3M ELECTRIC RANDOM ORBITAL SANDER Instruction Manual

3
ELECTRIC RANDOM ORBITAL SANDER INSTRUCTION MANUAL
127 mm (5 in) and 152 mm (6 in)
7,000/min – 10,000/min (RPM)
POWER SUPPLY Altertnating Current (AC) INPUT: 100 – 240 Va.c. 47-63 Hz.
POWER SUPPLY Direct Current (DC) OUTPUT: 30 Vd.c. 5 A
Important Safety Information
Please read, understand and follow all safety information contained in these instructions prior to the use of this tool. Retain these instructions for future reference.
This electric tool is intended for use in industrial locations, and used only by skilled, trained professionals in accordance with the instructions in this manual. This
electric tool is designed to be used with a disc pad and appropriate abrasive for sanding metals, wood, stone, plastics and other materials. It should only be used
for such sanding applications and within marked capacity and ratings. Only accessories specifi cally recommended by 3M should be used with this tool. Use in any
other manner or with other accessories could lead to unsafe operating conditions.
Do not operate tool in water or in an excessively wet application.
Do not use disc pads that have a Max RPM or Max OPM less than the tool Max RPM or Max OPM rating. Never use disc pads that have a weight and/or size
different from what the tool was specifi cally designed for.
Explanation of Signal Word Consequences
W
WARNING: Indicates a potentially hazardous situation which, if not avoided, may result in death or serious
injury and/or property damage.
W
Indicates a potentially hazardous situation which, if not avoided, may result in minor or
CAUTION:
moderate injury and/or property damage.
Summary of Device and Carton Labels containing Safety Information
CAUTION:
For safe operation, see instructions manual
Recycle: Do not dispose in household waste
Wear eye protection
Wear respiratory protection
Wear hearing protection
Read operator instructions before using
American Wire Gauge
United Coarse Thread
Underwriters Laboratories, Inc. United States and Canada Approved Mark
Technischer Überwachungsverein Rheinland United States and Canada Approved Mark
Intended Use
1
Read the
Material Data Sheets (MSDS)
Before using any materials
MSDS
Contact the suppliers of the workpiece materials
and abrasive materials for copies of the MSDS if
one is not readily available.
W
WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fi re, and/or other
serious injury.
Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work Area Safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of fl ammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
2) Electrical Safety
a) Power tools plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodifi ed plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a ground fault circuit interrupter (GFCI) protected supply. Use of a GFCI reduces
the risk of electric shock.
3) Personal Safety,
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under
the infl uence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your fi nger on the switch or energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
4) Power Tool Use and Care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source and/or the battery pack form the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power
tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits, etc. in accordance with these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
5) Service
Have your power tool serviced by a qualifi ed repair person using only identical replacement parts. This will ensure that the safety of the power tool
is maintained.
Original Instructions
W WARNING
Exposure to DUST generated from workpiece
and/or abrasive materials can result in lung
damage and/or other physical injury.
Use dust capture or local exhaust as stated
in the MSDS. Wear government-approved
respiratory Protection and eye and skin
protection. Failure to follow this warning
can result in serious lung damage and/or
physical injury.
W GENERAL POWER TOOL SAFETY WARNINGS
2
