INSTRUCTIONS
Model
GD-V4210PZW
GD-V4210PZW-G
GD-V4210PCE
GD-V4210PCE-G
GD-V4211PCE
This instruction manual refers to the GD-V4210PZW, GD-V4210PZW-G, GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE.
The explanations and illustrations used in this instruction manual are of the GD-V4210PZW unless otherwise stated.
The differences between each model are as follows:
GD-V4210PZW
Frame Colour
Inputs VIDEO A
VIDEO B
COMPONENT
*
1
These inputs will be available with the separately-purchased video interface kit (IF-C421P1W).
Ask your dealer to install the video interface kit.
Safety Precautions .................................................... 2
Parts Identification ..................................................... 4
• Remote Control ................................................... 4
• Monitor: Front View ............................................. 5
• Monitor: Rear Views ............................................ 6
Preparations .............................................................. 9
• Checking the Accessories ...................................9
• Installing the Batteries .........................................9
Installation ............................................................... 10
• Precautions ....................................................... 10
Connections ............................................................ 11
• Precautions ....................................................... 11
• Available Signals ............................................... 11
• Connection Examples ....................................... 12
Basic Operations ..................................................... 14
• Daily Operations ................................................ 14
• Changing the Aspect Ratio ............................... 15
Video Adjustments .................................................. 16
• Adjusting the Picture Quality ............................ 16
• Adjusting the Color Temperature ...................... 19
• Adjusting the White Balance ............................. 19
• Changing the Picture Mode .............................. 21
• Changing the Aspect Ratio ............................... 21
• Setting the RGB Input ....................................... 23
GD-V4210PZW-G
Silver
Gray
Available
Available
Available
Contents
Page
Thank you for purchasing this JVC Monitor.
Before using the monitor, read this manual carefully so
that you know how to use the Monitor correctly.
Refer to this manual whenever questions or problems
about operation arise. Be sure to read and observe the
safety precautions.
Keep this manual where the user can see it easily.
* Installation and removal require special expertise.
Consult your product dealer for details.
GD-V4210PCE
GD-V4210PCE-G
Silver
Gray
Not available*
Not available*
Not available*
Other Convenient Functions ....................................24
• Showing On-screen Display ............................. 24
• Confirming the Use Time ...................................25
• Setting the Auto Sleep Function ....................... 25
the Input Mode .................................................. 26
• Mounting the Monitor Vertically ........................ 27
• Using the Pixel Shift Function ........................... 27
• Using the Power Save Function ....................... 28
• Preventing the Afterimage Effect ...................... 29
• Refreshing the Screen....................................... 29
• Resetting All the Menu Settings ....................... 30
Serial Connections and Operations ........................ 31
• Assigning ID Numbers....................................... 31
Menu Classifications ............................................... 33
• Main Menu ........................................................ 33
• Setup Menu ....................................................... 35
Troubleshooting ....................................................... 36
• Self-diagnostic Indication ..................................37
Specifications .......................................................... 38
GD-V4211PCE
Silver
1
1
1
Page
1

Advertisement

Table of Contents
loading

Related Manuals for JVC GD-V4210PCE

Summary of Contents for JVC GD-V4210PCE

  • Page 1: Table Of Contents

    GD-V4210PCE GD-V4210PCE-G GD-V4211PCE This instruction manual refers to the GD-V4210PZW, GD-V4210PZW-G, GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE. The explanations and illustrations used in this instruction manual are of the GD-V4210PZW unless otherwise stated. The differences between each model are as follows: GD-V4210PZW...

  • Page 2: Safety Precautions

    GD-V4210PZW / GD-V4210PZW-G / GD-V4210PCE / GD-V4210PCE-G CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 – When the product is used on a cart, care should be taken to avoid quick stops, excessive force, and uneven surfaces which may cause the product and cart to overturn, damaging equipment or causing possible injury to the operator. –...

  • Page 4: Parts Identification

    To select the correct RGB input, you have to set “RGB INPUT” correctly on the menu (see page 23). • Only for GD-V4210PCE, GD-V4210PCE-G and GD-V4211PCE: Only RGB input can be reproduced. To reproduce images through the other inputs, you need to install video interface kit (IF-C421P1W), which is separately purchased.

  • Page 5: Monitor: Front View

    To select the correct RGB input, you have to set “RGB INPUT” correctly on the menu (see page 23). • Only for GD-V4210PCE, GD-V4210PCE-G and GD-V4211PCE: Only RGB input can be reproduced. To reproduce images through the other inputs, you need to install video interface kit (IF-C421P1W), which is separately purchased.

  • Page 6: Monitor: Rear Views

    (page 12) INTERNAL: To use built-in speakers. EXTERNAL: To use external speakers. 7 REMOTE 2 (JVC CODE) terminals (mini jack) (page 31) • IN For Master Monitor: Connect a wired remote control to this terminal for serial connection.
  • Page 7 8 RGB B input/output terminals (page 12) • R, G, B, HD/Cs, VD input terminals (BNC) Connect these terminals to the following output terminals of a personal computer or other equipment: – Analog RGB signal output terminals – Horizontal sync (HD) signal or composite (Cs) signal output terminal –...
  • Page 8 Connect these terminals to the audio output terminals of the other equipment. Note: * GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE do not have the following input terminals – VIDEO A, VIDEO B, and COMPONENT. To input video, S-video, and component signals, you need to install video interface kit (IF-C421P1W), which is separately purchased.

  • Page 9: Preparations

    Preparations Checking the Accessories The following accessories are included with the Monitor. Check for them. If any item is missing, please contact the dealer where you purchased the Monitor. • Remote control (RM-C575) x 1 • Remote control cable x 1 •...

  • Page 10: Installation

    Installation Precautions • When mounting the Monitor vertically, it is necessary to adjust the cooling fan speed to provide better heat dissipation. Do not forget to perform this adjustment. (See page 27.) • When installing the Monitor, be sure to use a dedicated Stand Unit, Wall Mounting Unit, or Monitor Hanger Unit, depending on a particular case.

  • Page 11: Connections

    • VIDEO A and VIDEO B terminals accept — PAL, NTSC, NTSC4.43, and SECAM signals. • COMPONENT terminals accept — 480i, 576i, 480p, 720p, and 1080i (1035i) signals. (For GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE, to input the above signals, you need to install the video interface kit (IF-C421P1W), which is separately purchased.) Computer signals (Preset and user-defined video modes) This Monitor has 13 preset video modes for the most popular industrial standard (marked with ¶...

  • Page 12: Connection Examples

    Personal computer 2 To audio output (used as the playback source) To RS-232C Power cord (RS232C) (120/230V) SPEAKER OUT (JVC CODE) INTERNAL EXTERNAL To audio output When connecting the RGB terminals, set the RGB INPUT setting correctly (see page 23.) •...
  • Page 13 AV connections These terminals are not available for GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE. To use them, you need to install video interface kit (IF-C421P1W), which is separately purchased. VCR 1 (used as the playback source) Notes: • You can connect another VCR or Monitor to the VIDEO A OUT terminal. However, when connecting a VCR to the VIDEO A terminals, do not connect both IN and OUT terminals to the same VCR.

  • Page 14: Basic Operations

    ID SET MENU/EXIT RM-C575 REMOTE CONTROL UNIT * Only for GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE: You need to install the video interface kit (IF-C421P1W), which is separately purchased, to reproduce input images for VIDEO A, VIDEO B, and COMPONENT. Daily Operations Turn on the main power.

  • Page 15: Changing The Aspect Ratio

    Changing the Aspect Ratio ASPECT DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT RM-C575 REMOTE CONTROL UNIT Precautions for using the screen mode switching function • This Monitor features a screen mode switching (aspect ratio change) function.

  • Page 16: Video Adjustments

    Video Adjustments MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT For video adjustments, use menus. You can use the buttons either on the remote control or on Monitor for menu operations.

  • Page 17: Adjusting The Screen Size And Position

    To make an adjustment while viewing the adjustment After step 3 on page 16, proceed as follows: 1 Press 5/∞ to move the cursor (3) to “sub menu.” 2 Press 3 to display the Sub Menu. The Sub Menu for CONTRAST appears on the screen. C O N T R A S T : + 0 1 –...
  • Page 18 Video Adjustments MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME VOLUME – MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT (Continued) Press 2/3 to adjust the selected item. Press MENU/EXIT (or MENU on the Monitor) twice to exit from the menu operations.

  • Page 19: Adjusting The Color Temperature

    Adjusting the Color Temperature The adjusted setting applies to all inputs. Press MENU/EXIT (or MENU on the Monitor) to display the Main Menu. M A I N M E N U Cursor (3) P I C T U R E A D J .
  • Page 20 Video Adjustments MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT (Continued) To make an adjustment while viewing the adjustment bars After step 3 on page 19, proceed as follows: 1 Press 5/∞...

  • Page 21: Changing The Picture Mode

    Changing the Picture Mode When one of the following signals comes in through the RGB terminals — RGB15K-50, RGB15K-60, PC98, VGA480-60, SVGA-56, SVGA-60, and XGA-60, you can select the picture mode suited to either still pictures or moving pictures. Press MENU/EXIT (or MENU on the Monitor) to display the Main Menu.

  • Page 22: Setting The Receivable Signal Types

    Video Adjustments MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT (Continued) Setting the Receivable Signal Types You can set the receivable signal types. Normally, select “AUTO.”...

  • Page 23: Setting The Rgb Input

    Setting the RGB Input After connecting the playback device such as a PC to the RGB terminals, you have to specify which terminal you have connected the device to — RGB A (D-sub 15 pin) or RGB B (BNC) input. •...

  • Page 24: Other Convenient Functions

    Other Convenient Functions MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME VOLUME – MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT To set the other convenient functions, use menus. You can use the buttons either on the remote control or on Monitor for menu operations.

  • Page 25: Confirming The Use Time

    Confirming the Use Time You can confirm the hours of use on the Setup Menu. This may be necessary when you ask for any service. On the remote control: Press MENU/EXIT while holding VOLUME – to display the Setup Menu. On the Monitor: Press MENU while holding 2 to display the Setup Menu.

  • Page 26: Prohibiting The Monitor's Button Operations

    Other Convenient Functions MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME – MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT (Continued) Prohibiting the Monitor’s Button Operations This function allows you to prohibit the button operations on the Monitor to prevent malfunction or avoid tampering.

  • Page 27: Mounting The Monitor Vertically

    Press 5/∞ to move the cursor (3) to “STATUS DISPLAY.” • The Setup Menu consists of two pages. If you keep pressing 5/∞, you can move to the other page from the current page. Press 2/3 to select the desired setting. Each time you press the button, the Status Display function alternates between “ON”...

  • Page 28: Using The Power Save Function

    Other Convenient Functions MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME VOLUME – MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT (Continued) Press 5/∞ to move the cursor (3) to “PIXEL SHIFT”...

  • Page 29: Preventing The Afterimage Effect

    Preventing the Afterimage Effect After showing the same still picture on the screen, reverse the color on the screen using this function so that you can avoid the screen from being burned in with the still picture. On the remote control: Press MENU/EXIT while holding VOLUME –...

  • Page 30: Resetting All The Menu Settings

    Other Convenient Functions MENU INPUT 2 / 3 MENU DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING VOLUME – MULTIPLE MONITOR ADJUSTMENT MODE ID SET MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT (Continued) Resetting All the Menu Settings You can reset all the Menu settings and adjustments at a time, except the use time of the source lamp (HOUR METER).

  • Page 31: Serial Connections And Operations

    • Do not connect the last monitor to Monitor 1. • When operating with a wired remote control, connect it to the REMOTE 2 (JVC CODE) input terminal of Monitor 1. • When Monitors are serially connected, Monitor 2 and subsequent Monitors cannot be directly controlled with a wireless remote control.

  • Page 32: Operating The Monitors Simultaneously

    Serial Connections and Operations • When performing simultaneous or individual operation, use the remote control. DISPLAY ASPECT VIDEO A VIDEO B COMPO. MUTING MULTIPLE MONITOR ADJUSTMENT MODE ID SET MODE MENU/EXIT MENU/EXIT RM-C575 REMOTE CONTROL UNIT Operating the Monitors Simultaneously •...

  • Page 33: Menu Classifications

    Menu Classifications Main Menu Main Menu M A I N M E N U P I C T U R E A D J . S I Z E / P O S I T I O N A D J . F U N C T I O N S E L E C T S T A T U S D I S P L A Y E N T E R :...
  • Page 34 Menu Classifications PICTURE ADJ. (Picture adjustment): See page 16. CONTRAST Adjusts the contrast of the picture. BRIGHT Adjusts the brightness of the picture. CHROMA*** Adjusts the color density of the picture. PHASE* Adjusts the color phase. SHARPNESS Adjusts the outlines of the picture. sub menu Displays the fine adjustment bar.

  • Page 35: Setup Menu

    Setup Menu S E T - U P M E N U 1 / 2 A U T O S L E E P : 1 M I N . C O N T R O L L O C K : O N S T A T U S D I S P L A Y : O N...

  • Page 36: Troubleshooting

    Troubleshooting Solutions to common problems related to the Monitor are described here. If none of the solutions presented here solves the problem, unplug the Monitor and consult an authorized dealer or service center. Symptom Power is not supplied. • Is the power cord disconnected? •Is the MAIN POWER switch turned on? Video image does not •Is the correct input selected?

  • Page 37: Self-Diagnostic Indication

    Please give me immediate advice or service if necessary. Self-diagnostic lamps NO. Lamp position Conditions & & Upper Lights & & Middle Lights & & Lower Lights Your Name: Telephone No.: Address: Flashes Flashes Flashes Remote sensor MENU INPUT POWER Model Name: Plasma Display Monitor GD-V4210PZW/GD-V4210PZW-G GD-V4210PCE/GD-V4210PCE-G GD-V4211PCE...

  • Page 38: Specifications

    500 mV(rms), high impedance BNC terminal x 3 Y: 1 V(p-p), 75 /B-Y: 0.7 V(p-p), 75 /R-Y: 0.7 V(p-p), 75 Pin jack terminal x 2 (L/R) 500 mV(rms), high impedance GD-V4210PCE / GD-V4210PCE-G / GD-V4211PCE GD-V4210PCE / GD-V4211PCE: Silver GD-V4210PCE-G: Gray...
  • Page 39 SPEAKER OUT terminal AUDIO output terminal GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE do not have the following input terminals – VIDEO A, VIDEO B, and COMPONENT. You need to install the video interface kit (IF-C421P1W), which is separately purchased, to reproduce input images for VIDEO A, VIDEO B, and COMPONENT.
  • Page 40 Specifications Pin assignment (Specifications for terminals) • Y/C terminal Pin number Signal name GND (Y) GND (C) • RGB Input Terminal Dimensions Top view Front view (Continued) • RS-232C terminal This is a female type connector. 4 3 2 1 Pin number Pin number Signal name...
