Quadra-Fire 41I-ACC User Manual

Quadra-Fire 41I-ACC User Manual

41-i acc wood insert automatic combustion control (acc)
Hide thumbs Also See for 41I-ACC:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
41-I ACC WOOD INSERT
Automatic Combustion Control (ACC)
Model(s):
41I-ACC
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate
poisonous gases (i.e. carbon monoxide).
Installation and service of this appliance should
be performed by qualified personnel. Hearth &
Home Technologies recommends NFI certified
professionals, or technicians supervised by an
NFI certified professional.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfire - If heater or chimney con-
nector glows, you are overfiring. Overfiring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fireplace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other flammable
materials away.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafire.com
7045-910
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
NOTE
October 14, 2013

Advertisement

Table of Contents
loading

Related Manuals for Quadra-Fire 41I-ACC

Summary of Contents for Quadra-Fire 41I-ACC

  • Page 1 41-I ACC WOOD INSERT fire may result causing property Automatic Combustion Control (ACC) damage, personal injury, or death. Model(s): • Do not store or use gasoline or other flam- 41I-ACC mable vapors and liquids in the vicinity of this or any other appliance. • Do not overfire - If heater or chimney con- nector glows, you are overfiring. Overfiring will void your warranty. • Comply with all minimum clearances to combustibles as specified. Failure to...

  • Page 2: Table Of Contents

    41I-ACC Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.

  • Page 3: Important Safety Information

    41I-ACC Important Safety Information A. Insert Certification WARNING Model: 4100-I (ACC) Insert Fire Risk. Laboratory: Intertek Hearth & Home Technologies disclaims any Report No: 100428837PRT-001 responsibility for, and the warranty will be voided Type: Solid Fuel Type, Listed Room Heater by, the following actions: Standard: UL1482 and ULC S628-93 and • Installation and use of any damaged appliance. (UM) 84-HUD, Mobile Home • Modification of the appliance. Approved. • Installation other than as instructed by Hearth & Home Technologies.

  • Page 4: Getting Started

    41I-ACC Install Guide Getting Started A. Design and Installation Considerations B. Draft Draft is the pressure difference needed to vent appliances CAUTION successfully. When a appliance is drafting successfully, all combustion byproducts are exiting the home through the Check building codes prior to installation.

  • Page 5: Negative Pressure

    41I-ACC C. Negative Pressure D. Tools And Supplies Needed Negative pressure results from the imbalance of air avail- Before beginning the installation be sure the following tools able for the appliance to operate properly. It can be stron- and building supplies are available: gest in lower levels of the house.

  • Page 6: Install Checklist

    41I-ACC F. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. Customer: Date Installed: Lot/Address: Location of Fireplace: Installer: Dealer/ Distributor Phone #: Serial #: Model (circle one): 41I-ACC WARNING! Risk of Fire or Explosion! Failure to install fireplace according to these instructions can lead to a fire or explosion. IF NO, WHY? Appliance Install Verified clearances to combustibles. (Pg. 8)

  • Page 7: Dimensions And Clearances

    41I-ACC Dimensions and Clearances A. Appliance Dimensions NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) 30 in. 762 mm 24 in. 610 mm 16 1/4 in. 413mm 10 9/16 in. 269 mm Figure 7.1 Top View Figure 7.2 Front View Overall Sizes 11 1/2 in.

  • Page 8: Clearances To Combustibles

    41I-ACC B. Clearances to Combustibles, United States and Canada (UL and ULC) TOP TRIM 32-1/8 22-5/8 816mm 575mm 42-1/8 1070mm USA 18-1/8 HEARTH CANADA EXTENSION 22-1/8 (562mm) 12in max MANTEL USA 23-1/8 CANADA 25-1/8 (638mm) 44-1/8 1121mm HEARTH EXTENSION (See next page for thermal protection requirements) In Canada a full length 6 inch (152mm) S635 flue liner required as per ULC S628.

  • Page 9: Alternate Floor Protection Calculation

    41I-ACC B. Clearances to Combustibles, United States and Canada (UL and ULC) (cont.) WARNING Thermal Protection Fire Risk. • Comply with all minimum clearances to combustibles as specified. USA and CANADA • Failure to comply may cause house fire. Floor height 0” to 1-3/4” (0 to 44mm) below insert 1/2 inch (13mm) of R=2.38 base. NOTE: Clearances may only be reduced by...

  • Page 10: Locating Your Stove & Chimney

    41I-ACC D. Locating Your Stove & Chimney • Consider the appliance location in order to avoid floor and ceiling attic joists and rafters. Location of the appliance and chimney will affect perfor- mance. As shown in Figure 10.1 the chimney should: • Locate termination cap away from trees, adjacent structures, uneven roof lines and other obstructions.

  • Page 11: 2-10-3 Rule

    41I-ACC F. 2-10-3 Rule These are safety requirements and are not meant to assure proper flue draft. This appliance is made with a 6 inch (152mm) diameter chimney connector as the flue collar on the unit. • Changing the diameter of the chimney can affect draft and cause poor performance. • It is not recommended to use offsets and elbows at altitudes above 4000 feet above sea level and or when there are other factors that affect flue draft. Less than 10 ft. (305cm) 2 ft. (61cm) 3 ft. (91cm) 2 ft. (61cm) Minimum 10 ft. (305cm) To Nearest Roofline 3 ft. (91cm) Minimum Figure 11.1 PItched Roof Pitched Roof 10 ft.

  • Page 12: Chimney Systems

    41I-ACC Chimney Systems A. Venting Systems D. Masonry Chimney Chimney Connector: • Must meet minimum standards of NFPA 211. It is also known as flue pipe or stove pipe. It must be 6 inches • Must have at least 5/8 inch (16mm) fireclay lining joined (152mm) minimum diameter stainless steel connector pipe. with refractory cement. (Installations into a clay flue without a stainless steel liner may reduce draw which...
  • Page 13 41I-ACC Masonry Chimney (Cont’d) NOTE: In Canada, this fireplace insert must be installed This insert conforms with the UL 1482 and ULC S628 with a continuous chimney liner of a 6 inch (152mm) diam- (Canada) in all respects, and is approved to UL & ULC safety eter extending from the fireplace insert to the top of the standards for installation and use within a fireplace with a chimney. The chimney liner must conform to the Class 3...

  • Page 14: Metal Heat Circulating Masonry

    41I-ACC E. Metal Heat Circulating Masonry •The original factory-built clearance fireplace chimney cap must be re-installed after installing the approved chimney liner meeting type UL 103 HT requirements This insert conforms with the safety standard UL-1482 and (2100°F) per UL 1777. ULC S628 (Canada) in all respects and is approved to UL & ULC safety standards for installation and use within a fire- •If the chimney is not listed as meeting HT requirements, place with masonry chimney, in accordance with NFPA 211, or if the factory built fireplace was tested prior to 1998, a with a direct flue collar connection.

  • Page 15: Securing Chimney Components

    41I-ACC Prefabricated Metal Chimney (Cont’d) H. Altering the Fireplace The following modifications of factory-built fireplaces are Inches Millimeters permissible: Minimum Width of Cavity Opening - Front The following parts may be removed: Minimum Width of Cavity Opening - Rear Damper Smoke Shelf or Baffle Minimum Height Ember Catches Fire Grate Minimum Depth from Front to Rear 16-1/4 Viewing Screen/Curtain Doors NOTE: Refer to chimney liner manufacturer for recom- mendations on supporting the liner. Installtion into fire-...

  • Page 16: Zero-Clearance Fireplace

    41I-ACC I. Zero-Clearance Fireplace J. Ovalizing Round Stainless Steel Liners A permit may be required for installations, final approval is Ovalizing round stainless steel liners to accommodate the contingent of the authority having local jurisdiction. Consult liner passing through the damper region of a fireplace is an insurance carrier, local building, fire officials or authorities allowable and acceptable practice.

  • Page 17: Appliance Set-Up

    41I-ACC Appliance Set-Up A. Outside Air Kit Installation WARNING A source of air (oxygen) is necessary in order for combustion to take place. Whatever combustion air is consumed by the Fire Risk. fire must be replaced. Air is replaced via air leakage around Asphyxiation Risk.

  • Page 18: Securing Stove Pipe/Liner To Flue Collar

    41I-ACC B. Securing Stove Pipe/Liner to Flue Collar D. Securing Appliance to Stove Pipe/Liner 1. Once you have the appliance in place and secured, reach 1. There are 4 pre-drilled holes in the flue collar 90 degrees up through the flue opening and grab the attachment bar apart. Attach the flue collar to the stove pipe/liner. If the and pull down inside flue opening. Figure 18.3. seal is questionable use high temperature sealant such as stove mastic Figure 18.1.

  • Page 19: Surround & Trim Kit Installation

    41I-ACC E. Surround & Trim Kit Installation Secure 2 Side Surrounds to Top Surround 1. Lay surround face down on a protected surface to pre- vent scratching. 2. Using a Phillips head screw driver attach the side sur- rounds to the top surround using 2 #8 sheet metal screws provided with the kit.

  • Page 20: Blower Cord Installation On Left Side

    41I-ACC F. Blower Cord Installation on Left Side The blower cord is shipped on the right side of the appli- ance. You may relocate the cord so it is on the left side. Relocating Blower Cord to Left Side 1. Remove the convection blower housing from the appli- ance by removing two 5/32 allen head bolts.

  • Page 21: Zero Clearance Adjustable Trim Support, 2" To 10

    41I-ACC G. Zero Clearance Adjustable Trim Support, EXPLODED VIEW OF SCISSORS 2” to 10” Part No. 841-0990, size 9” x 45” and Part No. ADJSPT-12, size 12” x 50” SCREWS ARE CIRCLED Included in Kit: ( 1) Trim Top, (1) Trim Front, (2) Trim...

  • Page 22: Mobile Home Installation

    41I-ACC Mobile Home Installation An outside air inlet must be provided for combustion and Burn wood only. Other types of fuels may generate must remain clear of leaves, debris, ice and/or snow. It poisonous gases (e.g., carbon monoxide). must be unrestricted while unit is in use to prevent room...

  • Page 23: Accessory List

    41I-ACC Accessory List Leveling Legs SRV7045-184 2 pieces (Left and Right) STOCKED ITEM DESCRIPTION COMMENTS PART NUMBER at DEPOT Gold 41IDRTRIM-GD Door Trim Kit (Includes Door Trim, Spring Handle, Hinge Pins, And Logo) Nickel 41IDRTRIM-NL Black TRIMKIT-4331-BK Surround Trim Kit 43 X 31...

  • Page 24: Contact Information

    Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL...
