Table A-1 C3G124-24P and C3G124-48P Specifications (continued)
Item
AC Input Specifications
Input Voltage
AC Volt Amps
C3G124-24P
C3G124-48P
Input Current
C3G124-24P
C3G124-48P
Phasing
Frequency
Environmental
Operating Temperature
Storage Temperature
Operating Relative Humidity

Mini-GBIC Input/Output Specifications

The Mini‐Gigabit Interface Card (Mini‐GBIC) port interface slots can support 1‐Gbps
fiber‐optic and copper connections as described in Table
are hot swappable.
Table A-2 Mini-GBIC Input/Output Port Specifications
Item
MGBIC-LC01
MGBIC-LC03
MGBIC-LC09
MGBIC-MT01
MGBIC-08
Specification
100–125 Vac or 200–240 Vac with automatic power sensing
539 VA
583 VA
4.9A at 110V, 2.5A at 220V
5.3A at 110V, 2.9A at 220V
Single-phase
50 to 60 Hz
0°C to 45°C (32°F to 113°F)
-40°C to 70°C (-40°F to 158°F)
5% to 95% (non-condensing)
Specification
Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-LX standard LC connector.
Provides one MT-RJ fiber-optic multi-mode port that is compliant with
the 1000BASE-SX standard MT-RJ connector.
Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-ELX standard LC connector.
Mini-GBIC Input/Output Specifications
A‐2. The optional Mini‐GBICs
SecureStack C3 Installation Guide A-3
