AVENGER 25Plus
CAPELLA 18Plus
Unflued Room Heater
Customer Operation & Installation Manual
This appliance shall be installed in accordance with:
Manufacturer's Installation Instructions
Local Gas Fitting Regulations
Municipal Building Codes
AG601/AS5601-2000 Gas Installations, AS/NZS 3000 Wiring Rules
Any other relevant Statutory Regulation
This appliance must be installed, serviced and removed by an Authorised Person
Proudly a member of the AGA
All of our gas products are AGA
tested and approved.
Advertisement
Table of Contents
Related Manuals for Rinnai AVENGER 25Plus
Summary of Contents for Rinnai AVENGER 25Plus
- Page 1 AVENGER 25Plus CAPELLA 18Plus Unflued Room Heater Customer Operation & Installation Manual This appliance shall be installed in accordance with: Manufacturer’s Installation Instructions Local Gas Fitting Regulations Municipal Building Codes AG601/AS5601-2000 Gas Installations, AS/NZS 3000 Wiring Rules Any other relevant Statutory Regulation...
-
Page 2: Rinnai Guarantee Of Quality
RINNAI GUARANTEE OF QUALITY As a purchaser of a high quality Rinnai product, we provide you with the following guarantee on your new Portable Convector Space Heater. Free Labour Period Free Parts Period FANS 5 Years 5 Years COMBUSTION CHAMBER... -
Page 3: Table Of Contents
TABLE OF CONTENTS RINNAI GUARANTEE OF QUALITY ................i ABOUT YOUR NEW AVENGER/CAPELLA Plus ............1 CONTROL PANEL LAYOUT ..................2 REMOTE CONTROL ....................3 FEATURES........................4 IMPORTANT POINTS ....................5 CUSTOMER OPERATING INSTRUCTIONS ............10 HOW TO OPERATE THE HEATER ..............11 ADJUSTING TEMPERATURES................12 HEATER MODES & FUNCTIONS..............13 SETTING HEATER MODES ................14... -
Page 4: About Your New Avenger/Capella Plus
ABOUT YOUR NEW AVENGER/CAPELLA Plus STANDBY/ON BUTTON Rinnai Australia RCE-470/670 TRE... -
Page 5: Control Panel Layout
CONTROL PANEL LAYOUT Rinnai Australia RCE-470/670 TRE... -
Page 6: Remote Control
REMOTE CONTROL STANDBY BUTTON Timer mode. STANDBY button will cancel any future timer operations, these will have to be reset manually. Rinnai Australia RCE-470/670 TRE... -
Page 7: Features
Timer program. ECONOMY AUTO-OFF The Economy / Auto-Off functions are energy saving FUNCTION feature designed to control the room temperature and are automatically selected in all modes. Rinnai Australia RCE-470/670 TRE... -
Page 8: Important Points
If the supply cord or gas hose are damaged or require replacing, they must be replaced by the manufacturer or the manufacturer's agent or similarly qualified person in order to avoid a hazard. The appliance weighs 21 kg. Exercise caution when lifting or moving. Rinnai Australia RCE-470/670 TRE... - Page 9 Young children should be supervised to ensure they DO NOT play with the appliance. Do not allow children or elderly persons to sleep in the warm air discharge from the heater. Do not cover or place articles on this heater. Rinnai Australia RCE-470/670 TRE...
- Page 10 Use of aerosols, paint, polishes etc. whilst this heater is in use may also cause unpleasant smells. Do not sit on this heater. Rinnai Australia RCE-470/670 TRE...
- Page 11 ON/ OFF times will remain in the memory. Do not place containers of liquid on top of the heater. Water spillage can cause extensive damage to the appliance and create an electrocution hazard. Rinnai Australia RCE-470/670 TRE...
- Page 12 When the heater is operated for the first time or after long periods of non use a slight odour may be emitted, this is normal. However if odours persist switch of the appliance and contact Rinnai. Rinnai Australia RCE-470/670 TRE...
-
Page 13: Customer Operating Instructions
Check room size and ventilation This heater must not be installed in a room smaller than: The AVENGER 25Plus must not be in a room smaller than 62.5 m The CAPELLA 18Plus must not be in a room smaller than 45.0 m... -
Page 14: How To Operate The Heater
''STANDBY/ON'' button once. ''STANDBY/ON'' button twice to restart. heaters ''STANDBY/ON'' button The ''STANDBY'' and ''ON'' buttons located on the remote control can also be used to operate the appliance. Remote control STANDBY and ON Buttons Rinnai Australia RCE-470/670 TRE... -
Page 15: Adjusting Temperatures
ADJUSTING TEMPERATURES STANDBY/ON ''STANDBY/ON'' button STANDBY/ON Button ''STANDBY/ON'' STANDBY/ON button once. STANDBY/ON STANDBY/ON Rinnai Australia RCE-470/670 TRE... -
Page 16: Heater Modes & Functions
“SET” temperature. Note: Electric convection will only operate when the “SET” temperate is at least 2°C higher than the “CURR” temperature. Timer operation is disabled when the appliance is in the “ELECTRIC” only mode. Rinnai Australia RCE-470/670 TRE... -
Page 17: Setting Heater Modes
SETTING HEATER MODES Rinnai Australia RCE-470/670 TRE... -
Page 18: Setting Clock
S TA N D B Y / O N S TA N D B Y / O N S TA N D B Y / O N S TA N D B Y / O N ''STANDBY/ON'' Button STANDBY Rinnai Australia RCE-470/670 TRE... -
Page 19: Programming The On/Off Timers
Here we will learn how to set the Timer (s) function by following the steps below. STANDBY/ON Button With the heater in the STANDBY condition press STANDBY/ON the ''SET'' button until ''PROGRAM'' is shown in the control panel display and the hour digits are flashing. STANDBY/ON STANDBY/ON STANDBY/ON STANDBY/ON STANDBY/ON STANDBY/ON Rinnai Australia RCE-470/670 TRE... -
Page 20: Operating The On/Off Timers
The temperature differential at the time of sensing the room temperature combined with the data from previous operation governs exactly how long before the programmed ON time the micro-computer will operate the heater and ignite the burner. Rinnai Australia RCE-470/670 TRE... -
Page 21: Override Function
S TA N DB Y /O N STANDBY S TA N DB Y /O N the ''STANDBY'' button once will return the heater to STANDBY. S TA N DB Y /O N return the heater to STANDBY, then the Rinnai Australia RCE-470/670 TRE... -
Page 22: Child Lock
The tilt switch may also operate if the heater is jolted or picked up whilst in operation. POWER FAILURE In the event of a power failure or power cut, the gas valves will automatically close. After the power is re-instated the appliance must be operated manually. Rinnai Australia RCE-470/670 TRE... -
Page 23: Care Of Heater
Replace filters by carefully repositioning the location tabs and fasten in place with the retaining screw . Filter 3 (the small filter) should be left in position for cleaning, carefully use a vacuum cleaner to remove any contaminates such as dust and lint. Rinnai Australia RCE-470/670 TRE... -
Page 24: Fault Finding
Any service or repair work should only be carried out by an authorized person. Rinnai Australia has service and spare parts departments. Fault Finding Procedure If you are unsure about the way your heater is operating, contact Rinnai Australia, or your local agent. Rinnai Australia RCE-470/670 TRE... -
Page 25: Error Codes
3 to 4 more times, however if the heater ignition continues to be unsuccessful arrange a service call. Rinnai Australia RCE-470/670 TRE... -
Page 26: Specifications
SPECIFICATIONS DIMENSIONS Dimensions in mm Rinnai Australia RCE-470/670 TRE... -
Page 27: Wiring Diagram
CONTROL TIMER CONTROL DISPLAY CIRCUIT CIRCUIT CIRCUIT F [ 3A ] POWER SUPPLY TRANSFORMER CIRCUIT FLAME FAILURE IGNITION MODULATION SOLENOID CIRCUIT CIRCUIT VALVE CIRCUIT VALVE CIRCUIT CONVECTION HEATER FAN CIRCUIT FAN CIRCUIT ODS1 ODS2 MAIN BURNER Rinnai Australia RCE-470/670 TRE... -
Page 28: Customer Contacts
CUSTOMER CONTACTS Australia Pty. Ltd. Internet: www.rinnai.com.au E-mail: enquiry@rinnai.com.au ABN 74 005 138 769 Head Office National Help Line 10-11 Walker Street, Braeside,Victoria 3195 Tel: 1300 555 545* P.O. Box 460 Fax: 1300 555 655* Internet: www.rinnai.com.au Tel: (03) 9271 6625 *Cost of a local call Higher from mobile or public phones.
