Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
BUILT TO LAST
Description
These units are powered by air-cooled
four cycle engines and designed to run
at maximum RPM and give a
continuous wattage as rated. On
certain models, a low-oil level shutoff
is provided to protect the engine. This
feature is usually associated with
extended run models. The alternator is
thermostatically protected. To operate
this unit as a generator or welder, set
the switch on the front panel
accordingly
Unpacking
When unpacking, inspect carefully for
any damage that may have occurred
during transit. Make sure any loose
fittings, bolts, etc., are tightened
before putting unit into service. Report
any missing items by calling 1-800-746-
5641.

General Safety

Danger alerts you
DANGER
!
to a hazard that
WILL result in death or serious injury
Warning alerts you
WARNING
!
to a hazard that
COULD result in death or serious
injury.
Caution alerts you
CAUTION
!
to a hazard that
MAY result in minor injury.
Notice alerts you
NOTICE
to important
information that will help you prevent
damage to equipment.
Before starting or
servicing any
welder/generator, read
and understand all
instructions. Failure to
follow safety precautions or
instructions can cause equipment
damage and or serious personal
© 2001 Campbell Hausfeld
TM
injury or death. Engine instructions
for these units are contained in a
separate manual. Retain all manuals
for future reference.
Never use this welder/generator for
any application other than that
specified by the manufacturer.
Never operate this welder/generator
under conditions not approved by
the manufacturer. Never attempt to
modify this welder/generator to
perform in any manner not
intended by the manufacturer.
For maintenance and repairs, use
only products and parts
recommended by the manufacturer.
Be sure that the welder/generator is
properly grounded to an external
ground path prior to operation.
Refer to the section entitled
"Grounding Instructions" for proper
grounding procedures.
Be sure that the welder/generator is
operated only by persons who have
read and understand these
instructions.
Be sure that the welder/generator is
placed on a flat level surface prior
to and during operation. The
welder/generator must not slide or
shift during operation.
Keep all persons away from the
welder/generator during operation.
Do not allow persons wearing loose
clothing or jewelry to start or
operate the welder/generator.
Loose clothing or jewelry may
become entangled in moving
components, causing equipment
damage and or personal injury.
Keep all persons away from parts
that move or become hot during
operation.
MANUAL
Be sure all powered devices are shut
off prior to connecting them to the
welder/generator.
Keep the welder/generator clean
and well maintained at all times.
For parts, product & service information
visit www.chpower.com or call 1-800-746-5641
Welder/Generator
!
Never operate this
welder/generator in an
explosive or flammable
atmosphere or poorly ventilated area.
!
on wet surfaces or in the rain.
!
disconnect the spark plug wire before
performing any service or maintenance
to the unit.
!
engine. This is a four cycle engine
designed to run on pure gasoline. Oil is
used for engine lubrication purposes
only.
!
Always keep a fire
extinguisher accessible while
performing arc welding
operations.
WARNING
Be sure that all tools and appliances
are in good repair and are properly
grounded. Use devices that have
three prong power cords. If an
extension cord is used, be sure that
it has three prongs for proper
grounding.
Do not operate this
WARNING
welder/generator
Shut off the
DANGER
engine and
Use only unleaded fuel. Do not refill
the fuel tank while the engine is
running. Use precautions to prevent
fuel spillage during refills. Be sure
the fuel tank cap is securely in place
before starting the engine. Clean up
any spilled fuel before starting the
engine. Allow engine to cool for at
least two minutes before refueling.
This welder/generator may be used
for emergency stand-by service. In
such cases, a manual transfer switch
must be installed between the
electric utilities meter and the
electrical distribution box. This
switch should be installed by a
licensed electrician.
Never mix oil with
CAUTION
gasoline for this
WARNING
IN952501AV 4/01
