Page 1: Lcd Video Monitor
• › LCD VIDEO MONITOR BEDIENUNGSANLEITUNG : LCD-VIDEO-MONITOR MANUEL D’INSTRUCTIONS : MONITEUR VIDEO LCD MANUALE DI ISTRUZIONI : MONITOR VIDEO LCD INSTRUCCIONES : MONITOR DE VIDEO LCD Ž g — p ¥ – ¾ ¥ • F ‰ t • » ¥ ¥ ¥ ¥ Š í LM-17G INSTRUCTIONS LM-15G... - Page 2 INSTRUCTIONS LCD VIDEO MONITOR LM-17G LM-15G Thank you for purchasing this JVC LCD video monitor. Before using it, read and follow all instructions carefully to take full advantage of the monitor’s capabilities. (* “LCD” stands for Liquid Crystal Display.) For Customer Use: Enter below the Serial No.
-
Page 3: Table Of Contents
Contents Safety Precautions ....................3 Installation........................5 Unpacking the Monitor....................5 Controls and Features ....................5 Using Your Monitor ....................7 Turning the Monitor On and Off ................. 7 Caring for and Cleaning the Monitor ................7 Using the Menu ......................8 Summary of Control Buttons.................. -
Page 4: Safety Precautions
This monitor is equipped with a 3-blade grounding-type plug to satisfy FCC rule. If you are unable to insert the plug into the outlet, contact your electrician. FCC NOTICE (U.S.A. only) Changes or modifications not approved by JVC could void the user’s authority to operate the CAUTION: equipment. - Page 5 ● Unplug this unit from the AC outlet and refer servicing to qualified service personnel under the following conditions: – when the power cord is frayed or the plug is damaged, – if liquid has been spilled into the unit, –...
-
Page 6: Installation
Installation Please follow the instructions in this chapter to install your LCD Monitor. Note: Before connecting your monitor, first read through the instructions in this chapter and the safety precautions in the previous chapter. Unpacking the Monitor When you are unpacking the monitor, make sure that you have the following items: The LCD monitor AC power cord Stand and screw... - Page 7 Use this button for menu operation. (See page 8) • Down ( ▼ ) button Displays the “AUTO SET UP” menu in the PC mode. (See page 13) Use this button for menu operation. (See page 8) • UP ( ▲ ) button Displays the “AUTO SET UP”...
-
Page 8: Using Your Monitor
Using Your Monitor This chapter contains information about using your LCD Monitor. Turning the Monitor On and Off Use the power button located at the lower right side of the front panel of the monitor to turn the monitor on and off. When the monitor is on, the Power indicator near the Power button lights green. -
Page 9: Using The Menu
Using the Menu This chapter contains information about how to changing monitor settings for your LCD Monitor. It is designed with an menu to help you easily adjust to its optimum performance. Note: In the PC mode, do the “AUTO SET UP” setting first, before adjusting any settings. For details, see “AUTO SET UP”... - Page 10 In the VIDEO A or B mode (composite video input): Menu Items You can adjust the light output of the backlight. BACK LIGHT PICTURE, PHASE, CHROMA, ASPECT, COLOR TEMP., LOW LIGHT ADJ. . PICTURE ADJ. SYSTEM SETTING SIGNAL LEVEL, DISPLAY, OSD POSITION, COLOR SYSTEM, AGC, REMOTE, All reset In the PC mode (analog RGB input): Menu...
- Page 11 COLOR TEMP. menu Press the ‘UP’ and ‘DOWN’ button to choose the “COLOR TEMP.”, and then press the ‘MENU/ENTER’ button to display the sub-menu. COLOR TEMP. HIGH NATURAL USER Press ‘UP’ and ‘DOWN’ button to choose one of four Color temp settings: HIGH, NATURAL, LOW and USER. “USER”...
- Page 12 SYSTEM SETTING menu SYSTEM SETTING Exit SIGNAL LEVEL DISPLAY OSD POSITION COLOR SYSTEM REMOTE All reset SIGNAL LEVEL: You can choose the signal level from ”STD.” or “AMP.”. STD.: Select this for normal operation. AMP.: Select this to watch dark part of the picture better. DISPLAY: If you select ‘DISPLAY’...
- Page 13 POSITION ADJ. menu You can adjust the position of the image from the PC on the screen. POSITION ADJ. Next page H. POSITION V. POSITION Press ‘UP’ and ‘DOWN’ button to choose “H. POSITION” (horizontal position) or “V. POSITION” (vertical position), and then press ‘MENU/ENTER’...
-
Page 14: Using The Monitor In The Pc Mode
Using the Monitor in the PC mode Since the inherent format of this monitor is 1024 pixels by 768 lines, the monitor will perform best when your PC is set to a screen resolution of 1024 x 768. If you use a lower resolution (such as 640 x 480), the image is expanded to fill the screen Your monitor supports many common video modes, as shown in “Video Modes”... - Page 15 The menu flowchart of the VIDEO mode *The menu can not be displayed when "No Sync" is displayed.
- Page 16 The menu flowchart of the PC mode *The menu cannot be displayed when "No Sync" is displayed.
-
Page 17: Basic Connection Example
Basic Connection Example Notes: Before connecting your system, make sure that all devices are turned off. • E • E The illustration shows some examples of different connections. Terminal connections may differ depending on the devices. Be sure to refer to the manuals provided with the devices. •... -
Page 18: Troubleshooting
Troubleshooting Solutions to common problems related to your monitor are described here. If none of the solutions presented here solove the problem, unplug the monitor and consult a JVC-authorised dealer or service centre for assistance. A. My monitor doesn’t work. -
Page 19: Specifications
Specifications Model LM-17G LM-15G Item LCD Video Monitor Type• F PAL,NTSC, BW60,BW50 Color system• F 17-in(43.275cm),TFT active matrix 15-in(38.1cm),TFT active matrix LCD panel• F 1280 x 1024 dot 1204 x 768 dot 16700000 colors 16700000 colors Display colors• F 337.92mmx270.34mmx432.75mm 304.1mmx228.1mmx380mm Display area(W x H x D) (H) 31.5kHz~80kHz(Analog) - Page 20 Dimensions <LM-17G> • ƒ Front View• „ • ƒ Side View• „ <LM-15G> • ƒ Front View• „ • ƒ Side View• „...
- Page 21 Video Modes (Analog RGB Signal) Your LCD monitor supports the following industry-standard combinations of screen resolution and refresh rates. For optimum performance, set your PC to the screen resolution of 1024 x 768 at 60 Hz refresh rate. <LM-17G> <LM-15G> Supported Resolution Vertical Frequency Supported Resolution...
- Page 22 VICTOR COMPANY OF J APAN, LIMITED ® Registered Trademark owned by VICTOR COMPANY OF JAPAN, LTD. P/N: 5030054005 © 2003 VICTOR COMPANY OF JAPAN, LIMITED 1003-MK-TU...
