Xerox WorkCentre M24 Quick Start Manual
Retrieving scanned documents
Hide thumbs
Also See for WorkCentre M24:
- User manual (441 pages) ,
- Reference manual (332 pages) ,
- System administrator manual (228 pages)
Advertisement
Quick Links
Fig. 1-1
Press
Access.
Fig. 1-2
Enter the System Administrator Password from the Numeric Keypad
and then press Confirm. (See Machine Administrator User Guide for
default password.)
Fig. 1-3
Press
System
Settings.
Fig. 1-4
Press
System
Settings.
Fig. 1-5
Press
Network
Settings.
Fig. 1-6
Press
Port
Settings.
Retrieving Scanned Documents Using Web Browser - 1 of 4
Fig. 1-7
Press the
Arrow
button to scroll to Internet Services.
Fig. 1-8
Make sure that
11. Internet Services
is enabled then press
Note: If Internet Services is disabled press 11. Internet Services then
press Change Settings. Press Enable, press Save.
Fig. 1-9
Press
Protocol
Settings.
Close.
Advertisement
Related Manuals for Xerox WorkCentre M24
Summary of Contents for Xerox WorkCentre M24
- Page 1 Fig. 1-4 Fig. 1-7 Press System Settings. Press the Arrow button to scroll to Internet Services. Fig. 1-1 Press Access. Fig. 1-2 Fig. 1-5 Fig. 1-8 Enter the System Administrator Password from the Numeric Keypad Press Network Settings. Make sure that 11.
-
Page 2: Quick Start Guide
WorkCentre M24 business, other entity, or individual.To enter the telephone number identifying the machine and the header text information (business name) please refer to "Entering Local Terminal Information"... - Page 3 IP address of Enter the number of the mailbox in which the document was scanned. Click Save this link. WorkCentre M24 and press Enter. On the Internet Services screen Then click Document List. click Properties. Fig. 2-6 In the File Download window*, click Save.
- Page 4 WorkCentre M24 business, other entity, or individual.To enter the telephone number identifying the machine and the header text information (business name) please refer to "Entering Local Terminal Information"...
