Page 1: Lcd Video Monitor
LCD VIDEO MONITOR BEDIENUNGSANLEITUNG : LCD-VIDEO-MONITOR MANUEL D’INSTRUCTIONS : MONITEUR VIDEO LCD MANUALE DI ISTRUZIONI : MONITOR VIDEO LCD INSTRUCCIONES : MONITOR DE VIDEO LCD 使用说明书：液晶视频监视器 LM-17G INSTRUCTIONS LM-15G... - Page 2 INSTRUCTIONS LCD VIDEO MONITOR LM-17G LM-15G Thank you for purchasing this JVC LCD video monitor. Before using it, read and follow all instructions carefully to take full advantage of the monitor’s capabilities. (* “LCD” stands for Liquid Crystal Display.) For Customer Use: Enter below the Serial No.
-
Page 3: Table Of Contents
Contents Safety Precautions ... 3 Installation... 5 Unpacking the Monitor... 5 Controls and Features ... 5 Using Your Monitor ... 7 Turning the Monitor On and Off ... 7 Caring for and Cleaning the Monitor ... 7 Using the Menu ... 8 Summary of Control Buttons... -
Page 4: Safety Precautions
FCC NOTICE (U.S.A. only) CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Power Cord
● Unplug this unit from the AC outlet and refer servicing to qualified service personnel under the following conditions: – when the power cord is frayed or the plug is damaged, – if liquid has been spilled into the unit, –... -
Page 6: Installation
Note: Place the monitor on a flat, sturdy surface. Choose an area free from excessive heat, moisture, and sunlight. <LM-17G> Attach the supplied stand to the monitor as shown, and then fix it with the screws. Please fix the stand with the supplied screw (A) first, and then fix it with the screws (B). Controls and Features <LM-15G>... - Page 7 □ Down ( ▼ ) button □ UP ( ▲ ) button □ MENU/ENTER button □ Video button □ PC button □ Power switch [POWER] □ VIDEO A indicator □ VIDEO B indicator □ PC indicator □ Power indicator To AC outlet (120 V AC, 50 Hz/60 Hz) For U.S.A.
-
Page 8: Using Your Monitor
When you connect the monitor to a PC, you might be requested to install the specific driver. In this case do the following: -use the driver attached with the video card of the PC you use. -set the monitor as standard monitor in the PC menu. Recommended mode, 1024x768 at 60Hz for LM-15G and 1280x1024 at 60Hz for LM-17G . Warning... -
Page 9: Using The Menu
Using the Menu This chapter contains information about how to changing monitor settings for your LCD Monitor. It is designed with an menu to help you easily adjust to its optimum performance. Note: In the PC mode, do the “AUTO SET UP” setting first, before adjusting any settings. For details, see “AUTO SET UP”... - Page 10 In the VIDEO A or B mode (composite video input): Menu BACK LIGHT You can adjust the light output of the backlight. PICTURE ADJ. PICTURE, PHASE, CHROMA, ASPECT, COLOR TEMP., LOW LIGHT ADJ. . SYSTEM SETTING SIGNAL LEVEL, DISPLAY, OSD POSITION, COLOR SYSTEM, AGC, REMOTE, All reset In the PC mode (analog RGB input): Menu...
- Page 11 COLOR TEMP. menu Press the ‘UP’ and ‘DOWN’ button to choose the “COLOR TEMP.”, and then press the ‘MENU/ENTER’ button to display the sub-menu. COLOR TEMP. HIGH NATURAL USER Press ‘UP’ and ‘DOWN’ button to choose one of four Color temp settings: HIGH, NATURAL, LOW and USER. “USER”...
- Page 12 SYSTEM SETTING menu SYSTEM SETTING Exit SIGNAL LEVEL DISPLAY OSD POSITION COLOR SYSTEM REMOTE All reset SIGNAL LEVEL: You can choose the signal level from ”STD.” or “AMP.”. STD.: Select this for normal operation. AMP.: Select this to watch dark part of the picture better. DISPLAY: If you select ‘DISPLAY’...
- Page 13 POSITION ADJ. menu You can adjust the position of the image from the PC on the screen. POSITION ADJ. Next page H. POSITION V. POSITION Press ‘UP’ and ‘DOWN’ button to choose “H. POSITION” (horizontal position) or “V. POSITION” (vertical position), and then press ‘MENU/ENTER’...
-
Page 14: Using The Monitor In The Pc Mode
Using the Monitor in the PC mode Since the inherent format of this monitor is 1024 pixels by 768 lines, the monitor will perform best when your PC is set to a screen resolution of 1024 x 768. If you use a lower resolution (such as 640 x 480), the image is expanded to fill the screen Your monitor supports many common video modes, as shown in “Video Modes”... - Page 15 The menu flowchart of the VIDEO mode *The menu can not be displayed when "No Sync" is displayed.
- Page 16 The menu flowchart of the PC mode *The menu cannot be displayed when "No Sync" is displayed.
-
Page 17: Basic Connection Example
Basic Connection Example Notes: Before connecting your system, make sure that all devices are turned off. ・ ・ The illustration shows some examples of different connections. Terminal connections may differ depending on the devices. Be sure to refer to the manuals provided with the devices. Each pair of input (IN) and output (OUT) terminals are bridge-connected ・... -
Page 18: Troubleshooting
E. The message “Signal Out of Range” appears on my monitor. This message appears when the input signal is beyond the monitor capability. Set your PC to a supported video mode; preferably 1024 x 768 at 60 Hz for LM-15G, 1280x1024 at 60Hz for LM-17G. -
Page 19: Specifications
1 line, RCA pin x 1 1 line, RCA pin x 1 5℃~35℃ at altitude 0~2000m,5℃~30℃ at altitude 2000~3000m, 20%~85%RH,non-condensing 3000m Max. 402mmx348mmx68.6mm 402mmx349.6mmx162mm 4.8 kg / 5.6kg (with stand) LM-15G 15-in(38.1cm),TFT active matrix 1024 x 768 dot 16200000 colors 304.1mmx228.1mm (H) 31.5kHz~60kHz(Analog) 15.734kHz (NTSC) 15.625kHz... - Page 20 Dimensions <LM-17G> ＜Front View＞ ＜Side View＞ <LM-15G> ＜Front View＞ ＜Side View＞...
- Page 21 If you want to use an unknown mode, do the AUTO SET UP at first. If AUTO SET UP doesn’t make adjustments corrrectly, adjust the CLOCK, PHASE , horizontal position and vertical position manually. <LM-15G> Vertical Frequency Supported Resolution...
- Page 22 P/N: 5030053031A © 2005 Victor Company of Japan, Limited 0205MKH-TU...
