Summary of Contents for JVC GD-V502PCE
- Page 1 PLASMA DISPLAY MONITOR INSTRUCTIONS GD-V502PCE...
-
Page 2: Table Of Contents
Dear JVC Customer Welcome to the JVC family of customers. We hope that you will have many years of enjoyment from your new Plasma Display. To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference. -
Page 3: Important Safety Notice
If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local JVC Dealer. If the fitted moulded plug is unsuitable for the socket outlet in your home, then the fuse shall be removed and the plug cut off and disposed of safety. -
Page 4: Safety Precautions
If water is spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result in fire or electric shock. If any foreign objects get inside the Plasma Display, please consult your local JVC dealer. -
Page 5: Cleaning And Maintenance
If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet becomes damages, disconnect the power cord plug immediately. • A short circuit may occur, which could cause fire. Contact your local JVC dealer for any repairs that need to be made. CAUTION When using the Plasma Display Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display. -
Page 6: Accessories
Accessories Accessories Supply Check that you have the accessories and items shown Operating Instruction book GD-V502PCE AC cord Remote Control Batteries Requires two R6 batteries. 1. Turn the transmitter face down. Press and slide off the battery cover. Helpful Hint: For frequent remote control users, replace old batteries with Alkaline batteries for longer life. -
Page 7: Connections
Connections When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation. Speakers (Optional accessories) SPEAKERS Terminals (R) – AC cord fixing 1. Open the clamper. – Cable fixing bands Secure any excess cables with bands as required. Pass the attached cable fixing band through the clip as shown in the... -
Page 8: Pc Input Terminals Connection
Connections PC Input Terminals connection COMPUTER Installing the ferrite core (Small size) Pull back the tabs (in two places) Installing the ferrite core (Large size) Notes: (1) Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning frequency of 48 to 120 Hz. -
Page 9: Serial Terminals Connection
SERIAL Terminals connection The SERIAL terminal is used when the Plasma Display is controlled by a computer. COMPUTER D-sub 9p Notes: (1) Use the RS-232C cable to connect the computer to the Plasma Display. (2) The computer shown is for example purposes only. (3) Additional equipment and cables shown are not supplied with this set. -
Page 10: Basic Controls
Basic Controls R - STANDBY G POWER ON Main Power On/Off Switch Remote control sensor Power Indicator The Power Indicator will light. • Power-OFF .. Indicator not illuminated (The unit will still consume some power as long as the power cord is still inserted into the wall outlet.) •... - Page 11 Stand-by (ON/OFF) button The Plasma Display must first be plugged into the wall outlet and turned on at the power switch (see page 12). Press this button to turn the Plasma Display On, from Stanby mode. Press it again to turn the Plasma Display Off to Stanby mode.
-
Page 12: Power On/Off And Input Signal Selection
Power On/Off and input signal selection AC cord connection Connecting the AC cord plug to the Plasma Display. Power On/Off – R - STANDBY INPUT MENU ENTER G POWER ON R - STANDBY G POWER ON Remote Control Power Indicator Sensor When the Power is turned on for the first time, the Language selection screen is... -
Page 13: Select The Input Signal
Select the input signal R - STANDBY INPUT MENU ENTER G POWER ON INPUT MENU ENTER INPUT SURROUND Selecting the On-Screen Menu Language INPUT SURROUND Selectable languages PICTURE SOUND SET UP MULTI ZOOM Power On/Off and input signal selection INPUT Press the INPUT button to select the input signal to be played back from the equipment which has been connected to the Plasma Display. -
Page 14: On-Screen Menu Displays
On-Screen Menu Displays To Picture adjust menu (see page 18) Picture Normalise Normal Picture Mode Normal Contrast Brightness Colour Tint Sharpness White balance Normal Advanced settings Press to select “On”. Press to enter Advanced settings. To Advanced settings (see page 18, 19) Advanced settings Normalise Normal... - Page 15 Press to access each adjust screen. To Signal screen for AV(S Video) (see page 30, 31) [ AV ] Signal 3D Y/C Filter ( NTSC ) Colour system Auto Cinema reality Aspect Auto ( 4:3 ) 4 : 3 Note: “Signal” setup menu displays different setting condition for each input signals. (see page 13) To setup Screensaver Press to select Start Time/ Finish Time (see page 24-26)
-
Page 16: Aspect Controls
ASPECT Controls The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format picture. ASPECT button ASPECT The aspect mode changes each time the INPUT ASPECT button is pressed. SURROUND [from the unit] PICTURE SOUND SET UP... -
Page 17: Adjusting Picture Pos./Size
Adjusting Picture Pos./Size Adjusting screen PICTURE POS. /SIZE Press to display the Picture Pos./Size menu. Press to select H-Pos/H-Size/V-Pos/V- Size/Clock Phase. During “AV(S Video)” and “Component” input signal. Picture Pos./Size Normalise Normal H-Pos H-Size V-Pos V-Size Press to adjust Pos./Size. Press to exit from adjust mode. -
Page 18: Picture Adjustments
Picture Adjustments PICTURE Press to display the Picture menu. Select to adjust each item. Press to select the menu to adjust. Select the desired level by looking at the picture behind the menu. Picture Normalise Normal Picture Mode Normal Contrast Brightness Colour Tint... -
Page 19: Advanced Settings
Item Effect Contrast Less More Brightness Darker Brighter Colour Less More Tint (NTSC only) Reddish Greenish Sharpness Less More Note: In PICTURE, there is not a noticeable change even when contrast is increased with a bright picture or reduced with a dark picture. -
Page 20: Sound Adjustment
Sound Adjustment SOUND Press to display the Sound menu. Select to adjust each item. Press to select the desired adjustment menu. Select the desired level by listening to the sound. Bass Adjusts low sounds Treble Adjusts high sounds Balance Adjusts left and right volumes Surround Select On or Off... -
Page 21: Digital Zoom
Digital Zoom This displays an enlargement of the designated part of the displayed image. Display the "Operation Guide". ZOOM MOVE Press to access Digital Zoom. The “Operation Guide” will be displayed. INPUT SURROUND PICTURE SOUND SET UP MULTI ZOOM SWAP SELECT MOVE PICTURE... -
Page 22: Present Time Setup / Set Up Timer
PRESENT TIME Setup / Set up TIMER The timer can switch the Plasma Display On or Off. Before attempting Timer Set, confirm the PRESENT TIME and adjust if necessary. Then set POWER ON Time / POWER OFF Time. INPUT SURROUND PICTURE SOUND SET UP... -
Page 23: Set Up Timer
Set up TIMER Display the Set up TIMER screen. Notes: • Pressing “ ” or “ ” button once changes POWER ON Time / POWER OFF Time 1minute. • Pressing “ ” or “ ” button continuously changes POWER ON Time / POWER OFF Time by 15 minutes. Note: Timer function will not work unless “PRESENT TIME”... -
Page 24: Screensaver (For Preventing After-Images)
Screensaver Do not display a still picture, especially in 4:3 mode, for any length of time. If the display must remain on, a Screensaver should be used. SET UP Reversal / Scroll selection Mode selection Start setting Note: This function does not guarantee the complete prevention of permanent afterimages. The potential for the occurrence of permanent afterimages is merely decreased. -
Page 25: Setup Of Screensaver Time
Setup of Screensaver Time After selecting Time Designation or Interval, the relevant Time Setup will become available for selection and the Operating Time may be set. (Time cannot be set when “Mode” is “on” or “off.”) Screensaver 10 : 00 PRESENT TIME Start White bar scroll... -
Page 26: Side Panel Adjustment
Screensaver (For preventing after-images ) Side Panel Adjustment Do not display a picture in 4:3 mode for an extended period, as this can cause an after-image to remain on the side panels either side of the display field. To prevent the appearance of such an after-image, illuminate the side panels. -
Page 27: Reduces Power Consumption
Reduces power consumption • Power save: When this function is turned On, luminous level of the plasma display is suppressed, so power consumption is reduced. • Standby save: When this function is turned On, power consumption of the microcomputer is reduced during power supply standby (see page 10, 11, 12), so standby power of the set is reduced. -
Page 28: Setup For Multi Display
Setup for MULTI DISPLAY By lining up Plasma Displays in groups of 4 or 9 as illustrated below, an enlarged picture may be displayed across all screens. For this mode of operation, each plasma display has to be set up with a Display number to determine its location. group of 4 (2 2) How to Setup MULTI DISPLAY INPUT... -
Page 29: For Each Plasma Display
How to set the display location number for each Plasma Display Notes: (1) For RGB/PC input signals, normal multi-display magnification is only available at the VGA, SVGA and XGA resolution. (2) The multi-display capability is functional for the following component signals: 525 (480) / 60i ·... -
Page 30: Setup For Input Signals
Setup for Input Signals Component/RGB-in Select Select the input signals to be connected by installing the Optional Terminal Board. (Refer to the Operating Instructions for the optional Terminal Board.) Select to match the signals from the source connected to the Component/RGB input terminals. Y, P signals “Component”... -
Page 31: Colour System / Aspect Auto
Colour system / Aspect Auto Select Signal from the “Setup” menu during AV(S Video) input signal. (“Signal [AV]” menu is displayed.) Press to select the “Colour System” or “Aspect Auto”. Press to select each functions. If the picture image becomes unstable: With the system set on Auto, under conditions of low level or noisy input signals the image may in rare cases become unstable. -
Page 32: Sync
Setup for input signals Sync Select Signal from the “Setup” menu during RGB input signal. Press to adjust. Press to exit from adjust mode. Setting RGB sync signal: Confirm that the input is set to RGB input (this setting is valid only for RGB input signal). -
Page 33: Troubleshooting
Troubleshooting Before you call for service, determine the symptoms and make a few simple checks as shown below. Symptoms Picture Interference Normal Picture No Picture No Picture No Colour This Plasma Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type of input signal. -
Page 34: Input Signal Can Be Displayed
Input signal can be displayed Applicable input signals for PC Input (Mini D-sub 15P) ( Mark) Signal name 525 (480) / 60i 525 (480) / 60p 625 (575) / 50i 625 (575) / 50p 750 (720) / 60p 750 (720) / 50p 1,125 (1,080) / 60i 1,125 (1,080) / 50i 1,125 (1,080) / 24p... -
Page 35: Specifications
1,210 mm INPUT MENU – ENTER R - STANDBY G POWER ON approx. 43.5 kg net approx. 48.1 kg GD-V502PCE 445 W 0.4 W 3000:1 1,269 mm (diagonal) 768 (H)) [4,098 768 dots] 0 C - 40 C 20 % - 80 % XGA display R,G,B/0.7 Vp-p (75-ohm) - Page 36 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan © 2003 VICTOR COMPANY OF JAPAN, LIMITED TQZW367...
