Summary of Contents for Envision G917w

  • Page 2: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ------------------------------------------------ 1 SAFETY PRECAUTIONS-------------------------------------- 2 SPECIAL NOTES ON LCD MONITORS ----------------- BEFORE YOU OPERATE THE MONITOR---------------------- FEATURES ------------------------------------------------------- PACKING LIST --------------------------------------------------- 3 INSTALLATION INSTRUCTIONS --------------------------- 4 CONTROLS AND CONNECTORS ------------------------- ADJUSTING THE VIEWING ANGLE----------------------- OPERATING INSTRUCTIONS ------------------------------------- 7 GENERAL INSTRUCTIONS ---------------------------------- 7 RONT PANEL CONTROL ------------------------------------- 8...

  • Page 3: For Your Safety

    Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 4: Safety Precautions

    PRECAUTIONS  Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement.  Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance.

  • Page 5: Special Notes On Lcd Monitors

    SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. NOTES • Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears.

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS Install Remove Figure 1 Installing and Removing the Base...

  • Page 7: Controls And Connectors

    POWER CORD Power Source: 1. Make sure that the power cord is the correct type required in your area. 2. This LCD monitor has an External universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area (No user adjustment is required).

  • Page 8: Adjusting The Viewing Angle

    ADJUSTING THE VIEWING ANGLE • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. • Hold the stand so you do not topple the monitor when you change the monitor’s angle.

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. •...

  • Page 10: Ront Panel Control

    FRONT PANEL CONTROL • Power / Menu : Press the Menu (Power) button to activate the OSD window. Press left, right, up, down button to navigate through the functions. Once the desired function is highlighted, press the Menu (Power) button to activate sub-menu . •...
  • Page 11 NOTES • Do not install the monitor in a location near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, or excessive dust or mechanical vibration or shock. • Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your monitor.

  • Page 12: How To Adjust A Setting

    HOW TO ADJUST A SETTING Press the Menu (Power) button to activate the OSD window. Press left, right, up, down button to navigate through the functions. Once the desired function is highlighted, press the Menu (Power) button to activate sub- menu .

  • Page 13: Adjusting The Picture

    ADJUSTING THE PICTURE Function Control Illustration Main Main Description Menu Menu Menu Sub Menu Icon Item Icon Item 0-100 Brightness Backlight Adjustment Contrast from Digital- 0-100 Contrast register. Standard Standard Mode Text Text Mode Internet Internet Mode Eco Mode Game Game Mode Lumina Movie...
  • Page 14 Adjust the 0-100 V.Position verticalposition of the picture. Recall Warm Color Warm 6500K Temperature from EEPROM. Recall Normal Color Normal 7300K Temperature from EEPROM. Recall Cool Color Cool 9300K Temperature from Color EEPROM. Temp. Recall SRGB Color sRGB Temperature from EEPROM.
  • Page 15 Adjust the vertical V.Position 0-100 position of OSD Timeout Adjust the OSD Timeout 5-120 Adjust the transparence Transparence 0-100 of OSD Select the OSD Language language Select to Auto Detect Auto input signal Select Digital Sigal Input Select Source as Input Select Analog Sigal D-SUB Source as Input...

  • Page 16: Plug And Play

    PLUG AND PLAY PLUG & PLAY DDC2B FEATURE This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.

  • Page 17: Technical Support(Faq)

    TECHNICAL SUPPORT (FAQ) Problem & Question Possible Solution *Check if the Power Switch is in the ON Power LED is not on position *Power Cord should be connected *Check if the PC system is Plug & Play compatible *Check if the Video Card is Plug & Play No Plug &...

  • Page 18: Error Message & Possible Solution

    CLOCK (pixel frequency) controls the number of pixels scanned by one horizontal sweep. If the frequency is not correct, the screen shows vertical stripes and the picture has not correct width. FOCUS adjusts the phase of the pixel clock signal. With a wrong phase adjustment the picture has horizontal disturbances in light picture.

  • Page 19: Appendix

    APPENDIX SPECIFICATIONS Driving system TFT Color LCD Size 481 mm diagoanl LCD Panel Pixel pitch 0.2835mm(H) × 0.2835mm(V) R,G,B Analog Interface Video Digital Input Separate Sync. H/V TTL H-Frequency 30kHz – 83kHz V-Frequency 56Hz-75Hz Dot Clock 135MHz Max. Resolution 1440X900@60Hz Plug &...
  • Page 20  External Controls: Switch Eco Mode /Up  Contrast /Left  DCR/Right  Source(Auto) /Exit  Power / Menu  Functions Luminance  Image Setup  Color Temp.  Color Boost  Picture Boost  OSD Setup  Extra  Reset ...

  • Page 21: Factory Preset Timing Table

    Preset Display Modes HORIZONTAL VERTICAL STAND RESOLUTION FREQUENCY(KHz) FREQUENCY(Hz) DOS-MODE 720 × 400 31.47 70.0 640 × 480 31.47 60.0 640 × 480 37.50 75.0 800 × 600 37.879 60.0 SVGA 800 × 600 46.875 75.0 1024 × 768 48.363 60.0 1024 ×...
  • Page 22 24 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS Data 2- TMDS Data 3+/N.C. TMDS Data 2+ +5V Power TMDS Data 2/4 Shield GND(return for +5V hsync.vsync) TMDS Data 4-/N.C. Hot Plug Detect TMDS Data 4+/N.C. TMDS Data 0- DDC Clock TMDS Data 0+...
