Assembling the Wi-Fi module

1. Push the Wi-Fi module down into a slot and fix the hook on the top.
2. Connect the wire of the Wi-Fi module.
3. Close the cover of the sub panel.

Checking the connection status on the panel-display

f Wi-Fi display description
1) Wi-Fi Indicator LED off :
Not connected with AP
Not connected with internet
2) Wi-Fi Indicator LED blinking :
Connected with AP
Not connected with internet
3) Wi-Fi Indicator LED on :
Connected with AP
Connected with internet
