Summary of Contents for Envision Envision Professional G22LWK
-
Page 2: Operation Instructions
Operation Instructions Thank you for purchasing this monitor, a high-resolution multi-scan color monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 3: Table Of Contents
Content Safety Precautions...1 First Setup ...2 Quick Installation...2-3 Front View of the Product ...4 Rear View of the Product ...4 Using On Screen Display (OSD) Functions ...5-7 Supporting Timing Modes ...8 Technical Information...9 Care and Maintenance...10 Troubleshooting ...10... -
Page 4: Safety Precautions
Safety Precautions This monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may result danger to the monitor as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy. -
Page 5: First Setup
First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories: Power Cable D-Sub Cable (15 pin) DVI Cable (24 pin) Audio Cable User’s Guide Quick Start Guide Warranty Documents Quick Installation Installing & Removing the Base Install Remove... -
Page 6: Connecting The Monitor
Connecting the Monitor 1. Connect Power Cable Connect the power cable to the back of the monitor. Plug the power cable to a nearby power outlet. 2. Connect Analog video cable (D-Sub cable) Make sure both monitor and computer are powered OFF. Connect the video cable ( D-Sub cable) to the computer, then to the monitor. -
Page 7: Front View Of The Product
Rear View of the Product ➐ POWER INPUT ➑ AUDIO INPUT Front View of the Product ➊ OSD TURN ON/OFF ➋ SCROLL DOWN/DECREASE ➌ SCROLL UP/INCREASE ➐ ➑ ➒ ➒ DVI INPUT (DVI 24 PIN) ➓ VGA INPUT (D-SUB 15 PIN) ➊... -
Page 8: Using On Screen Display (Osd) Functions
Using On Screen Display (OSD) Functions Display main menu. Exit from OSD menu. Auto adjust the image when not in main menu. Confirm the selection. Select the desired item when in OSD menu. When not in OSD menu, it is to immediately activate Contrast/ Brightness. -
Page 9: Osd Functions
OSD Functions Auto Image Adjust : Phase (Fine Tune) and Clock (H. Size) of the screen. Available in Analog mode only. Contrast : Adjust the foreground white level of screen image. : increase contrast, Brightness : Adjust the luminance of the video. : increase brightness, Input Select : Select Analog (D-sub) or Digital (DVI) Input... - Page 10 Fine Tune : Adjust the delay time of data and clock. Press ▼ or ▲to adjust to your preference. Sharpness : Adjust the clarity of a non-WXGA (1440x900) signal with ▼ or ▲ button. Setup Menu : Set up Language Select, Resolution Notice, OSD Position, OSD Time Out, and OSD Background.
-
Page 11: Supported Timing Modes
Supported Timing Modes VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA VESA Warning : Do not set the graphic card in your computer to exceed these maximum refresh rates. Doing so may result in permanent damage to your monitor. 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz... -
Page 12: Technical Information
Technical Information Technical Specification LCD Panel Power Management Displayable Resolution Input Signal Pixel Dimension LCD Display Color Tilt Active Display Area Temperature Compliance Power Speakers 22” Widescreen TFT EPA ENERGY STAR ® Off Mode: <1W WSXGA 1680 x 1050 max. Vertical Frequency 60Hz max. -
Page 13: Care And Maintenance
Care and Maintenance Care Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place any heavy objects on top of your monitor. Make certain your monitor is installed in a clean and moisture-free area.
