URLhttps:\\my.barco.com. Registration is necessary.
Page 27: Installation Process Overview
8. Zoom and shift the lens until the image is properly projected on the screen, Do this by using the “ZOOM” and “FOCUS” key on the remote control unit or on the local keypad. If necessary, level the projector from side to side by turning the adjustable feet in or out. R5905032 HDX SERIES 01/06/2011...
Page 28 2. General R5905032 HDX SERIES 01/06/2011...
Page 29: Physical Installation
Connecting the projector with the power net • Alignment of a table mounted projector • Mounting the bottom carry handler • Mounting the top carry handler • Suspension of the projector with rigging clamps • Alignment of a ceiling mounted projector R5905032 HDX SERIES 01/06/2011...
Page 30: Remote Control Unit (Rcu)
Image 3-1 Remote control unit (RCU). Rugged case. XLR adaptor. Overview • RCU battery installation • RCU rugged case installation • RCU XLR adaptor installation • Using the XLR adaptor of the RCU • RCU usage possibilities R5905032 HDX SERIES 01/06/2011...
Page 31: Rcu Battery Installation
To prevent battery explosion • Danger of explosion if battery is incorrectly installed. • Replace only with the same or equivalent type recommended by the manufacturer. • Disposal of used batteries must be done according to the manufacturer’s instruction. R5905032 HDX SERIES 01/06/2011...
Page 32: Rcu Rugged Case Installation
How to install the rugged case of the remote control ? 1. Slide the bottom of the RCU into the rugged case and then pull the top of the rugged case over the top of the RCU as illustrated. Image 3-5 R5905032 HDX SERIES 01/06/2011...
Page 33: Rcu Xlr Adaptor Installation
Note: Ensure that the text of the XLR adaptor is on top. Image 3-6 2. Fasten the two screws (S) of the XLR adaptor. Turn each screw repeatedly one or two turns until both screws are tight. R5905032 HDX SERIES 01/06/2011...
Page 34: Using The Xlr Adaptor Of The Rcu
3. Push the XLR adaptor completely against the rugged case of the remote control unit, as illustrated in the left image below, for wired communication. Pull out the XLR adaptor (about 8 mm) to switch over to wireless communication. Image 3-7 R5905032 HDX SERIES 01/06/2011...
Page 35: Rcu Usage Possibilities
RCU with rugged case and XLR adaptor The RCU will send the commands via the cable connected with the XLR pushed in “WIRED” and wired adaptor to the projector. Backlight illuminates continuously when wire is connected. Infra red disabled. Image 3-8 R5905032 HDX SERIES 01/06/2011...
Page 36: Lenses
3. Physical installation Lenses Overview • Available lenses • Lens selection • Lens installation • Lens removal • Lens shift, zoom & focus • Scheimpﬂug adjustment R5905032 HDX SERIES 01/06/2011...
Page 37: Available Lenses
R9862030: TLD HB zoom lens (2.8 - 4,5 : 1) Image 3-15 Image 3-16 Image 3-17 R9842120: TLD HB zoom lens (5.0 - 8.0 : 1) R9862000: TLD+ lens (0.73 : 1) R9862005: TLD+ zoom lens (1.16 - 1.49 : 1) R5905032 HDX SERIES 01/06/2011...
Page 38 R9862020: TLD+ zoom lens (2.0 - 2.8 : 1) R9862030: TLD+ zoom lens (2.8 - 4.5 : 1) Image 3-21 Image 3-22 R9862040: TLD+ zoom lens (4.5 - 7.5 : 1) R9829997: TLD+ zoom lens (7.5 - 11.0 : 1) R5905032 HDX SERIES 01/06/2011...
Page 39: Lens Selection
How to select the right lens 1. Determine the required screen width (SW). 2. Determine the approximate position of the projector in the room. 3. Start up the Lens Calculator on the Barco web side : http://www.barco.com/en/tools/lenscalculator to determine the possible lenses for your conﬁguration.
Page 40: Lens Installation
7. Secure the lens in the lens holder by sliding the lens lock handle into the “locked” position, which is away from the lens power supply socket. Ensure the lens touches the front plate of the lens holder. R5905032 HDX SERIES 01/06/2011...
Page 41 8. Check if the lens is really secured by trying to pull the lens out of the lens holder. AUTION Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens before transporting the projector. Neglecting this can damage the Lens Holder and Prism. R5905032 HDX SERIES 01/06/2011...
Page 42: Lens Removal
It’s recommended to place the foam rubber of the original projector packaging, back in the Lens opening to prevent intrusion of dust. Note that this foam rubber is packed in a plastic bag to prevent the dust, emitted by the foam, from entering the projector. R5905032 HDX SERIES 01/06/2011...
Page 43: Lens Shift, Zoom & Focus
1. Press LENS FOCUS button [-] or [+] (C) for an overall focus of the image. 2. Press ▲ LENS SHIFT ▼ button for correct vertical position of the image on the screen. 3. Press ◄ LENS SHIFT ► button for correct horizontal position of the image on the screen. R5905032 HDX SERIES 01/06/2011...
Page 44: Scheimpﬂug Adjustment
1, 2 and 3 Scheimpﬂug adjustment nuts A, B, C and D Set screws a, b, c and d lock nuts 1, 2 and 3 are adjustment points. 4 is a locking point and NOT used during Scheimpﬂug adjustment. R5905032 HDX SERIES 01/06/2011...
Page 45: How To Adjust
Place the zoom lens in WIDE position (largest projected image) and adjust the focus by turning equally on nut 1, 2 and 3. c) Repeat steps “a” and “b” until the projected image is as sharp as possible. Image 3-34 Center focusing R5905032 HDX SERIES 01/06/2011...
Page 46 6. Sharpen bottom left corner of the screen by adjusting nut 1. Image 3-35 Left bottom focusing 7. Sharpen bottom right corner of the screen by adjusting nut 2. Image 3-36 Right bottom focusing 8. Sharpen top right corner of the screen by adjusting nut 3 R5905032 HDX SERIES 01/06/2011...
Page 47 5. Tighten nut 4 until the offset of the image movement created in step 3 is canceled. Tip: The amount of image movement in step 3 will determine how tight the nut in step 5 will need to be turned to return the image to its original position. R5905032 HDX SERIES 01/06/2011...
Page 48: Connecting The Projector With The Power Net
The projector is protected with an automatic circuit breaker of 20 A which is built into the power switch. The voltage meter is protected with a fuse (1A) which is located on the neutral bonding cable. If necessary to replace this fuse, consult a service technician. R5905032 HDX SERIES 01/06/2011...
Page 49: Alignment Of A Table Mounted Projector
3. Turn the adjustable feet in or out until the projected hatch pattern has a perfect rectangle shape and is leveled. Image 3-40 Level alignment When this is achieved, the projector is set horizontal and vertical at right angles to the screen. Image 3-41 Angle adjustment R5905032 HDX SERIES 01/06/2011...
Page 50: Mounting The Bottom Carry Handler
How to mount 1. Turn the projector upside down. 2. Turn out the 4 feet. Image 3-42 Remove feet 3. Turn out the feet of the carry handle as far as possible. Image 3-43 Mount carry handle R5905032 HDX SERIES 01/06/2011...
Page 51 4. Place the carry handle on the projector as illustrated. Adjustment knob to the back of the projector. Make sure that the mounting holes matches the holes in the projector. 5. Insert a bolt in each corner and turn in these bolts. Image 3-44 Insert bolts R5905032 HDX SERIES 01/06/2011...
Page 52: Mounting The Top Carry Handler
1. Place the carry handle on top of the projector so that the ﬁxation holes match the holes in the projector. Image 3-45 top carry handle 2. Turn in the 4 ﬁxation bolts (1). Insert a washer between the bolt and the carry handle. R5905032 HDX SERIES 01/06/2011...
Page 53: Suspension Of The Projector With Rigging Clamps
To release the nuts of the rigging points use a 24 mm open ended spanner. Ensure that the rigging points are symmetrically lined up, so that the projector will hang in balance. Warning: Be careful while working with heavy loads. Warning: Always secure the rigging points after adjustment. Image 3-48 Rigging points, distance R5905032 HDX SERIES 01/06/2011...
Page 54 5. Place the projector (upside down) under the truss installation and lower the truss until the support bars of the truss are nearby the rigging clamps mounted on the projector. Image 3-50 Mount to truss 6. Lift up the projector and hook the four rigging clamps over the support bars of the truss. R5905032 HDX SERIES 01/06/2011...
Page 55 Mount the 2 safety cables in such a way that when something goes wrong, the projector cannot fall more than 20 cm. If necessary, turn the cables a few times around the truss to obtain this maximum distance. R5905032 HDX SERIES 01/06/2011...
Page 56: Alignment Of A Ceiling Mounted Projector
3. Physical installation Alignment of a ceiling mounted projector Necessary tools No tools. Skew adjustment 1. Turn the adjustment knob on the carry handle until the projected hatch pattern is perfectly squared. Skew Image 3-53 Skew adjustment R5905032 HDX SERIES 01/06/2011...
Page 57: Input & Communication
4. Input & Communication 4. INPUT & COMMUNICATION Overview • Introduction • Input source connections • Communication connections • Utility-Accessory Outlet R5905032 HDX SERIES 01/06/2011...
Page 58: Introduction
XLR input port for remote control RS232/RS422 input port Dual Link DVI-I HDCP input Free input slot Button module Optional antenna for GSM RS232/RS422 input port Ethernet port Status and indication LEDs USB port 3G/Dual/HDSDI input - output Free input slot R5905032 HDX SERIES 01/06/2011...
Page 59: Input Source Connections
— — Super Video Luma Chroma — Component Video / (R - Y) / (B - Y) — — Component Video / (R - Y) / (B - Y) - SOY YUV-CV 5-cable input speciﬁcations : R5905032 HDX SERIES 01/06/2011...
Page 60 G(s) : 1Vpp ±3dB (0,7Vpp G + 0,3Vpp Sync) 75 Ohm termination. B : 0,7Vpp ±3dB 75 Ohm termination. • Diagnostic LED’s on front panel: Green LED: Lights up in case input module is selected Yellow LED: Lights up in case sync detected R5905032 HDX SERIES 01/06/2011...
Page 61: Communication Connections
DMX device (console). The DMX output port can be connected with the next device in the loop. Description Earth Cold Return - (or not used) Return + (or not used) DMX-512 Lighting protocol over RS-485 interface. Carries information of 512 channels from a lighting controller to lighting devices. Standardized by USITT. R5905032 HDX SERIES 01/06/2011...
Page 62 It is also called RS-232-C, which is the third version of the RS-232 standard, and is functionally identical to the CCITT V.24 standard. Logical ’0’ is > + 3V, Logical ’1’ is < - 3V. The range between -3V and +3V is the transition zone. R5905032 HDX SERIES 01/06/2011...
Page 63: Usb Port
IR received and acknowledged orange WIFI sel When WiFi is selected When WiFi is connected with an Ethernet See "Status LEDs", page 70. orange See "Status LEDs", page 70. orange See "Status LEDs", page 70. R5905032 HDX SERIES 01/06/2011...
Page 64: Utility-Accessory Outlet
Power 9 - 24 Volt DC With Setting in menu 9 / 12 / 24 @ 25W Note : do not overload ! Maximum 1A on 24V is allowed. The connector is a duplicated output of the DMX signal entering the projector over the 5 Pin XLR R5905032 HDX SERIES 01/06/2011...
Page 65: Getting Started
5. GETTING STARTED Overview • RCU & Local keypad • Terminology overview • Power on projector • Switching to standby • Power off projector • Status LEDs • Using the RCU • Projector Address • Source selection R5905032 HDX SERIES 01/06/2011...
Page 66: How Controlling The Projector
Other functions of the remote control are : • switching between stand by and operational mode. • switching to "pause" (blanked picture, full power for immediate restarting) • direct access to all connected sources. R5905032 HDX SERIES 01/06/2011...
Page 67: Terminology Overview
Auto alignment at ﬁrst access. Digit buttons Direct input selection or numeric entries Lens zoom/focus Zoom and focus controls of the lens Lens shift Shift control of the lens, to shift the lens up/down or left/right R5905032 HDX SERIES 01/06/2011...
Page 68 Direct access key for picture in picture selection. RC Operating indication Lights up when a button on the remote control is pressed. (This is a visual indicator to check the operation of the remote control) Table 5-1 R5905032 HDX SERIES 01/06/2011...
Page 69: Power On Projector
Main input the selected PIP input the IP address the Customer Id the Lamp status the Mains voltage the current ambient temperature the Text status (OSD) To display an image, the standby key must be pressed once. R5905032 HDX SERIES 01/06/2011...
Page 70: Software Overview
Software overview Once the projector is started, press About to get an overview of the software versions such as : Image 5-5 Local screen, about R5905032 HDX SERIES 01/06/2011...
Page 71 Standby key indication The projector starts up on the last saved source. The LMP LED on the communication interface lights up. Some lamp and runtime warnings can be displayed when an image is displayed after a start up. R5905032 HDX SERIES 01/06/2011...
Page 72: Switching To Standby
1. Press and hold Standby on the local keypad or the remote control. The projector goes to standby. All custom settings are written to the internal backup device. A message ’Save data ...’ indicates this process. Never switch off the projector while this message is displayed. R5905032 HDX SERIES 01/06/2011...
Page 73: Power Off Projector
2. Let cool down the projector until the fan speed decrease. At least 5 minutes. 3. Switch off the projector with the power switch. ’0’ must be pressed. AUTION Never switch off the projector while the message ’Save data ... ’ is displayed ! R5905032 HDX SERIES 01/06/2011...
Page 74: Status Leds
Lamp is on in ECO mode Green Lamp is on in normal mode Green-Orange Lamp is on in CLO mode ERR (error LED) No error Red toggles on/off Error Orange toggles on/off Warning IR signal received Green IR signal acknowledged R5905032 HDX SERIES 01/06/2011...
Page 75: Using The Rcu
IR sensor. 45° 45° 45° 45° 45° 45° Image 5-8 RCU to one of the IR sensors R5905032 HDX SERIES 01/06/2011...
Page 76: Projector Address
5. Getting started Projector Address R5905032 HDX SERIES 01/06/2011...
Page 77: Displaying And Programming Addresses Into The Rcu
2. Enter the address with the digit buttons within 5 seconds after pushing the address key. Note: That address can be any digit between 0 and 9. The LED on the remote control must lit up while pressing a digit key. Otherwise the address is not entered in the remote control. R5905032 HDX SERIES 01/06/2011...
Page 78: Controlling The Projector
IBM PC (or compatible), Apple MAC, etc. for addresses between 0 and 255. Common Address Every projector has a common address ’0’ or ’1’. The choice between ’0’ and ’1’ can be selected in Projector Control → Projector address → Common address. R5905032 HDX SERIES 01/06/2011...
Page 79: Source Selection
To select the source for the picture in picture window, press Window button until PiP window is activated and then select the desired source with the digit keys. To select the source for the main window, press Window button until the main window is activated and then select the desired source with the digit keys. R5905032 HDX SERIES 01/06/2011...
Page 80 5. Getting started R5905032 HDX SERIES 01/06/2011...
Page 81: Quick Set Up Adjustment
6. Quick set up adjustment 6. QUICK SET UP ADJUSTMENT Overview • Text boxes ON or OFF • Quick Lens Adjustment via LENS key • Direct Lens Adjustment (RCU) • Quick picture in picture • Quick language selection R5905032 HDX SERIES 01/06/2011...
Page 82: Text Boxes On Or Off
The on-screen text boxes can be switched OFF so that an adjustment during the operation of the projector are not visible on the screen. The adjustment indication remains visible on the local LCD screen. To toggle Text ON or OFF, press the TEXT key on the remote control or local keypad. R5905032 HDX SERIES 01/06/2011...
Page 83: Quick Lens Adjustment Via Lens Key
Press the LENS key to switch to another pattern. Different patterns are available. Quick shift adjustment 1. Press the LENS key on the remote control or local keypad to open the Zoom/Focus Adjustment menu. Image 6-2 Zoom/Focus adjustment 2. Press ENTER to go to the Shift menu. R5905032 HDX SERIES 01/06/2011...
Page 84 Shift adjustment 3. Use the ▲ or ▼ key to shift the lens in vertical direction. Use the ◄ or ► key to shift the lens in horizontal direction. Press ENTER to switch to zoom/focus adjustment. R5905032 HDX SERIES 01/06/2011...
Page 85: Direct Lens Adjustment (Rcu)
2. Press LENS FOCUS button [-] or [+] (C) for an overall focus of the image. 3. Press ▲ LENS SHIFT ▼ button for correct vertical position of the image on the screen. 4. Press ◄ LENS SHIFT ► button for correct horizontal position of the image on the screen. R5905032 HDX SERIES 01/06/2011...
Page 86: Quick Picture In Picture
Press on the PIP key on the remote control or the local keypad to activate the Load layout window. Use the ▲ ▼ key to scroll to the desired layout and press ENTER to activate. Select Main full screen to switch off PIP. Image 6-5 Load layout ﬁle list R5905032 HDX SERIES 01/06/2011...
Page 87: Quick Language Selection
3. Select the desired language with the ▲ ▼ key and press ENTER to activate. The current active language is indicated with a selected radio button Image 6-6 Main menu Image 6-7 Projector Control Image 6-8 Change language R5905032 HDX SERIES 01/06/2011...
Page 88 6. Quick set up adjustment R5905032 HDX SERIES 01/06/2011...
Page 89: Start Up Of The Adjustment Mode
About the use of the remote control and the local keypad • Start up the adjustment mode • Navigation and adjustments • Menu memory • Shortcut keys to the menus • Test patterns in adjustment mode R5905032 HDX SERIES 01/06/2011...
Page 90: About The Adjustment Mode
Projector control: contains the accessibility settings of the projector, such as address and communication setup. • Service: contains information about how the projector is performing. This information will be useful when calling for a service intervention. R5905032 HDX SERIES 01/06/2011...
Page 91: About The Use Of The Remote Control And The Local Keypad
All navigations and adjustments can be done either with the remote control or with the local keypad. Almost all the keys on the remote control have an equivalent on the local keypad. Exceptions: • Direct adjustment keys such as Contrast, Brightness, Saturation, Phase, etc. R5905032 HDX SERIES 01/06/2011...
Page 92: Start Up The Adjustment Mode
To start up the adjustment mode, use the remote control or the local keypad. How to start up? 1. Press Menu on the remote control (RCU) or on the local keypad to start up the Adjustment mode. The main menu of the adjustment mode opens. Image 7-1 Main menu R5905032 HDX SERIES 01/06/2011...
Page 93: Navigation And Adjustments
When the bar scale is displayed, via direct input. Press ENTER to activate the input ﬁeld. Image 7-4 Direct contrast adjustment Enter the desired value with the digit keys. Press ENTER to accept. Press EXIT to ﬁnalize the adjustment. R5905032 HDX SERIES 01/06/2011...
Page 94: Menu Memory
When restarting the projector from stand-by, the menu memory is reset. After re-opening the main menu and selecting an item, the previous selected sub item of that selected item is highlighted and can be opened just by pressing ENTER. R5905032 HDX SERIES 01/06/2011...
Page 95: Shortcut Keys To The Menus
Scroll to the desired menu. Press the digit key behind which the menu must be stored for 5 seconds. When the creation is success- fully, a conﬁrmation message appears on the screen. E.g. : Image 7-5 Select Yes to conﬁrm the creation. To erase the shortcut, navigate to Projector Control → Buttons. R5905032 HDX SERIES 01/06/2011...
Page 96: Test Patterns In Adjustment Mode
Press as many times on the Pattern key as necessary to display the desired test pattern. The test pattern remains on the screen as long as the adjustment mode is selected, even when selecting other menus. When leaving the adjustment mode, the selected test pattern is cleared and the normal image is displayed again. R5905032 HDX SERIES 01/06/2011...
Page 97: Input
8. Input 8. INPUT Overview • Input menu overview • Slot Module Type • Input locking • Native resolution • No Signal R5905032 HDX SERIES 01/06/2011...
Page 98: Input Menu Overview
Input on Main Window Input on Pip Window Input 1 Input 2 Input 3 Input 4 Free Run Free Run Options Native Resolution [On/Off] No Signal Color [black/blue] Logo [On/Off] Shutdown [Off/On] Shutdown time Auto dimming [On/Off] R5905032 HDX SERIES 01/06/2011...
Page 99: Slot Module Type
8. Input Slot Module Type Overview • About Input Setup • Input conﬁguration • DVI - RGB input • SDI input • 5 cable input R5905032 HDX SERIES 01/06/2011...
Page 100: About Input Setup
The projector has 4 input slots. Slot 1 and 2 is ﬁlled up by default with a DVI and Dual SDI input. Slot 3 and 4 can be ﬁlled up with optional input modules. Identical modules are allowed. R5905032 HDX SERIES 01/06/2011...
Page 101: Input Conﬁguration
3. Use the ▲ or ▼ key to select a slot. Press ENTER to open the selection menu which will be different from input type to input type. Image 8-2 Input window Image 8-1 Main window Image 8-3 Slot module type R5905032 HDX SERIES 01/06/2011...
Page 102: Dvi - Rgb Input
DVI - RGB input How to select Select DVI / RGB and press ENTER to open the selections Image 8-4 DVI selection The following selections are possible: • • DVI - dual link • RGB HS-VS/CS • YUV HS-VS/CS R5905032 HDX SERIES 01/06/2011...
Page 103: Sdi Input
4:4:4 - YCbCr-10 • 4:4:4 - RGB-10 • 4:4:4 - YCbCr-12 • 4:4:4 - RGB-12 • 4:2:2 - YCrCb-12 Then, select the 3G setting. Use the ▲ or ▼ key to select and press ENTER to accept. R5905032 HDX SERIES 01/06/2011...
Page 104 When Dual HD is selected, it is possible to use Swap links. If Swap links must be used, use the ▲ or ▼ key to select and press ENTER to accept. The check box will be checked. Dual HD : • Swap links R5905032 HDX SERIES 01/06/2011...
Page 105: Cable Input
For RGB selections, advanced settings are possible. To adjust these advanced settings, use the ▲ or ▼ key to select Advanced settings and press ENTER. The advanced settings menu opens: Press ENTER to toggle between [Analog] and [TTL]. R5905032 HDX SERIES 01/06/2011...
Page 106: Input Locking
Free run without changing the user settings. Once the sync is available, it applies again the user settings. Options for Free Run When free run is selected, radio button selected, then the Free Run Options become available. R5905032 HDX SERIES 01/06/2011...
Page 107 To change the locking frequency for Manual, use the ▲ or ▼ key to select Vert freq and press ENTER to activate. Image 8-13 Free run, manual setting Use the ▲ or ▼ key to change the value. R5905032 HDX SERIES 01/06/2011...
Page 108: Native Resolution
1. Press Menu to activate the menus and select Input → Native Resolution [On]. 2. Press ENTER to toggle between [On] and [Off]. [On] : images displayed in native resolution [Off] : images scaled to ﬁll the complete screen R5905032 HDX SERIES 01/06/2011...
Page 109 8. Input Image 8-16 Input, native resolution Image 8-15 Main window R5905032 HDX SERIES 01/06/2011...
Page 110: No Signal
Shutdown retarding time • Auto Dimming What can happen when no signal When no signal is available at the selected input, the output can be set to blue or black or a personal deﬁned logo can be displayed. R5905032 HDX SERIES 01/06/2011...
Page 111: Background Color
1. Press Menu to activate the menus and select Input → No Signal. → Color. 2. Press ENTER to toggle between [Blue] or [black]. Image 8-18 Input, no signal Image 8-17 Main window Image 8-19 No signal, color R5905032 HDX SERIES 01/06/2011...
Page 112: Background Logo
2. Press ENTER to toggle between [On] or [Off]. Image 8-21 Input, no signal Image 8-20 Main window Image 8-22 No signal, logo A dedicated logo can be loaded via Projector Toolset with a HDX plug-in installed. R5905032 HDX SERIES 01/06/2011...
Page 113: Shutdown Settings
Image 8-23 Main window Image 8-25 No signal, shutdown 2. Press ENTER to toggle between [On] and [Off]. [On] : projector goes in shutdown after a certain retarding time. [Off] : projector does not go in shutdown. R5905032 HDX SERIES 01/06/2011...
Page 114: Shutdown Retarding Time
1. Press Menu to activate the menus and select Input → No Signal. → Shutdown time (min). Image 8-27 Input, no signal Image 8-26 Main window Image 8-28 2. Press ENTER to toggle between [1], [3], [5] and [10] minutes. R5905032 HDX SERIES 01/06/2011...
Page 115: Auto Dimming
Main window Image 8-31 No signal, auto dimming 2. Press ENTER to toggle between [On] or [Off]. [On] : when no signal, auto dimming is started. [Off] : when no signal, no auto dimming is started. R5905032 HDX SERIES 01/06/2011...
Page 116 8. Input R5905032 HDX SERIES 01/06/2011...
Page 117: Image
9. Image 9. IMAGE Overview • Image menu overview • Start up the Image adjustments • Image settings • Aspect Ratio • Timings • Image File Services • Save custom settings R5905032 HDX SERIES 01/06/2011...
Page 118: Image Menu Overview
Horizontal Total Pixels Active pixels Horizontal start Period Total vertical lines Active lines Vertical start Advanced settings Clamp delay Clamp width Image ﬁle service Manual load File load ﬁlter Delete Delete all Rename Copy Options Save custom settings R5905032 HDX SERIES 01/06/2011...
Page 119: Start Up The Image Adjustments
9. Image Start up the Image adjustments Start up 1. Press Menu to activate the menus and select Image Image 9-2 Image adjustments Image 9-1 Main menu, Image R5905032 HDX SERIES 01/06/2011...
Page 120: Image Settings
9. Image Image settings About image settings Depending on the type of the connected source, some settings are grayed out R5905032 HDX SERIES 01/06/2011...
Page 121: Contrast
To adjust via the bar scale menu, press ENTER to display the Contrast menu and adjust with the ◄ or ► key. Press ENTER again to enter the value directly with the numeric keys. Press EXIT to return to Image Settings menu. Image 9-6 Contrast adjustment R5905032 HDX SERIES 01/06/2011...
Page 122: Brightness
To adjust via the bar scale menu, press ENTER to display the Brightness menu and adjust with the ◄ or ► key. Press ENTER again to enter the value directly with the numeric keys. Press EXIT to return to Image Settings menu. Image 9-10 Brightness adjustment R5905032 HDX SERIES 01/06/2011...
Page 123: Saturation
To adjust via the bar scale menu, press ENTER to display the Saturation menu and adjust with the ◄ or ► key. Press ENTER again to enter the value directly with the numeric keys. Press EXIT to return to Image Settings menu. R5905032 HDX SERIES 01/06/2011...
Page 124: Phase
1. Press Menu to activate the menus and select Image → Image Settings → Phase. Image 9-16 Image adjustments Image 9-15 Main menu, Image Image 9-17 Image settings, phase 2. Press ENTER to select. Image 9-18 Phase adjustment R5905032 HDX SERIES 01/06/2011...
Page 125 To adjust via the bar scale menu, press ENTER to display the Phase menu and adjust with the ◄ or ► key. Press ENTER again to enter the value directly with the numeric keys. Press EXIT to return to Image Settings menu. R5905032 HDX SERIES 01/06/2011...
Page 126: Color Temperature (Fixed Values)
Image 9-21 Image settings, color temperature 2. Press ENTER to select. The color temperature selection menu is displayed. Image 9-22 3. Use the ◄ or ► key to select the desired value. Press ENTER to accept. R5905032 HDX SERIES 01/06/2011...
Page 127 9. Image The following ﬁxed choices are possible : Projector White Computer 9300 Video 6500 Film 5400 Broadcast 3200 Next to these 5 ﬁxed temperatures, a custom setup is also possible. R5905032 HDX SERIES 01/06/2011...
Page 128: Color Temperature (Custom Values)
4. Select Gain Red and press ENTER. Use the ◄ or ► key to adjust the red gain. Select Gain Blue and press ENTER. Adjust the blue gain in the same way as the red gain using the ◄ or ► key. 5. When ﬁnished, press EXIT to return. R5905032 HDX SERIES 01/06/2011...
Page 129: Input Balance
9. Image 9.3.7 Input Balance R5905032 HDX SERIES 01/06/2011...
Page 130: Introduction To Input Balance
One can conclude here that a good data conversion can only be met by using three previously (input) balanced color signals The objective of input balancing The objective in input balancing is to “set” the same black level and the same white level for the three colors of a particular input source. R5905032 HDX SERIES 01/06/2011...
Page 131 These two references also set the range in which the ADC will work for that particular source (this explains also why each input balance setting is linked to a particular source and thus saved in the image ﬁle). R5905032 HDX SERIES 01/06/2011...
Page 132: Adjusting The Input Balance
Image 9-31 How to adjust 1. Press Menu to activate the menus and select Image → Image Settings → Input Balance. Image 9-33 Image adjustments Image 9-32 Main menu, Image R5905032 HDX SERIES 01/06/2011...
Page 133 Performing White input balance 1. Connect the source you want to project. 2. Press Menu to activate the menus and select Image → Image Settings → Input Balance. Image 9-37 Image adjustments Image 9-36 Main menu, Image R5905032 HDX SERIES 01/06/2011...
Page 134 4. Adjust the Green black balance until ﬁrst gray dots in the black bar (only in the black bar, the rest must be mid gray, except the white bar). 5. If you see multiple or no white bars in stead of one, change white balance for green (higher or lower) until only one bar is visible. R5905032 HDX SERIES 01/06/2011...
Page 135: Aspect Ratio
1. Press Menu to activate the menus and select Image → Aspect Ratio. Image 9-42 Image, aspect ratio Image 9-41 Main menu, Image 2. Press ENTER to select. 3. Use the ▲ or ▼ key to select the desired aspect ratio. R5905032 HDX SERIES 01/06/2011...
Page 136 Press ENTER to open the X adjustment menu and follow the adjustment method as described in "Navigation and adjustments", page 89. 3. Select Y and change the current value in the same way until the desired value is obtained. R5905032 HDX SERIES 01/06/2011...
Page 137: Timings
9. Image Timings R5905032 HDX SERIES 01/06/2011...
Page 138: Source Timings
ENTER to open the speciﬁc adjustment menu. Follow the adjustment method as described in "Navigation and adjust- ments", page 89. 5. Continue with the other settings in the same way until all timings are set. R5905032 HDX SERIES 01/06/2011...
Page 139: Advanced Timings, Clamp Delay - Clamp Width
How to change the clamp delay - clamp width 1. Press Menu to activate the menus and select Image → Timings → Advanced settings. Image 9-50 Image, timings Image 9-49 Main menu, Image Image 9-51 Timings, advanced settings 2. Press ENTER to select. R5905032 HDX SERIES 01/06/2011...
Page 140 3. Use the ▲ or ▼ key to select Clamp Delay or Clamp Width and use the ◄ or ► key to change the value. press ENTER to open the speciﬁc adjustment menu. Follow the adjustment method as described in "Navigation and adjust- ments", page 89. R5905032 HDX SERIES 01/06/2011...
Page 141: Image File Services
9. Image Image File Services R5905032 HDX SERIES 01/06/2011...
Page 142: Connecting A New Source
• Rename : renaming a ﬁle. • Delete : deleting a ﬁle (only custom ﬁles) • Delete all : delete all custom ﬁles • Options : way of loading a ﬁle when a source is selected. R5905032 HDX SERIES 01/06/2011...
Page 143: Manual Load File
3. Use the ▲ or ▼ key to select the desired ﬁle and press ENTER to load this ﬁle. The image is not perfect If the displayed image is not correct after selecting the best ﬁtting ﬁle, go to the Timings menu and change the ﬁle settings. R5905032 HDX SERIES 01/06/2011...
Page 144: File Load Filter
1. Press Menu to activate the menus and select Image → Image File Services → File Load Filter. Image 9-58 Image, image ﬁle services Image 9-57 Main menu, Image Image 9-59 File load ﬁlter 2. Press ENTER to toggle between [All] and [Fit]. R5905032 HDX SERIES 01/06/2011...
Page 145: Delete A File
If no custom ﬁles are available, a message that no custom ﬁles are available is displayed. 3. Use the ▲ or ▼ key to select the ﬁle to delete. Image 9-63 Delete custom ﬁle 4. Press ENTER to delete the selected ﬁle. No recovery possible ! R5905032 HDX SERIES 01/06/2011...
Page 146: Delete All Custom Files
2. Use the ▲ or ▼ key to select Yes or No. Image 9-67 Delete all 3. If Yes is selected, press ENTER to delete all custom ﬁles. If No is selected, press ENTER to return to the Image File Services menu without deleting any custom ﬁle. R5905032 HDX SERIES 01/06/2011...
Page 147: Rename Custom Files
If no custom ﬁles are available, a message that no custom ﬁles are available is displayed. Image 9-71 Rename, list of ﬁles 3. Use the ▲ or ▼ key to select the ﬁle to rename and press ENTER. R5905032 HDX SERIES 01/06/2011...
Page 148 Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. Arrow key left (◄) has the backspace functionality. 5. Press ENTER to ﬁnalize the rename action. R5905032 HDX SERIES 01/06/2011...
Page 149: Copy Custom File
Image ﬁle services, copy 2. Press ENTER to select. The available custom ﬁles are displayed. Image 9-76 Copy ﬁles, list If no custom ﬁles are available, a message that no custom ﬁles are available is displayed. R5905032 HDX SERIES 01/06/2011...
Page 150 Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. Arrow key left (◄) has the backspace functionality. R5905032 HDX SERIES 01/06/2011...
Page 151: Image File Service Options, Load File
2. Press ENTER to toggle between [Automatic], [Manual] or [Custom only]. Automatic : correct ﬁle will be loaded automatically. Manual : correct ﬁle should be loaded manually. Custom only : correct ﬁle will be loaded automatically out of the available custom ﬁles. R5905032 HDX SERIES 01/06/2011...
Page 152: Image File Service Options, Auto Picture Alignment
2. Press ENTER to toggle between [Off], [Always] or [Load File]. Off : auto picture alignment deactivated. Always : auto picture alignment is always activated. Load ﬁle: when new ﬁle is loaded for the selected source. R5905032 HDX SERIES 01/06/2011...
Page 153: Save Custom Settings
1. Press Menu to activate the menus and select Image → Save Custom Settings Image 9-88 Image, save custom settings Image 9-87 Main menu, Image 2. Use the ▲ or ▼ key to select Yes and press ENTER. Image 9-89 Save custom settings, question R5905032 HDX SERIES 01/06/2011...
Page 154 9. Image R5905032 HDX SERIES 01/06/2011...
Page 155: Layout
10. Layout 10. LAYOUT Overview • Layout menu overview • Introduction • Main window • PiP window • Layout File Services • Zoom - Focus - Shift windows R5905032 HDX SERIES 01/06/2011...
Page 156: Layout Menu Overview
Pip Window [On], [Off] Source Size Position Layout File Services Load Main Full Screen Native Resolution Pip Up Right Split Left Right Split Top Bottom Custom x Rename Delete Delete all Copy/Save as Zoom/Focus/Shift Same zoom/focus/shift [yes], [no] R5905032 HDX SERIES 01/06/2011...
Page 157: Introduction
Layout ﬁles determine the size and the position of the main and PiP window on the screen. Some pre-deﬁned layouts are available in the projector but custom layouts can be created and saved for future use. R5905032 HDX SERIES 01/06/2011...
Page 158: Main Window
10. Layout 10.3 Main window Overview • Main window source selection • Main window size • Main window position When starting the Main window settings, the system will ask to create a custom layout R5905032 HDX SERIES 01/06/2011...
Page 159: Main Window Source Selection
Image 10-4 Select source 3. Use the ▲ or ▼ key to select the desired source and press ENTER. The radio button of the selected source is checked and the source is linked with the main window. R5905032 HDX SERIES 01/06/2011...
Page 160: Main Window Size
How to change the size 1. Press Menu to activate the menus and select Layout → Main window → Size. Image 10-7 Layout, main window Image 10-6 Main menu, layout Image 10-8 Main window, size 2. Press ENTER to select. R5905032 HDX SERIES 01/06/2011...
Page 161 A Save Layout window opens. Image 10-10 Save layout 6. Use the ▲ or ▼ key to select Yes and press ENTER to save. Select No if you want to quit without saving the current position. R5905032 HDX SERIES 01/06/2011...
Page 162: Main Window Position
The Position window opens. Image 10-15 Position window 3. Use the ▲ or ▼ key to change the Top position and the ◄ or ► key to change the Left position. 4. When desired position is reached, press EXIT. R5905032 HDX SERIES 01/06/2011...
Page 163 A Save Layout window opens. Image 10-16 Save layout 5. Use the ▲ or ▼ key to select Yes and press ENTER to save. Select No if you want to quit without saving the current position. R5905032 HDX SERIES 01/06/2011...
Page 164: Pip Window
10. Layout 10.4 PiP window Overview • Introduction to PIP • Picture in Picture activation • PiP window, source selection • PiP window, Size • PiP window, position R5905032 HDX SERIES 01/06/2011...
Page 165: Introduction To Pip
The input section of the projector allows a combination of different input signals which may be projected in the 2 windows, main and PiP. The PiP window can be placed anywhere, with any dimensions, on the screen by changing its position and its size. Image 10-17 Position of PiP Top position Left position R5905032 HDX SERIES 01/06/2011...
Page 166: Picture In Picture Activation
1. Press Menu to activate the menus and select Layout → PiP window → PiP window [On] / [Off]. Image 10-19 Layout, PiP Window Image 10-18 Main menu, layout Image 10-20 PiP window, activation 2. Press ENTER to toggle between [On] or [Off]. R5905032 HDX SERIES 01/06/2011...
Page 167: Pip Window, Source Selection
3. Use the ▲ or ▼ key to select the desired source and press ENTER. The radio button of the selected source is checked and the source is linked with the PiP window. PiP source and main source can be the same input. R5905032 HDX SERIES 01/06/2011...
Page 168: Pip Window, Size
Remark: During adjustment of the window size, scaling artifacts can be visible. Image 10-26 Size PIP window remark How to resize 1. Press Menu to activate the menus and select Layout → PiP window → Size. Image 10-28 Layout, PiP Window Image 10-27 Main menu, layout R5905032 HDX SERIES 01/06/2011...
Page 169 A Save Layout window opens. Image 10-31 Save layout 6. Use the ▲ or ▼ key to select Yes and press ENTER to save. Select No if you want to quit without saving the current position. R5905032 HDX SERIES 01/06/2011...
Page 170: Pip Window, Position
A Save Layout window opens. Image 10-36 Save layout 5. Use the ▲ or ▼ key to select Yes and press ENTER to save. Select No if you want to quit without saving the current position. R5905032 HDX SERIES 01/06/2011...
Page 171: Layout File Services
10. Layout 10.5 Layout File Services Overview • Load layout ﬁle • Rename layout ﬁle • Delete layout ﬁle • Delete all layout ﬁles • Copy or Save as layout ﬁle R5905032 HDX SERIES 01/06/2011...
Page 172: Load Layout File
When staying for at least 3 seconds on the same ﬁle selection after scrolling through the list of layoout ﬁles a pre-load is started. Image 10-40 Load layout ﬁle list 3. Use the ▲ or ▼ key to select the desired ﬁle and press ENTER to activate. The radio button in front of the selected ﬁle is checked. R5905032 HDX SERIES 01/06/2011...
Page 173: Rename Layout File
Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. Arrow key left (◄) has the backspace functionality. R5905032 HDX SERIES 01/06/2011...
Page 174: Delete Layout File
A conﬁrmation window is displayed. Image 10-50 4. Use the ▲ or ▼ key to select Yes and press ENTER to delete the custom layout. Select No if you want to quit without deleting the custom ﬁle. R5905032 HDX SERIES 01/06/2011...
Page 175: Delete All Layout Files
If no custom ﬁles are available, a message that no custom ﬁles are available is displayed. Image 10-54 Layout ﬁles, delete all conﬁrmation 3. Use the ▲ or ▼ key to select Yes. Press ENTER to delete all layout ﬁles. R5905032 HDX SERIES 01/06/2011...
Page 176: Copy Or Save As Layout File
Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. Arrow key left (◄) has the backspace functionality. R5905032 HDX SERIES 01/06/2011...
Page 177: Zoom - Focus - Shift Windows
[No] = each layout will use its own zoom/focus/shift settings. [Yes] = each layout will use the same zoom/focus/shift settings. The zoom/focus/shift settings of the previous selected layout will be applied to the next selected layouts. R5905032 HDX SERIES 01/06/2011...
Page 178 10. Layout R5905032 HDX SERIES 01/06/2011...
Page 179: Lamp
11. LAMP Overview • Lamp menu overview • Lamp power mode • Lamp power • Auto dimming when on Pause • CLO mode (Constant light output mode) • CLO targets • Lamp identiﬁcation • Z-axis adjustment R5905032 HDX SERIES 01/06/2011...
Page 180: Lamp Menu Overview
11. Lamp 11.1 Lamp menu overview Overview table Level 1 Level 2 Level 3 Lamp Power Power mode Power Auto dimming when pause CLO mode CLO targets Identiﬁcation Z-axis Light output R5905032 HDX SERIES 01/06/2011...
Page 181: Lamp Power Mode
When the power mode is [Economic] and the CLO mode is switched to the [On] mode, then the power mode will be switched to the [Normal] mode. Once the CLO mode is switched to [Off] again, then the power mode is switched back to [Economic] R5905032 HDX SERIES 01/06/2011...
Page 182: Lamp Power
1. Press Menu to activate the menus and select Lamp → Power → Power. Image 11-5 Lamp, power Image 11-4 Main menu, lamp Image 11-6 Lamp power adjustment 2. Use the ◄ or ► key to change the power value. The value can be changed between 75 and 100% R5905032 HDX SERIES 01/06/2011...
Page 183: Auto Dimming When On Pause
Auto dimming when Pause 2. Press ENTER to toggle between [On] or [Off]. [On] : when switched to pause, lamp power will be reduced. [Off] : when switched to pause, power remains on its original value. R5905032 HDX SERIES 01/06/2011...
Page 184: Clo Mode (Constant Light Output Mode)
Image 11-10 Relative Light Output (%) Constant Light Output working area Runtime (hrs) 1000 Image 11-11 How to switch CLO mode 1. Press Menu to activate the menus and select Lamp → Power → CLO mode. R5905032 HDX SERIES 01/06/2011...
Page 185 11. Lamp Image 11-13 Lamp, power Image 11-12 Main menu, lamp Image 11-14 Power, CLO mode 2. Press ENTER to toggle between [On] or [Off]. R5905032 HDX SERIES 01/06/2011...
Page 186: Clo Targets
1. Press Menu to activate the menus and select Lamp → Power → CLO mode. Image 11-16 Lamp, power Image 11-15 Main menu, lamp Image 11-17 CLO Target lumens setup 2. Use the ◄ or ► key to change the CLO target lumens. R5905032 HDX SERIES 01/06/2011...
Page 187: How To Display
These parameters are useful in case of a service request. How to display 1. Press Menu to activate the menus and select Lamp → Identiﬁcation. Image 11-19 Lamp, identiﬁcation Image 11-18 Main menu, lamp 2. Press ENTER to select. Image 11-20 Lamp identiﬁcation R5905032 HDX SERIES 01/06/2011...
Page 188: Z-Axis Adjustment
How to display the light output 1. Press Menu to activate the menus and select Lamp → Z-axis. Image 11-22 Lamp, Z-axis Image 11-21 Main menu, lamp 2. Press ENTER to display the current light output. Image 11-23 Current light output R5905032 HDX SERIES 01/06/2011...
Page 189: Alignment
Lens adjustment, zoom - focus • Lens adjustment, shift • Lens adjustment, mid position • Home lens at startup • Calibrate lens • Warping • Blanking adjustment • Contrast-Intensity • Gamma • Internal patterns • Color space • Scenergix R5905032 HDX SERIES 01/06/2011...
Page 190: Alignment Menu Overview
Keystone Pin/Barrel 4 corners Warp ﬁle service Reset Blanking Bottom Left Right Contrast/Intensity Contrast enhancement Intensity Gamma Internal Patterns Color Space Status Projector SMPTE Custom ScenergiX Status White level Black level ScenergiX pattern Adjust lines Reset R5905032 HDX SERIES 01/06/2011...
Page 191: Orientation
1. Press Menu to activate the menus and select Alignment → Orientation. Image 12-1 Main menu, alignment Image 12-2 Alignment, orientation 2. Use the ▲ or ▼ key to select the desired orientation and press ENTER to activate. Image 12-3 Orientation list R5905032 HDX SERIES 01/06/2011...
Page 192: Lens Adjustment, Zoom - Focus
Image 12-6 Lens, Zoom/Focus 3. Use the ▲ or ▼ key to zoom the lens. Use the ◄ or ► key to focus the lens. Press ENTER to switch to Lens shift adjustment. Image 12-7 Zoom/Focus adjustment R5905032 HDX SERIES 01/06/2011...
Page 193: Lens Adjustment, Shift
3. Use the ▲ or ▼ key to shift the lens in vertical direction. Use the ◄ or ► key to shift the lens in horizontal direction. Press ENTER to switch to Zoom/Focus adjustment. Image 12-11 Shift adjustment R5905032 HDX SERIES 01/06/2011...
Page 194: Lens Adjustment, Mid Position
Image 12-13 Alignment, lens 2. Use the ▲ or ▼ key to select Mid Position and press ENTER to activate. Image 12-14 Lens, mid position Lens will be shifted horizontally and vertically to its mid position. R5905032 HDX SERIES 01/06/2011...
Page 195: Home Lens At Startup
Image 12-15 Main menu, alignment Image 12-16 Alignment, lens 2. Use the ▲ or ▼ key to select Home lens at startup and press ENTER to toggle between [on] and [off]. Image 12-17 Home lens at startup R5905032 HDX SERIES 01/06/2011...
Page 196: Calibrate Lens
2. Use the ▲ or ▼ key to select Calibrate lens and press ENTER to activate. Image 12-20 Calibrate lens A conﬁrmation window opens. Select Yes to start the calibration procedure. Image 12-21 Calibrate lens conﬁrmation R5905032 HDX SERIES 01/06/2011...
Page 197: Warping
Not all models are equipped with a warping unit. For these models, the warping unit is optional. Overview • About warping • Warping status • Rotation • Keystone • Pin-Barrel correction • 4 corners adjustment • Warp ﬁle service R5905032 HDX SERIES 01/06/2011...
Page 198: About Warping
While an image can be transformed in various ways, pure warping doesn’t affect the colors. Some examples of warped images, using the warp geometry settings: Image 12-22 Image 12-23 Example 1 : distorted image Example 2 : distorted image R5905032 HDX SERIES 01/06/2011...
Page 199: Warping Status
How to set the warp status 1. Press Menu to activate the menus and select Alignment → Warping. Image 12-24 Main menu, alignment Image 12-25 Alignment, warping Image 12-26 Warping, status 2. Press ENTER to toggle between [Off], [Manual] or [File]. R5905032 HDX SERIES 01/06/2011...
Page 200: Rotation
2. Press ENTER to open the Warping menu. Image 12-30 Warping, rotation 3. Use the ▲ or ▼ key to select Rotation. 4. Press ENTER to check the Rotation check box. 5. Use the ► key to open the rotation adjustment. R5905032 HDX SERIES 01/06/2011...
Page 201 12. Alignment Image 12-31 Rotation 6. Use the ◄ or ► key to change the value of the selected adjustment or enter the value with the numeric keys. R5905032 HDX SERIES 01/06/2011...
Page 202: Keystone
Image 12-32 Keystone adjustment How to adjust 1. Press Menu to activate the menus and select Alignment → Warping . Image 12-33 Main menu, alignment Image 12-34 Alignment, warping 2. Press ENTER to open the Warping menu. R5905032 HDX SERIES 01/06/2011...
Page 203 6. Use the ▲ or ▼ key to select Horizontal Keystone or Vertical Keystone. Use the ◄ or ► key to adjust the value of the selected keystone or enter the desired value with the numeric keys. R5905032 HDX SERIES 01/06/2011...
Page 204: Pin-Barrel Correction
2. Press ENTER to open the Warping menu. 3. Use the ▲ or ▼ key to select Pin/Barrel. Image 12-40 Warping, Pin/Barrel 4. Press ENTER to check the Pin/Barrel check box. 5. Use the ► key to open the keystone adjustments. R5905032 HDX SERIES 01/06/2011...
Page 205 6. Use the ▲ or ▼ key to select Pinc./Barrel Hor. or Pinc/Barrel Vert.. Use the ◄ or ► key to adjust the value of the selected Pin/barrel or enter the value with the numeric keys. R5905032 HDX SERIES 01/06/2011...
Page 206: Corners Adjustment
4 corner, warping menu 5. Use the ▲ or ▼ key to select the desired corner and direction. Use the ◄ or ► key to adjust the value or enter the value with the numeric keys. R5905032 HDX SERIES 01/06/2011...
Page 207: Warp File Service
2. Press ENTER to activate. A list with possible warp ﬁles is displayed. Image 12-49 List of warp ﬁles 3. Use the ▲ or ▼ key to select the desired warp ﬁle and press ENTER to load this ﬁle. R5905032 HDX SERIES 01/06/2011...
Page 208: Blanking Adjustment
The reset function brings all blanking settings back to zero. How to adjust 1. Press Menu to activate the menus and select Alignment → Blanking. Image 12-51 Main menu, alignment Image 12-52 Alignment, blanking 2. Press ENTER to select. R5905032 HDX SERIES 01/06/2011...
Page 209 The blanking adjustment menu opens. Image 12-53 Blanking adjustment 3. Use the ▲ or ▼ key to select the desired blanking adjustment and adjust with the ◄ or ► key. Select Reset to reset all blanking adjustments. R5905032 HDX SERIES 01/06/2011...
Page 210: Contrast-Intensity
Use the ◄ or ► key to change the contrast enhancement until the desired value is reached (adjustable between 0 and 5) 4. Use the ▲ or ▼ key to select Intensity. Use the ◄ or ► key to change the intensity until the desired value is reached (adjustable between 0 and 255) Image 12-57 Intensity R5905032 HDX SERIES 01/06/2011...
Page 211: Gamma
1. Press Menu to activate the menus and select Alignment → Gamma. Image 12-58 Main menu, alignment Image 12-59 Alignment, gamma 2. Press ENTER to toggle between the different values. A range of 8 values are available between 1.0 and 3.1 in steps of 0.3. R5905032 HDX SERIES 01/06/2011...
Page 212: Internal Patterns
3. Use the ▲ or ▼ key to select a pattern and press ENTER to display that pattern. The following patterns are available: Checker board Color Bars Convergence Convergence_2 Ansi Lumen Focus white Focus black Focus green Full Screen Black Full Screen White Cross Hatch Outline Scenergix R5905032 HDX SERIES 01/06/2011...
Page 213: Color Space
The user can deﬁne the x and y coordinates for red, green and blue which forms the corners of the color space. By changing the coordinates, the color reproduction can be changed. Edit color targets Color targets will be used when Custom is selected. 1. Select Edit Color Targets and press ENTER. R5905032 HDX SERIES 01/06/2011...
Page 214 2. Use the ▲ or ▼ key to select a color coordinate. Use the ◄ or ► key to change the value of the selected coordinate. Adjust all other coordinates in the same way. Select Reset to return to previous saved values. R5905032 HDX SERIES 01/06/2011...
Page 215: Scenergix
12. Alignment 12.14 Scenergix R5905032 HDX SERIES 01/06/2011...
Page 216: Introduction
Adjustable overlapping area Light output per image 100% image 1 image 2 Total composite light output 100% image 1 image 2 Image 12-69 ScenergiX Basic Principle R5905032 HDX SERIES 01/06/2011...
Page 217: Preparations
12. Alignment 12.14.2 Preparations ScenergiX Preparations To ensure proper ScenergiX adjustment, be sure that the following adjustments are done perfectly on all projectors: • Convergence • Geometry • Color Matching (Color Temperature, Color Standard, Input Balance, Gamma) R5905032 HDX SERIES 01/06/2011...
Page 218: Scenergix Activation
The Scenergix menu opens. Image 12-72 Scenergix, status 3. Use the ▲ or ▼ key to select Status and press ENTER to toggle between [On] and [Off] [On] : Scenergix is activated. [Off] : Scenergix is deactivated R5905032 HDX SERIES 01/06/2011...
Page 219: Scenergix Pattern
[Off] : no scenergix pattern is displayed. 10 50 90 130 170 210 250 290 330 370 40 80 120 160 200 240 280 320 360 400 10 50 90 130 170 210 250 290 330 370 Image 12-76 Scenergix pattern R5905032 HDX SERIES 01/06/2011...
Page 220: Scenergix Adjustment Lines
How to display 1. Press Menu to activate the menus and select Alignment → Scenergix → Adjust lines. Image 12-77 Main menu, alignment Image 12-78 Alignment, Scenergix Image 12-79 2. Press ENTER to toggle between [On] and [Off]. R5905032 HDX SERIES 01/06/2011...
Page 221: White Level Adjustment (Blending Area)
3. Use the ▲ or ▼ key to select one of the four size adjustments and press ENTER to select Use the ◄ or ► key to change the border of the blending area to the desired position (value between 0 and 255) R5905032 HDX SERIES 01/06/2011...
Page 222 12. Alignment Image 12-84 Width selections 4. Set ﬁrst the width for the ﬁrst projector and repeat for the second one. Image 12-85 Width set up for projector 1 R5905032 HDX SERIES 01/06/2011...
Page 223 12. Alignment Image 12-86 Width set up for projector 2 To eliminate all blending settings, select Reset and press ENTER. R5905032 HDX SERIES 01/06/2011...
Page 224: Black Level Adjustment
After the area is set, use TEXT key to remove the area border lines when adjusting the black level. How to set the leakage area width 1. Press Menu to activate the menus and select Alignment → Scenergix → Black level. Image 12-88 Main menu, alignment Image 12-89 Alignment, Scenergix R5905032 HDX SERIES 01/06/2011...
Page 225 3. Use the ▲ or ▼ key to select one of the four size adjustments. Use the ◄ or ► key to move the green border line to the desired position. Image 12-92 DLP leakage area Overlap area DLP Leakage area R5905032 HDX SERIES 01/06/2011...
Page 226 Black level, adjust 3. Adjust the black level of area A until the black level of area A, B and C are equal. Use the Adjust function Red, Green and Blue in the Black level menu. R5905032 HDX SERIES 01/06/2011...
Page 227 12. Alignment Image 2 Image 1 Image 12-97 Black level adjustment R5905032 HDX SERIES 01/06/2011...
Page 228 12. Alignment R5905032 HDX SERIES 01/06/2011...
Page 229: Projector Control
13. PROJECTOR CONTROL Overview • Projector Control menu overview • Individual Projector Address • Projector Common Address • Serial Communication • Network • IR Control switching • • Buttons • Menu position • Local LCD • Language selection R5905032 HDX SERIES 01/06/2011...
Page 230: Projector Control Menu Overview
Subnet mask IR Control IR front IR back IR side Address Universe Mode Art DMX [On/Off] Monitor Buttons Shortcut keys Standby button Menu position Menu position Bar scale position Local LCD Back light Time out Change Language R5905032 HDX SERIES 01/06/2011...
Page 231: Individual Projector Address
Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 232: Projector Common Address
1. Press Menu to activate the menus and select Projector Control → Projector Address → Common Address. Image 13-5 Main menu, projector control Image 13-6 Projector control, projector address Image 13-7 Projector address, common address 2. Press ENTER to activate the address input. Image 13-8 Projector common address R5905032 HDX SERIES 01/06/2011...
Page 233: Serial Communication
13. Projector Control 13.4 Serial Communication Overview • Baud rate setup • Interface Standard R5905032 HDX SERIES 01/06/2011...
Page 234: Baud Rate Setup
Main menu, projector control Image 13-10 Projector control, serial communication Image 13-11 Serial communication, baud rate 2. Press ENTER to toggle between the available baud rates. The following baud rates can be selected: 9600 19200 38400 57600 115200 R5905032 HDX SERIES 01/06/2011...
Page 235: Interface Standard
1. Press Menu to activate the menus and select Projector Control → Serial Communication. Image 13-12 Main menu, projector control Image 13-13 Projector control, serial communication 2. Use the ▲ or ▼ key to select Interface Standard. Press ENTER to toggle between [RS232] or [RS422]. Image 13-14 Interface standard R5905032 HDX SERIES 01/06/2011...
Page 236: Network
Wired IP address set up • Wired subnet mask set up • Wired default gateway set up • Wireless network activation • Wireless DHCP set up • Wireless IP address set up • Wireless subnet mask set up R5905032 HDX SERIES 01/06/2011...
Page 237: Introduction To A Network Connection
This must not be 0.0.0.0. If there is no router on the projector’s local subnet then just set this ﬁeld to any IP-Address on the subnet. R5905032 HDX SERIES 01/06/2011...
Page 238: Wired Dhcp Set Up
2. Use the ▲ or ▼ key to select DHCP under Wired and press ENTER to toggle between [On] or [Off]. [On] : DHCP is activated. An automatic IP address is assigned. [Off] : DHCP is deactivated. A ﬁxed address must be used. R5905032 HDX SERIES 01/06/2011...
Page 239: Wired Ip Address Set Up
Image 13-20 2. Use the ▲ or ▼ key to select IP Address under Wired and press ENTER to activate the input box. Image 13-21 3. Use the ▲ or ▼ key to change the selected character. R5905032 HDX SERIES 01/06/2011...
Page 240 Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 241: Wired Subnet Mask Set Up
Subnet mask 2. Use the ▲ or ▼ key to select Subnet Mask under Wired and press ENTER to activate the input box. Image 13-25 3. Use the ▲ or ▼ key to change the selected character. R5905032 HDX SERIES 01/06/2011...
Page 242 Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 243: Wired Default Gateway Set Up
Image 13-27 Projector control, network Image 13-28 Network, default gateway 2. Use the ▲ or ▼ key to select Default Gateway under Wired and press ENTER to activate the input box. Image 13-29 Default Gateway, input R5905032 HDX SERIES 01/06/2011...
Page 244 Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 245: Wireless Network Activation
1. Press Menu to activate the menus and select Projector Control → Network → Wireless setup. Image 13-30 Main menu, projector control Image 13-31 Projector control, network Image 13-32 Network, wireless 2. Press ENTER to select. R5905032 HDX SERIES 01/06/2011...
Page 246 13. Projector Control Image 13-33 Wireless, status 3. Press ENTER to toggle the status between [Off] and [On]. R5905032 HDX SERIES 01/06/2011...
Page 247: Wireless Dhcp Set Up
2. Use the ▲ or ▼ key to select DHCP and press ENTER to toggle between [On] or [Off]. [On] : Wireless DHCP is activated. An automatic IP address is assigned. [Off] : Wireless DHCP is deactivated. A ﬁxed address must be used. R5905032 HDX SERIES 01/06/2011...
Page 248: Wireless Ip Address Set Up
Image 13-40 Network, wireless 2. Use the ▲ or ▼ key to select IP Address and press ENTER to activate the input box. Image 13-42 3. Use the ▲ or ▼ key to change the selected character. R5905032 HDX SERIES 01/06/2011...
Page 249 Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 250: Wireless Subnet Mask Set Up
2. Use the ▲ or ▼ key to select Subnet Mask and press ENTER to activate the input box. Image 13-47 Wireless Subnet Mask, input 3. Use the ▲ or ▼ key to change the selected character. R5905032 HDX SERIES 01/06/2011...
Page 251 Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 252: Ir Control Switching
2. Use the ▲ or ▼ key to select the desired IR control and press ENTER to check checkbox. Checked : IR receiver is enabled and can receive and process commands send by the remote control. Not checked : IR receiver is disabled and not receive any command. R5905032 HDX SERIES 01/06/2011...
Page 253: Dmx
If you are using a DMX console and other automated lighting products compatible with Art-Net, the Ethernet network can serve as the link for DMX control. All DMX controls can be sent over the Ethernet cable. Multiple universes are possible. R5905032 HDX SERIES 01/06/2011...
Page 254: Dmx Address
Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 255: Dmx Universe
Use the ◄ or ► key to select another character. Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. R5905032 HDX SERIES 01/06/2011...
Page 256: Dmx Mode
1. Press Menu to activate the menus and select Projector Control → DMX → Universe. Image 13-59 Main menu, projector control Image 13-60 Projector control, DMX Image 13-61 DMX mode 2. Press ENTER to toggle between [Basic], [Extended] or [Full]. R5905032 HDX SERIES 01/06/2011...
Page 257: Art Net Dmx
1. Press Menu to activate the menus and select Projector Control → DMX → Art DMX. Image 13-62 Main menu, projector control Image 13-63 Projector control, DMX Image 13-64 DMX ArtNet activation 2. Press ENTER to toggle between [On] and [Off]. R5905032 HDX SERIES 01/06/2011...
Page 258: Monitor
1. Press Menu to activate the menus and select Projector Control → DMX → Monitor. Image 13-65 Main menu, projector control Image 13-66 Projector control, DMX Image 13-67 DMX monitor 2. Press ENTER to open the overview list. Image 13-68 DMX overview list R5905032 HDX SERIES 01/06/2011...
Page 259: Buttons
13. Projector Control 13.8 Buttons Overview • Standby button • Shortcut keys R5905032 HDX SERIES 01/06/2011...
Page 260: Standby Button
2. Press ENTER to toggle between [Lamp only] and [Lamp and Power]. Lamp only : only lamp will be switched off when Standby is pressed. Other electronics remain powered. Lamp and Power : lamp will be switched off and projector will be powered down. R5905032 HDX SERIES 01/06/2011...
Page 261: Shortcut Keys
Main menu, projector control Image 13-73 Projector control, buttons Image 13-74 Buttons, shortcut keys Image 13-75 Shortcut allocations 2. Use the ▲ or ▼ key to select the desired key and press ENTER to remove the allocation. R5905032 HDX SERIES 01/06/2011...
Page 262: Menu Position
Main menu, projector control Image 13-77 Projector control, menu position Image 13-78 Menu position 2. Use the ▲ or ▼ key to select Menu position or Barscale position and press ENTER to toggle the different possibilities. R5905032 HDX SERIES 01/06/2011...
Page 263: Local Lcd
4. Use the ▲ or ▼ key to select Time out. Image 13-82 Local LCD, time out 5. Press ENTER to toggle between [Off], [10], [30], [60] or [120]. [Off] : LCD panel remains always on. a value : LCD shut down in x seconds. R5905032 HDX SERIES 01/06/2011...
Page 264: Language Selection
Language selection 2. Use the ▲ or ▼ key to select the desired language and press ENTER to activate. The radio button before the active language is checked. The menu content is changed to the new language. R5905032 HDX SERIES 01/06/2011...
Page 265: Service
• Internal Service Patterns • Convergence • Factory defaults • USB memory • Reset Formatter • Reﬁll mode • Save Custom Settings • Special HD Camera mode • Auto Dimming when over-temperature • Time and Date R5905032 HDX SERIES 01/06/2011...
Page 266: Service Menu Overview
Convergence Blue Green on Blue Red on Blue Factory Defaults USB Memory Save custom settings Load custom settings Reset Formatter Reﬁll Mode Save Custom Settings Special HD Camera Mode Auto Dimming when Overtemperature Time and Date R5905032 HDX SERIES 01/06/2011...
Page 267: Identiﬁcation
Lamp on runtime • Remaining Lamp runtime • Customer Id How to display the overview 1. Press Menu to activate the menus and select Service → Identiﬁcation. Image 14-1 Main menu, service Image 14-2 Service, identiﬁcation R5905032 HDX SERIES 01/06/2011...
Page 268 14. Service Image 14-3 Identiﬁcation 2. Use the ▲ or ▼ key to scroll through the menu. R5905032 HDX SERIES 01/06/2011...
Page 269: Diagnosis
14.3 Diagnosis What can be seen? The diagnosis menu gives the possibility to get an overview of the working of the projector. Overview • Versions • Measurements • Logging • Board Id • Notiﬁcation • Tilt sensor R5905032 HDX SERIES 01/06/2011...
Page 270: Versions
1. Press Menu to activate the menus and select Service → Diagnosis → Versions. Image 14-4 Main menu, service Image 14-5 Service, diagnosis Image 14-6 Diagnosis, versions 2. Press ENTER to display an overview of the versions. R5905032 HDX SERIES 01/06/2011...
Page 271 14. Service Image 14-7 Diagnosis, versions list R5905032 HDX SERIES 01/06/2011...
Page 272: Measurements
2. Use the ▲ or ▼ key to select Voltages and get an overview of the voltages or to select Temperatures to get an overview of the internal temperatures or to select Fan Speeds to get an overview of current speeds of the different fans. R5905032 HDX SERIES 01/06/2011...
Page 273 14. Service Image 14-12 Overview voltages Image 14-13 Overview temperatures Image 14-14 Overview fan speeds R5905032 HDX SERIES 01/06/2011...
Page 274: Logging
2. Use the ▲ or ▼ key to select Main Controller to get a logging of the main controller or to select Lamp Power Supply to get a logging of the lamp power supply. Image 14-19 Main controller logging R5905032 HDX SERIES 01/06/2011...
Page 275 14. Service Image 14-20 Lamp power supply logging R5905032 HDX SERIES 01/06/2011...
Page 276: Board Id
1. Press Menu to activate the menus and select Service → Diagnosis → Board Id. Image 14-21 Main menu, service Image 14-22 Service, diagnosis Image 14-23 Diagnosis, board ID 2. Press ENTER to display an overview of the board IDs. Image 14-24 Overview board IDs R5905032 HDX SERIES 01/06/2011...
Page 277: Notiﬁcation
How to display 1. Press Menu to activate the menus and select Service → Diagnosis → Notiﬁcations. Image 14-25 Main menu, service Image 14-26 Service, diagnosis Image 14-27 Diagnosis, notiﬁcations 2. Press ENTER to display the notiﬁcation list. R5905032 HDX SERIES 01/06/2011...
Page 278 14. Service Image 14-28 Notiﬁcation overview list R5905032 HDX SERIES 01/06/2011...
Page 279: Tilt Sensor
1. Press Menu to activate the menus and select Service → Diagnosis → Tilt sensor. Image 14-29 Main menu, service Image 14-30 Service, diagnosis Image 14-31 Diagnosis, tilt sensor 2. Press ENTER to read out the tilt sensor. Image 14-32 Tilt sensor output R5905032 HDX SERIES 01/06/2011...
Page 280 The rotation of the projector is visually displayed. Coordinates of the tilt sensor and the offset from the normal position are given in the tilt sensor pane. The status pane indicates if the projector is used with an allowed rotation. R5905032 HDX SERIES 01/06/2011...
Page 281: Internal Service Patterns
2. Use the ▲ or ▼ key to select the desired internal service pattern and press ENTER to open a selection menu. Pmp In patterns Image 14-36 Pmp In test patterns To change the options for the selected pattern, use he ► key to open these options. The number of options can change for the different patterns. R5905032 HDX SERIES 01/06/2011...
Page 282 Internal service patterns, OSD Press ENTER to display the list of possible patterns. Image 14-39 OSD Test patterns Pmp out patterns Image 14-40 Internal service patterns, Pmp Out Press ENTER to display the list of possible patterns. R5905032 HDX SERIES 01/06/2011...
Page 283 To change the options for the selected pattern, use he ► key to open these options. The number of options can change for the different patterns. Image 14-42 Pmp out internal service test patterns options Fib patterns Image 14-43 Internal service patterns, Fib Press ENTER to display the list of possible patterns. Image 14-44 Fib test patterns R5905032 HDX SERIES 01/06/2011...
Page 284: Convergence
1. Press Menu to activate the menus and select Service → Convergence. Image 14-45 Main menu, service Image 14-46 Service, convergence Image 14-47 Convergence pattern 2. Use the ▲ or ▼ key to select a pattern. 3. Press ENTER to start the adjustment. Image 14-48 Convergence adjustment R5905032 HDX SERIES 01/06/2011...
Page 285 4. Use the convergence adjustments buttons on the light processor to adjust the convergence. Adjust until the crossing of the center Green (Red) convergence pattern coincide with the diagonal line of the center Blue con- vergence pattern. R5905032 HDX SERIES 01/06/2011...
Page 286: Factory Defaults
2. If you want to restore also one of the items in the list, check the check box in front of that item. Select Yes to restore the factory settings. Select No to stop the restore process. R5905032 HDX SERIES 01/06/2011...
Page 287: Usb Memory
2. Select Save Custom Settings and press ENTER to download this set. Note: Make sure a formatted USB stick is inserted in the USB connector. Load custom settings 1. Press Menu to activate the menus and select Service → USB Memory. R5905032 HDX SERIES 01/06/2011...
Page 288 USB memory selection 2. Select Load Custom Settings and press ENTER. An overview of the available sets of custom settings is given. Image 14-59 Custom settings ﬁles 3. Select a set and press ENTER to upload this set. R5905032 HDX SERIES 01/06/2011...
Page 289: Reset Formatter
2. Press ENTER to select. Use the ▲ or ▼ key to select Yes. or No and press ENTER. Image 14-62 Reset formatter If you want to reset the formatter, select Yes. If you do not want to reset the formatter, select No. R5905032 HDX SERIES 01/06/2011...
Page 290: Reﬁll Mode
2. Press ENTER to select. Use the ▲ or ▼ key to select Yes. or No and press ENTER. Image 14-65 If you want to start the reﬁll mode, select Yes. If you do not want to start the reﬁll mode, select No. R5905032 HDX SERIES 01/06/2011...
Page 291: Save Custom Settings
1. Press Menu to activate the menus and select Service → Save Custom Settings. Image 14-66 Main menu, service Image 14-67 Service, save custom settings 2. Use the ▲ or ▼ key to select Yes and press ENTER. Image 14-68 Save custom settings, question R5905032 HDX SERIES 01/06/2011...
Page 292: Special Hd Camera Mode
1. Press Menu to activate the menus and select Service → Special HD Camera Mode. Image 14-69 Main menu, service Image 14-70 Service, special HD camera mode 2. Press ENTER to toggle between [On] and [Off]. R5905032 HDX SERIES 01/06/2011...
Page 293: Auto Dimming When Over-Temperature
Image 14-72 Service, auto dimming when over-temperature 2. Press ENTER to toggle between [On] and [Off]. [On] : Dimming is started when an over-temperature is detected. [Off] : No dimming is started when over-temperature is detected. R5905032 HDX SERIES 01/06/2011...
Page 294: Time And Date
Note: Digits can be entered with the digit keys on the remote control or the local keypad. When a digit is entered in that way, the next character will be selected automatically. 4. Press ENTER to accept the changes. Repeat for other values in the same way. R5905032 HDX SERIES 01/06/2011...
Page 295: Maintenance
15. Maintenance 15. MAINTENANCE About this chapter This chapter contains general maintenance procedures which can be easily performed by the operator of the projector. Overview • Cleaning the lens • Cleaning the exterior of the projector R5905032 HDX SERIES 01/06/2011...
Page 296: Cleaning The Lens
Do not use fabric softener when washing the cleaning cloth or softener sheets when drying the cloth. Do not use liquid cleaners on the cloth as doing so will contaminate the cloth. Other lenses can also be cleaned safely with this Toraysee cloth. R5905032 HDX SERIES 01/06/2011...
Page 297: Cleaning The Exterior Of The Projector
1. Switch off the projector and unplug the projector from the mains power net. 2. Clean the housing of the projector with a damp cloth. Stubborn stains may be removed with a cloth lightly dampened with a mild detergent solution. R5905032 HDX SERIES 01/06/2011...
Page 298 15. Maintenance R5905032 HDX SERIES 01/06/2011...
Page 299: Servicing
Remove and clear metal front ﬁlter Extra service information Extra service information for qualiﬁed service technicians can be found on Barco’s Partnerzone (URL:http:\\my.barco.com). Regis- tration is necessary. If you are not yet registered, click on Partnerzone registration and follow the instructions. With the created login and password, it is possible to enter the partnerzone where you can ﬁnd extra service information about the projector.
Page 300: Inserting An Input Module
3. Insert the new input module in its compartment. Make sure the module seats in its sliders (2). Pull in the module until the contacts (3) are fully inserted into the connectors. 4. Fixate both ﬁxation screws. Image 16-2 Fixate input R5905032 HDX SERIES 01/06/2011...
Page 301: Removal Of The Lamp House
1. Remove the lamp cover on the input side, see "Removal of the lamp cover", page 304. 2. Release the 3 spring lock screws. Image 16-3 Lamp house, captive screws 3. Take the lamp house by both handles and pull it out. R5905032 HDX SERIES 01/06/2011...
Page 302 16. Servicing Image 16-4 Lamp house, removal R5905032 HDX SERIES 01/06/2011...
Page 303: Installation Of The Lamp House
3. Secure this position by fastening the 3 spring lock screws. 4. Reinstall the lamp cover of the projector. While starting up the projector, the electronics detect if a lamp is installed. If no lamp is installed, it is not possible to start up the projector. R5905032 HDX SERIES 01/06/2011...
Page 304: Removal Of The
7 mm ﬂat screw driver How to remove 1. Remove the lens. See "Lens removal", page 38. 2. Remove the rubber dust ring from the lens holder. Image 16-6 Dust ring removal 3. Release the 4 captive screws (1). R5905032 HDX SERIES 01/06/2011...
Page 305 16. Servicing Image 16-7 Front cover removal 4. Take off the front cover. R5905032 HDX SERIES 01/06/2011...
Page 306: Mounting The
1. Place the front cover with the rubber dust facing the projector on its place. Image 16-8 Mount front cover 2. Secure the 4 captive screws (1). 3. Reinstall the rubber dust ring around the lens holder. R5905032 HDX SERIES 01/06/2011...
Page 307 16. Servicing Image 16-9 Mount dust ring 4. Mount lens again. R5905032 HDX SERIES 01/06/2011...
Page 308: Removal Of The Lamp Cover
Switch off the projector and unplug the power cord before starting the procedure. Necessary tools 7 mm ﬂat screw driver How to remove 1. Release the 6 captive screws. Image 16-10 Lamp side cover 2. Take off the side cover. R5905032 HDX SERIES 01/06/2011...
Page 309: Mounting The Lamp Cover
Switch off the projector and unplug the power cord before starting the procedure. Necessary tools 7 mm ﬂat screw driver How to mount 1. Place the front cover on the is place and secure the 6 captive screws. Image 16-11 Lamp side cover R5905032 HDX SERIES 01/06/2011...
Page 310: Replacement Of The High Density Dust Filter
1. Remove the front cover, see "Removal of the front cover", page 300. 2. Push both ﬁlter holders to the outside. Image 16-12 Filter replacement 3. Take out the ﬁlter and insert a new one. AUTION Never clean the ﬁlter Always replace with a new one. R5905032 HDX SERIES 01/06/2011...
Page 311: Remove And Clear Metal Front Filter
If you cannot clean the ﬁlter anymore, insert a new one. How to install 1. Pull the bottom holder to the front and insert the ﬁlter. 2. Fasten the thumb screw (1). AUTION Never use the projector with removed ﬁlters ! R5905032 HDX SERIES 01/06/2011...
Page 312 16. Servicing R5905032 HDX SERIES 01/06/2011...
Page 313: Dimensions
A. Dimensions A. DIMENSIONS Overview • Dimensions of a HDX projector R5905032 HDX SERIES 01/06/2011...
Page 314: Dimensions Of A Hdx Projector
A. Dimensions A.1 Dimensions of a HDX projector Overview Center of gravity Center of gravity Image A-1 Dimensions, mm Geometrical centre Centre without lens Centre with lens 186.5 170.0 185.0 237.5 241.0 248.0 362.5 370.0 330.0 R5905032 HDX SERIES 01/06/2011...
Page 315: Speciﬁcations
B. Specifications B. SPECIFICATIONS R5905032 HDX SERIES 01/06/2011...
Page 316 B. Specifications R5905032 HDX SERIES 01/06/2011...
Page 317: Speciﬁcations Of The Hdx W14
Orientation table - ceiling - side (portrait) - vertical Picture-in-picture Up to two sources on-screen simultaneously Pixel clock 200MHz Power consumption 2,600 W STBY <8 W Projector type WUXGA three-chip DLP digital projector Resolution 1920x1200 (WUXGA) R5905032 HDX SERIES 01/06/2011...
Page 318 Shipping Dimensions (LxWxH) 900 x 650 x 560 mm (35,43" x 25,59" x 22,04") Software tools Projection Toolset Technology 0.96" DMD x3 Transport with lamp WARP Preset values + custom Warranty 2 years Weight 50kg (110lbs) R5905032 HDX SERIES 01/06/2011...
Page 319: Speciﬁcations Of The Hdx W12
Orientation table - ceiling - side (portrait) - vertical Picture-in-picture Up to two sources on-screen simultaneously Pixel clock 200MHz Power consumption 2,300 W STBY <8 W Projector type WUXGA three-chip DLP digital projector Resolution 1920x1200 (WUXGA) R5905032 HDX SERIES 01/06/2011...
Page 320 Shipping Dimensions (LxWxH) 900 x 650 x 560 mm (35,43" x 25,59" x 22,04") Software tools Projection Toolset Technology 0.96" DMD x3 Transport with lamp WARP Preset values + custom Warranty 2 years Weight 50kg (110lbs) R5905032 HDX SERIES 01/06/2011...
Page 321: Standard Source Files
C. Standard source files C. STANDARD SOURCE FILES R5905032 HDX SERIES 01/06/2011...
Page 322 C. Standard source files R5905032 HDX SERIES 01/06/2011...
Page 323: C.1 Table Overview
4. Fpix MHz: pixel frequency 5. Ptot : total pixels on one horizontal line. 6. Pact: active pixels on one horizontal line. 7. Ltot: total lines in one field 8. Lact: active lines in one field. R5905032 HDX SERIES 01/06/2011...
Page 324 74,250 2200 1920 1125 1080 hd-1920x1080@29,97p 2 9,97 33,750 74,250 2200 1920 1125 1080 hd-1920x1080_2@25i 50,000 31.25 74,250 2376 1920 hd-1920x1080@50p 50,000 56,250 148,500 2640 1920 1125 1080 hd-1920x1080@60p 60,000 67,500 148,500 2200 1920 1125 1080 R5905032 HDX SERIES 01/06/2011...
Page 325 C. Standard source files Name Fvert FHor Fpix Ptot Pact Ltot Lact VIDEO525 59,940 15,734 13,500 VIDEO525p 59,940 31,469 27,000 VIDEO625 50,000 15,625 13,500 VIDEO625p 50,000 31,250 27,000 Table C-1 R5905032 HDX SERIES 01/06/2011...
Page 326 C. Standard source files R5905032 HDX SERIES 01/06/2011...
Page 327: Dmx Chart
D. DMX chart D. DMX CHART Overview • DMX chart, Basic • DMX chart, Full • DMX chart, Extended R5905032 HDX SERIES 01/06/2011...
Page 328: Dmx Chart, Basic
Stand by / lamp Off (If held for 5 seconds) 224 - 231 XLR output voltage On (if held for 5 seconds) 232 - 239 XLR output voltage Off (if held for 5 seconds) 240 - 255 No function R5905032 HDX SERIES 01/06/2011...
Page 329: Dmx Chart, Full
Powered at 80% 125 - 149 Powered at 75% 150 - 174 Powered at 70% 175 - 199 Powered at 65% 200 - 224 Powered at 60% 225 - 255 Powered at 55% Free 0 - 255 R5905032 HDX SERIES 01/06/2011...
Page 330: Dmx Chart, Extended
Stand by / Lamp Off (if held for 5 seconds) 224 - 231 XLR output voltage On (if held for 5 seconds) 232 - 239 XLR output voltage Off (if held for 5 seconds) 240 - 255 No function 9. Only when lens is calibrated R5905032 HDX SERIES 01/06/2011...
Page 331: Stacking Hdx Projectors
E. Stacking HDX projectors E. STACKING HDX PROJECTORS Overview • Mount stacking points • Stacking HDX projectors • Aligning stacked HDX projectors R5905032 HDX SERIES 01/06/2011...
Page 332: Mount Stacking Points
Necessary tools Allen key 8 mm How to mount 1. Place the ﬁrst stacking point on a corner. Image E-1 Stacking points, mount 2. Turn in the delivered bolt. 3. Repeat for the other 3 stacking points. R5905032 HDX SERIES 01/06/2011...
Page 333: Stacking Hdx Projectors
In case of stacking projectors for a ceiling mount conﬁguration, ﬁrst turn the projectors upside down before placing the projectors on top of each other. 4. Attach the two projectors together by closing all four interlocking adapters. Image E-3 Interlocking, close R5905032 HDX SERIES 01/06/2011...
Page 334 3. Repeat this procedure for the second safety cable on the other side of the carry handle. ARNING Always use both safety cables of the lowest projector to secure a stacked projector in a ceiling mount conﬁguration. How to open an interlocking adapter 1. Open an interlocking adaptor as illustrated. R5905032 HDX SERIES 01/06/2011...
Page 335 E. Stacking HDX projectors Image E-5 Interlocking, open ARNING Never open an interlocking adapter of a stacked projector which is still suspended. First place the stacked projectors on the ﬂoor. R5905032 HDX SERIES 01/06/2011...
Page 336: Aligning Stacked Hdx Projectors
Adjust until the outline of the hatch pattern is most symmetric with the reference hatch pattern. Inclination Image E-7 Stacked projectors, inclination R5905032 HDX SERIES 01/06/2011...
Page 337 8. If necessary, repeat from step 2 until the hatch pattern of the stacked projector is perfectly aligned with the hatch pattern of the reference projector. In case of a triple stacked table mount projector conﬁguration adjust and align ﬁrst the bottommost projector (reference), than the projector in the middle and ﬁnally the uppermost projector. R5905032 HDX SERIES 01/06/2011...
Page 338 E. Stacking HDX projectors R5905032 HDX SERIES 01/06/2011...
Page 339: Environmental Information
F. Environmental information F. ENVIRONMENTAL INFORMATION R5905032 HDX SERIES 01/06/2011...
Page 340 F. Environmental information R5905032 HDX SERIES 01/06/2011...
Page 341: Disposal Information
Battery Directive 2006/66/EC, these chemical symbols will appear below the crossed-out wheeled bin symbol. By participating in separate collection of batteries, you will help to ensure proper disposal and to prevent potential negative effects on the environment and human health. R5905032 HDX SERIES 01/06/2011...
Page 342: Rohs Compliance
Printed Circuit Assemblies 插入式插件 Plug assembly 外接电(线)缆 External Cables 內部线路 Internal wiring 散热片(器) Heatsinks 光学镜头 Optical lenses 底架 Chassis 外壳 Enclosure 螺帽,螺钉(栓),螺旋( 钉),垫圈, 紧固件 Nuts, bolts, screws, washers, Fasteners 电源供应器 Power Supply Unit 风扇键盘 Keyboard R5905032 HDX SERIES 01/06/2011...
Page 343 SJ/T11363-2006. X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求. X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in SJ/T11363-2006 R5905032 HDX SERIES 01/06/2011...
Page 344 F. Environmental information R5905032 HDX SERIES 01/06/2011...
Page 345: Index
Horizontal keystone Logging Pin cushion correction Measurements Rotation Fan speeds Status Temperatures Vertical keystone Voltages Aspect ratio Notiﬁcation Auto dimming 111, 179, 289 Tilt sensor No signal Versions Over-temperature Dimensions 309–310 When on pause Projector 249–254 Art-net R5905032 HDX SERIES 01/06/2011...
Page 346 Source selection Input balance 126, 128–129 Terminology overview Adjust Getting Started Introduction RCU & local keypad White balance Input conﬁguration Input locking Input menu 93–95, 97–99, 101–102, 104, 106–110 Input locking Hang up Native resolution Projector R5905032 HDX SERIES 01/06/2011...
Page 347 Front cover Load ﬁle Lamp cover Rename Stacking points Zoom-Focus-Shift Introduction Main window 154–156, 158 Position Size Native resolution Source selection Navigation Overview Network 162–164, 166 Introduction Activation Network connection 232, 234–235, 237, 239, 241, 243–244, 246 R5905032 HDX SERIES 01/06/2011...
Page 348 DMX universe 251–252 Safety 5, 7–10, 27 Monitor Battery explosion 9, 27 IR control Cooling liquid circuit Language selection Electrical shock Local LCD Fire hazard Back light Flight cases Time out Important instructions Menu overview Personal injury R5905032 HDX SERIES 01/06/2011...
Page 349 Pin cushion correction HDX W14 Rotation Stacking 327–329, 332 Status Mount stacking points Vertical keystone Projectors 329, 332 Wired remote control Align Stacking points Mount Standard source ﬁles 317, 319 Z-axis, current light output Table overview R5905032 HDX SERIES 01/06/2011...
Page 350 Index R5905032 HDX SERIES 01/06/2011...
Page 351 Revision Sheet Barco nv Media & Entertainment Division/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11, Fax: +32 56.36.88.24 Support: www.Barco.com/esupport, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5905032/00): page wrong correct R5905032 HDX 01/06/2011 SERIES...

This manual is also suitable for:

Hdxw14 Hdxw12

Barco HDX series Installation Manual

1 Safety

2 General

3 Physical Installation

4 Input & Communication

5 Getting Started

6 Quick Set up Adjustment

7 Start up of the Adjustment Mode

8 Input

9 Image

10 Layout

11 Lamp

12 Alignment

13 Projector Control

14 Service

15 Maintenance

16 Servicing

Dimensions

Speciﬁcations

Standard Source Files

DMX Chart

Stacking HDX Projectors

Environmental Information

Index

Quick Links

Related Manuals for Barco HDX series

Summary of Contents for Barco HDX series
