Before using your air conditioner, please read
this manual carefully and keep it for future reference.
-
INVERTER SPLIT TYPE
ROOM AIR CONDITIONER
R
ead This Manual
Inside you will find many helpful hints on how
to use and maintain your air conditioner properly.
Just a little preventative care on your part can
save you a great deal of time and money over
the life of your air conditioner. You'll find many
answers to common problems in the chart of
troubleshooting tips. If you review the chart of
Troubleshooting Tips first, you may not need
to call for service.
Advertisement
Table of Contents
Related Manuals for Midea INVERTER SPLIT TYPE ROOM AIR CONDITIONER
Summary of Contents for Midea INVERTER SPLIT TYPE ROOM AIR CONDITIONER
-
Page 1: Room Air Conditioner
Before using your air conditioner, please read this manual carefully and keep it for future reference. INVERTER SPLIT TYPE ROOM AIR CONDITIONER ead This Manual Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventative care on your part can save you a great deal of time and money over the life of your air conditioner. -
Page 2: Table Of Contents
CONTENTS SOCIABLE REMARK Sociable remark........................2 SAFETY PRECAUTIONS Warning ..........................3 Caution ..........................4 OPERATING INSTRUCTIONS Parts names ........................5 Operating temperature......................7 Manual operation ........................7 Airflow direction control ......................8 How the air conditioner works ....................9 CARE AND MAINTENANCE Care and maintenance ......................10 OPERATION TIPS Operation tips .... -
Page 3: Sociable Remark
SOCIABLE REMARK The follow contents apply only the countries of Europe. DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are several possibilities: A) The municipality has established collection systems, where electronic waste can be disposed of at least free of charge to the user. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. -
Page 5: Caution
SAFETY PRECAUTIONS ! CAUTION When the air filter is to be Do not clean the air Ventilate the room well conditioner with water. when used together removed, do not touch the with a stove, etc. metal parts of the unit. It may cause an injury. -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Indoor unit NOTE: The indoor unit you purchased would like one of the following. There is a slightly difference on front panel and display window, but the features are the same. Indoor unit Air inlet 1. Front panel 2. - Page 7 OPERATING INSTRUCTIONS B) It displays the room temperature when the air conditioner is in FAN only operation. C) Displays the malfunction code or protection code. D) When SELF CLEAN feature is activated, it displays OPERATION FREQUENCY display: This display is separated into five zones. The zones illuminate based on the compressor current frequency.
-
Page 8: Operating Temperature
OPERATING INSTRUCTIONS NOTE: This manual does not include Remote Controller Operations, see the <<Remote Controller Instruction>> packed with the unit for details. Operating temperature Mode Cooling operation Heating operation Drying operation Temperature >17 C Room temperature <30 C >10 C 50 C -15 C 34 C... -
Page 9: Airflow Direction Control
OPERATING INSTRUCTIONS Airflow direction control Adjust the air flow direction properly otherwise, it might cause discomfort or cause uneven room temperatures. Adjust the horizontal/vertical louver using the remote controller. Adjust the vertical louver manually only(For some models). To set the horizontal/vertical air flow direction Range (automatically) Perform this function while the unit is in operation. -
Page 10: How The Air Conditioner Works
OPERATING INSTRUCTIONS How the air conditioner works AUTO operation When you set the air conditioner in AUTO mode, it will SLEEP operation 7 hours timer off automatically select cooling, heating(cooling/heating models only), or fan only operation depending on what temperature you have selected and the room temperature. The air conditioner will control room temperature Temperature automatically round the temperature point set by you. -
Page 11: Care And Maintenance
CARE AND MAINTENANCE Care and maintenance Care and maintenance Cleaning the Grille, Case and Remote Controller Turn the system off before cleaning. To clean, wipe with a soft, dry cloth. Do not use bleach or abrasives. Household Drain Cleaner NOTE: Supply power must be disconnectd before cleaning the indoor unit. - Page 12 CARE AND MAINTENANCE 4. Remove the Air Freshening Filter(Optional filter included: Plasma Dust Collector/ Silver Ion filter / Bio filter /Vitamin C filter/3M air purifier filter) from its support frame.(The removing and installation method are slightly difference, see the pictures marked on the left.
-
Page 13: Operation Tips
OPERATION TIPS The following events may occur during normal operation. Protection of the air conditioner. Compressor protection The compressor can't restart for 3 minutes after it stops. Anti-cold air (Cooling and heating models only) The unit is designed not to blow cold air on HEAT mode, when the indoor heat exchanger is in one of the following three situations and the set temperature has not been reached. - Page 14 OPERATION TIPS 7. Dripping water may generate on the surface of the indoor unit when cooling in a high relatively humidity (relative humidity higher than 80%). Adjust the horizontal louver to the maximum air outlet position and select HIGH fan speed. Heating mode (For cooling and heating models only) The air conditioner draws in heat from the outdoor unit and releases it via the indoor unit during heating operation.
-
Page 15: Troubleshooting Tips
TROUBLESHOOTING TIPS Troubleshooting Tips Stop the air conditioner immediately if one of the following faults occur. Disconnect the power and contact the nearest customer service center. If the following code appears on the LED window, disconnect the power and contact the service people: E0,E1,E2,E3,E4,E5,E6,E7,E8 or P0,P1,P2,P3,P4. - Page 16 CS011U-BP9V1 202000100311...
