Introduction
Preliminary knowledge
Getting started
Basic operations
Advanced operations
Initial settings
Additional information
/(7$
2
5
13
20
24
39
46
>%@

Advertisement

Table of Contents
loading

Related Manuals for JVC XV-M50BK

Summary of Contents for JVC XV-M50BK

  • Page 1 '9' 9,'(2 3/$<(5 ;90%.;906/ STANDBY/ON DISC SELECT PLAY TV/VIDEO MODE PHONIC CANCEL RETURN TV -/-- MUTING THEATER ANGLE SUBTITLE AUDIO POSITION DIGEST ZOOM STAND/BY PLAY & EXCHANGE SELECT DVD / VIDEO CD / CD STANDBY/ON 10-bit/27MHz VIDEO D/A CONVERTER ENTER ∞...
  • Page 2 öppnad och spärren är af funktion. Undgå udsæt- AVOID DIRECT EXPOSURE urkopplad. Betrakta ej telse for stråling TO BEAM. strålen. Front XV-M50BK/ XV-M52SL Stand height 5 cm or more Floor VARO: Avattaessa ja suo- jalukitus ohitettaessa olet alttiina näkymättömälle lasersäteilylle.

  • Page 3: Table Of Contents

    Table of Contents Introduction Features...2 Supplied accessories...2 About this instruction manual ...3 Notes on handling ...4 Preliminary knowledge Names of parts and controls ...5 Front panel...5 Remote control unit ...6 Display window...8 Rear panel...8 Operational Principles...9 On-screen displays...9 To prevent the monitor from burning out [SCREEN SAVER] ...10 On-screen guide icons ...11 How to use numeric buttons...11...

  • Page 4: Introduction

    Introduction Features Picture functions 7 7 7 7 Strobe function The unit can display nine continuous still pictures on the TV screen. 7 7 7 7 Digest function You can select the desired selection to be played from the opening scenes displayed on the TV screen. 7 7 7 7 Angle function* You can select a desired angle from multiple camera angles recorded on the DVD VIDEO disc.

  • Page 5: About This Instruction Manual

    About this instruction manual This instruction manual basically explains operations as follows: To playback in random order [RANDOM] You can play titles or tracks on discs inserted in random order by using the Random function. 7 While stopped The number indicates the procedural step.

  • Page 6: Notes On Handling

    Introduction Notes on handling Important cautions Installation of the unit • Select a place which is level, dry and neither too hot nor too cold (between 5 C and 35 • Leave sufficient distance between the unit and the TV. •...

  • Page 7: Preliminary Knowledge

    Preliminary knowledge Names of parts and controls Refer to the corresponding pages indicated in () for details. Front panel 1 STANDBY indicator 2 STANDBY/ON STANDBY PLAY & EXCHANGE STANDBY/ON DVD / VIDEO CD / CD 10-bit/27MHz VIDEO D/A CONVERTER DOLBY D I G I T A L 1 STANDBY indicator Lights when the power cord is connected and the unit...

  • Page 8: Remote Control Unit

    Preliminary knowledge Remote control unit 1 DISC SELECT button 2 PLAY MODE button 3 3D PHONIC button 4 Numeric buttons 5 ANGLE button 6 SUBTITLE button 7 DIGEST button 8 4/PREVIOUS button 9 7/CLEAR button 0 1/SLOW– button - TITLE button = CURSOR (5 UP, ∞...
  • Page 9 1 DISC SELECT button (21) By pressing this button followed by the appropriate numeric button (among 1 through 3),you can select a disc to be played. 2 PLAY MODE button (26, 30, 31, 32) Displays an on-screen display for controlling the advanced playback functions.

  • Page 10: Display Window

    Preliminary knowledge Display window 4 Disc indicators 3D-PHONIC PROGRAM RANDOM RESUME DISC TITLE CHAP. TRACK DVD VCD EACH REMAIN 2 Title/chapter/ track indicators 1 Disc number indicator Rear panel 1 VIDEO OUT - VIDEO jack 2 VIDEO OUT - S-VIDEO jack VIDEO OUT AV OUT VIDEO...

  • Page 11: Operational Principles

    Operational Principles On-screen displays The unit provides several on-screen displays. With some displays, you can set or select preferences or functions, while the others are display-only. Opening displays The Opening display appears automatically in some conditions. At the bottom, the following information are indicated depending on the unit’s status.

  • Page 12: To Prevent The Monitor From Burning Out [Screen Saver]

    Preliminary knowledge Play mode displays Pressing the PLAY MODE button brings up the play mode display in which you can control playback functions. Different displays appear depending on the disc type and the unit’s status. Status displays Pressing the DISPLAY button during playback brings up the status display.

  • Page 13: On-Screen Guide Icons

    On-screen guide icons During DVD VIDEO playback, you may see icons displayed over the picture. These have the following meanings. : Displayed at the beginning of a scene recorded from multiple angles. (See page 33.) : Displayed at the beginning of a scene recorded with multiple audio languages. (See page 35.) : Displayed at the beginning of a scene recorded with multiple subtitle languages.

  • Page 14: About Discs

    Preliminary knowledge About discs Playable disc types Playable and non-playable disc types are as follows: Playable discs DVD VIDEO DVD VIDEO The DVD VIDEO Logo is a trademark. • CD-R and CD-RW discs recorded with the Audio CD format can be played back, though some may not be played back because of the disc characteristics or recording condition.

  • Page 15: Getting Started

    Getting started Connections *In the following description, “TV” may be substituted with “monitor” or “projector.” *Before using the unit, you have to connect the unit to a TV and/or amplifier. Before making any connections • Do not connect the AC power cord until all other connections have been made. •...

  • Page 16: To Connect To A Tv With The Scart Connector

    Getting started To connect to a TV with the SCART connector You can enjoy using the unit by simply connecting it to your television set with a 21-pin SCART cable. To hear audio sound with better quality, connect the audio output to your audio equipment. The unit VIDEO OUT AV OUT...

  • Page 17: To Connect To An Audio Amplifier Or Receiver

    Keep holding down the 7 (STOP) button on the front panel. After a few more seconds, “R OUT” replaces “S OUT” in the display window. Now the RGB signal can be output when setting the COMP . - Y/C switch to “COMP.” . (Display window) 3D-PHONIC PROGRAM...

  • Page 18: To Connect To Audio Equipment With A Digital Input

    Getting started To connect to audio equipment with a digital input You can enhance the sound quality by connecting either of the unit's DIGITAL OUT jacks (OPTICAL or COAXIAL) to the digital input of an amplifier, MD, etc. by using an optional digital cable. The digital audio signal from a disc is directly transferred.

  • Page 19: Using The Remote Control Unit

    Using the remote control unit Using the remote control, you can operate not only all the functions of the unit but also basic functions of your TV. To install batteries in the remote control unit The battery compartment is located on the back of the remote control unit. Press down on the point shown by the arrow at the top of the compartment cover, and pull up the cover to open the compartment.

  • Page 20: To Use The Remote Control Unit For Tv Operation

    DIGEST ZOOM SELECT ENTER ∞ RM-SXVM50J REMOTE CONTROL No. Manufacturer GRADIENTE SANYO PHILCO/DAEWOO LG (GOLDSTAR) GRUNDIG NEC/GRADIENTE PHILCO BEIJING/NOBLEX JVC (ONWA) JVC (ONWA) JVC (ONWA) THOMSON FERGUSON No. Manufacturer MIVAR FINLUX NOKIA FUNAI SAMSUNG SAMSUNG/PEONY/CHANGHONG SAMSUNG AIWA DAEWOO JINXING/PEONY PEONY...
  • Page 21 ∞ NOTES • The remote control unit is initially set operating a JVC TV. • If there is more than one code listed for the manufacturer of your TV, try them one by one until you succeed. Turns the TV on or off.

  • Page 22: Basic Operations

    Basic operations In the following description, the buttons on the remote control unit are mainly used, however, you may use the corresponding buttons on the front panel of the unit if available. Turning on/off the unit Press DVD STANDBY/ON on the remote control unit or press STANDBY/ON DISC SELECT...

  • Page 23: Basic Playback

    Basic playback Now you can play a disc. First, let’s enjoy simple playback according to following procedure. To start playback Method 1 Press on the front panel or remote control unit. The unit starts playback from the selected disc indicated in the display window Method 2 Press any of the DISC (1 through 3) buttons on the front panel.

  • Page 24: To Advance Or Reverse Playback Rapidly While Monitoring

    Basic operations To advance or reverse playback rapidly while monitoring 7 During playback From the Remote control unit Press 1 or ¡. Each press of 1 or ¡ increases the playback speed. You can select the speed among 2x, 5x, 10x, 20x and 60x the normal speed.

  • Page 25: To Resume Playback

    To resume playback 7 While the disc you interrupt playback last time is still in the disc tray. Press 3. The unit starts playback from the position where you interrupted playback last time. • To clear the resume position memory Carry out one of the followings.

  • Page 26: Advanced Operations

    Advanced operations When you use the functions described below while stopped, make sure that the desired disc number is selected (the selected disc number is shown in the display window). If it is not selected, press the appropriate DISC (1 - 3) button to start playback and then press 7. When controlling the unit using the CURSOR, TV/VIDEO - CANCEL or numeric buttons, make sure that the...

  • Page 27: To Locate A Desired Selection Using The Numeric Buttons

    Use the numeric buttons to select the desired number of the item. • See page 11 for details about how to use the numeric buttons. The unit starts playback of the selected item. You can return to the menu by pressing the RETURN button.

  • Page 28: To Locate A Desired Scene By Specifying The Chapter Number [Chap.search]

    Advanced operations To locate a desired scene by specifying the chapter number [CHAP.SEARCH] If the current title of a DVD VIDEO disc being played is divided into chapters, you can skip to a desired chapter by specifying the chapter number using the on-screen display.

  • Page 29: To Locate A Desired Scene From The Display [Digest]

    Use the numeric buttons (0 to 9) to enter the time. You can specify the elapsed time of the current title or track to set the location which you want to playback from. Press ENTER. The unit starts playback from the specified time. (for DVD VIDEO) (for Audio CD) DVD CONTROL...

  • Page 30: Special Picture Playback

    Advanced operations Use CURSOR 5/∞/2/3 to select the desired scene. The selected scene is indicated by If there are more than 9 scenes, the digest screen will have more than one page. In this case, pressing ¢ advances to the next page, while pressing 4 returns to the previous page.

  • Page 31: To Playback In Slow-Motion [Slow]

    • Pressing 8 when the nine still pictures is shown will advance to the next nine still pictures. • Pressing 3 when the nine still pictures is shown will advance pictures in normal playback speed. • To cancel strobe play Press and hold 8 for more than 1 second.

  • Page 32: Changing The Playback Order

    Advanced operations Changing the playback order You can play titles or tracks on discs inserted in the desired order or in random order. To playback in the desired order [PROGRAM] You can play titles or tracks on discs inserted in the desired order by using the Program function.

  • Page 33: To Playback In Random Order [Random]

    To playback in random order [RANDOM] You can play titles or tracks on discs inserted in random order by using the Random function. STANDBY/ON DISC SELECT PLAY TV/VIDEO MODE PHONIC CANCEL RETURN TV -/-- MUTING THEATER ANGLE SUBTITLE AUDIO POSITION DIGEST ZOOM SELECT...

  • Page 34: To Repeat A Desired Part [A-B Repeat]

    Advanced operations • During Audio CD/Video CD playback (for Audio CD) (for Video CD) CD CONTROL REPEAT A-B REPEAT TIME SEARCH PBC CALL REPEAT A-B REPEAT TIME SEARCH REPEAT ALL REPEAT ALL Selected repeat mode Selected repeat mode REPEAT ALL (all track repeat) REPEAT 1 (current track repeat) No indication (off)

  • Page 35: Selecting A Scene Angle Of Dvd Video

    • To quit A-B repeat playback Press 7 . The unit stops playback and quits A-B repeat mode. • During playback, pressing ENTER when B REPEAT] quits A-B repeat mode and continues playback. • You can also quit A-B repeat mode by pressing 4 or ¢. NOTES •...

  • Page 36: To Select A Scene Angle From The Angle List Display [Angle]

    Advanced operations To select a scene angle from the angle list display [ANGLE] STANDBY/ON DISC SELECT PLAY TV/VIDEO MODE PHONIC CANCEL RETURN TV -/-- MUTING THEATER POSITION ANGLE SUBTITLE AUDIO DIGEST ZOOM SELECT ENTER ∞ RM-SXVM50J REMOTE CONTROL 7 During DVD VIDEO playback Press and hold ANGLE for more than 1 second.

  • Page 37: To Change The Audio Language Or Sound [Audio]

    NOTES • For DVD VIDEO, the selected language may be abbreviated on the TV screen. See “Appendix A: Table of languages and their abbreviations” at the end of this manual. • The Subtitle selection display will automatically disappear if you do not change the subtitle for 10 seconds.

  • Page 38: Selecting The Picture Character

    Advanced operations Selecting the picture character You can select the picture character from among four options according to the source program, lighting condition of the room and/or personal preference. To select the picture character [THEATER POSITION] STANDBY/ON DISC SELECT PLAY TV/VIDEO MODE PHONIC...

  • Page 39: Checking The Status

    • THEATER You can enjoy sound effects like in a major theater in Hollywood. When you play a DVD VIDEO disc recorded in Dolby Digital which contains more than 3 channels, ACTION does not appear. NOTES • The 3D Phonic display will automatically disappear if you do not change the 3D PHONIC for 5 seconds.

  • Page 40: To Check The Dvd Function Status

    Advanced operations To check the DVD function status STANDBY/ON DISC SELECT PLAY TV/VIDEO MODE PHONIC CANCEL RETURN TV -/-- MUTING THEATER ANGLE SUBTITLE AUDIO POSITION DIGEST ZOOM SELECT ENTER ∞ RM-SXVM50J REMOTE CONTROL 7 During DVD VIDEO playback Press DISPLAY. The DVD function status display appears on the TV screen.

  • Page 41: Initial Settings

    Initial settings Selecting preferences You can set various preferences for playback via four dedicated displays. How to set preferences Note that you cannot bring up a preference display during playback or when an Audio CD is loaded in the tray. STANDBY/ON DISC SELECT...

  • Page 42: Audio Page

    Initial settings SUBTITLE You can select the default subtitle language to be displayed if it is contained on the disc. Each time you press CURSOR 3, the language setting changes in the following order: ENGLISH → → → → SPANISH → → → → FRENCH → → → → CHINESE → → → → GERMAN →...

  • Page 43: Display Page

    DOWN MIX To playback a DVD VIDEO LANGUAGE disc recorded with surround DIGITAL AUDIO OUTPUT multichannel audio DOWN MIX COMPRESSION correctly, the DOWN MIX setting must be properly made according to your PRESS audio system. Note that this setting affects the output signal from the AUDIO (both DIGITAL and ANALOG) output jacks when playing back a DVD VIDEO disc recorded with surround multichannel audio.

  • Page 44: System Page

    Initial settings ON SCREEN GUIDE The unit can display “on- screen guide” icons or characters on the picture, which show what is happening to the disc or the unit. • ON The on-screen guide will be displayed. • OFF The on-screen guide will not be displayed. Examples of “on-screen guide”...

  • Page 45: Limiting Playback By Children

    Limiting playback by children This function restricts playback of DVD VIDEO discs which contain violent (and other) scenes according to the level set by the user. For example, if a movie which includes violent scenes supports the parental lock feature, such scenes which you do not want to let children view can be cut or replaced with other scenes.

  • Page 46: To Change The Settings [Parental Lock]

    Initial settings To change the settings [PARENTAL LOCK] You can change the Parental lock settings later. STANDBY/ON DISC SELECT PLAY TV/VIDEO MODE PHONIC CANCEL RETURN TV -/-- MUTING THEATER POSITION ANGLE SUBTITLE AUDIO DIGEST ZOOM SELECT ENTER ∞ RM-SXVM50J REMOTE CONTROL 7 While a DVD VIDEO disc is stopped or no disc is inserted Press ENTER while holding down 7 on the remote control unit.

  • Page 47: To Temporarily Release The Parental Lock [Parental Lock]

    To temporarily release the Parental lock [PARENTAL LOCK] When you set the parental level strictly, some discs may not be played back at all. When you insert such a disc and try to play it, the following Parental Lock on-screen display appears on the TV screen, asking you whether you want the parental lock to be temporarily released or not.

  • Page 48: Additional Information

    Additional information Care and handling of discs How to handle discs When handling a disc, do not touch the surface of the disc. Since discs are made of plastic, they are easily damaged. If a disc gets dirty, dusty, scratched or warped, the images and sound will not be picked up correctly, and such a disc may cause the player to malfunction.

  • Page 49: Troubleshooting

    Troubleshooting What appears to be a malfunction may not always be serious. Please go through the following list before requesting service. Symptom Power does not come on. Remote control does not work. No picture is displayed on the monitor. Picture is not normal when using the S-VIDEO jack.

  • Page 50: Specifications

    Additional information Specifications General Readable discs: DVD VIDEO, Audio CD, Video CD Video format: Other Power requirements: AC 230 V Power consumption: 17 W (POWER ON), 3.1 W (STANDBY mode) Mass: 4.8 kg (10.6 lbs) Dimensions (W x H x D): 435 mm x 127 mm x 329 mm (17-3/16 inch x 5 inch x 13 inch) Video outputs...

  • Page 51: Country Code List For Parental Lock

    Appendix B:Country code list for parental lock This list is used for the parental Lock operation. For details, see page 43. Andorra United Arab Emirates Afghanistan Antigua and Barbuda Anguilla Albania AM Armenia Netherlands Antilles Angola Antarctica Argentina American Samoa Austria Australia AW Aruba...
  • Page 52 “SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT” This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.
