5-4 AUTOMATICALLY ADJUSTMENTS

• The following adjustments must be performed at "ADJUSTMENT MODE".
• The following adjustments can be ajusted automatically.
• In case of be finished to adjust "BAR ANTENNA", "VHF SENSITIVITY" and "UHF SENSITIVITY" ADJUSTMENTS already,
DO NOT need to perform the following adjustment.
ADJUSTMENT
BAR 1 • Displayed frequency
ANTENNA • Connect the SSG to the antenna connector and set as :
• Receiving
2 • Displayed frequency
• Set the SSG level
• Receiving
VHF 1 • Displayed frequency
SENSITIVITY • Set the SSG level
• Receiving
2 • Displayed frequency
• Receiving
UHF 1 • Displayed frequency
SENSITIVITY • Set the SSG level
• Receiving
2 • Displayed frequency
• Receiving
*This output level of the standard signal generator (SSG) is indicated as SSG's open circuit.
ADJUSTMENT CONDITION
: (trL ch) 0.495 MHz
Level : 40 mV (–15 dBm)
*
Modulation : OFF
: (trH ch) 1.620 MHz
: 50 mV (–13 dBm)
*
: (trL ch) 118.100 MHz
: 1.0 µV (–107 dBm)
*
: (trH ch) 174.900 MHz
: (trL ch) 330.100 MHz
: 1.0 µV (–107 dBm)
*
: (trH ch) 469.900 MHz
Push the [V/M] key.
Push the [V/M] key.
Push the [V/M] key.
Push the [V/M] key.
Push the [V/M] key.
Push the [V/M] key.
5 - 8
OPERATION
