Icom IC-R5 Service Manual page 20

ADJUSTMENT MODE ADJUSTMENTS (Continued)
• The following adjustments must be performed at "ADJUSTMENT MODE".
ADJUSTMENT
1 • Displayed frequency
S-METER
• Connect the SSG to the antenna connector and set as :
• Mode
• Receiving
2 • Set the SSG as :Level : 1.6 µV
• Mode
• Receiving
3 • Displayed frequency
• Set the SSG level
• Mode
• Receiving
4 • Set the SSG level
• Mode
• Receiving
5 • Displayed frequency
• Set the SSG level
• Mode
• Receiving
6 • Set the SSG level
• Mode
• Receiving
7 • Displayed frequency
• Set the SSG level
• Mode
• Receiving
8 • Set the SSG level
• Mode
• Receiving
9 • Displayed frequency
• Set the SSG Level
• Receiving
10 • Set the SSG level
• Mode
• Receiving
11 • Displayed frequency
• Set the SSG level
• Receiving
12 • Set the SSG level
• Mode
• Receiving
*This output level of the standard signal generator (SSG) is indicated as SSG's open circuit.
ADJUSTMENT CONDITION
: (SM ch) 14.100 MHz
Level : 0.5 µV (–113 dBm)
*
Modulation : OFF
: FM
(–103 dBm)
*
: WFM
: (SM ch) 145.100 MHz
: 0.5 µV (–113 dBm)
*
: FM
: 1.6 µV (–103 dBm)
*
: WFM
: (SM ch) 200.100 MHz
: 0.5 µV (–113 dBm)
*
: FM
: 1.6 µV (–103 dBm)
*
: WFM
: (SM ch) 435.100 MHz
: 0.5 µV (–113 dBm)
*
: FM
: 1.6 µV (–103 dBm)
*
: WFM
: (SM ch) 650.100 MHz
: 0.5 µV (–113 dBm)
*
: 1.6 µV (–103 dBm)
*
: WFM
: (SM ch) 1100.100 MHz
: 1 µV (–107 dBµ)
*
: 3.2 µV (–97 dBm)
*
: WFM
Push and hold the [MOD] key.
• Verify that S-Meter shows S4 (3dots).
5 - 7
OPERATION
