- Page 1 LS 3X80-I233A Special Operating Instructions (70-13424-233) Revision B: August 1995 Special Operating Instructions ®...
- Page 2 LS 3X80-I233A Special Operating Instructions (70-13424-233) Revision B: August 1995 LS 3X80-I233A The LS 3X80-I233A differs from the standard in that it contains custom default parameters as follows: Parameter Custom Default Keyboard Type IBM AT Compatible Convert UPC-E to Enabled...
- Page 3 LS 3X80-I233A Special Operating Instructions (70-13424-233) Revision B: August 1995 Interconnection Diagram – IBM-3151 IBM-3151 Terminal LS 3X80 Scanner To Keyboard Connector on IBM-3131 Terminal Cable Assy (25-04464-02) Junction Box Twist Lock (20-04436-05) Connector to Scanner Terminal To Keyboard Power Keyboard...
-
Page 4: Keyboard Type
LS 3X80-I233A Special Operating Instructions (70-13424-233) Revision B: August 1995 Keyboard Selection – IBM-3151 To select the IBM-3151 terminal keyboard, scan the KEYBOARD TYPE bar code below, followed by the two numeric bar codes (1, then 7), followed by the ENTER bar code. - Page 5 LS 3X80-I233A Special Operating Instructions (70-13424-233) Revision B: August 1995 Interconnection Diagram – Memorex/Telex Memorex/Telex Terminal LS 3X80 Scanner To Keyboard Connector on Memorex/Telex Terminal Twist Lock Connector to Scanner Memorex/Telex Keyboard To Keyboard Connector on “Y” Cable Assy Memorex/Telex...
- Page 6 LS 3X80-I233A Special Operating Instructions (70-13424-233) Revision B: August 1995 Keyboard Selection – Memorex/Telex To select the Memorex/Telex terminal key- board, scan the KEYBOARD TYPE bar code below, followed by the two numeric bar codes (0, 2), followed by the ENTER bar code.
