Chain Drive
Garage Door Opener
Models HD220, HD220C,
PD220, PD222, and LW260C
FOR RESIDENTIAL USE ONLY
INSTALL ON 7 FOOT
SECTIONAL DOORS ONLY
Register your new garage door opener at
www.prodregister.com/chamberlain or
scan the QR code with your smartphone
■ Please read this manual and the enclosed safety materials carefully!
■ Fasten the manual near the garage door after installation.
■ The door WILL NOT CLOSE unless the Protector System
properly aligned.
■ Periodic checks of the garage door opener are required to ensure safe operation.
■ The model number label is located on the back panel of your garage door opener.
■ This garage door opener is compatible with Security✚ 2.0™ accessories.
■ WARNING: To reduce the risk of injury to persons - Use this opener ONLY with a
7 foot sectional door.
®
is connected and
Write down the following information
for future reference:
Model Number:
Serial Number:
Date of Purchase:
CONTENTS
Preparation .............................. 1-4
Assembly ................................. 5-9
Installation ............................ 10-17
Install the Door Control ............. 18-19
®
...... 20-23
Power .................................. 24-25
Adjustments .......................... 26-28
Operation.................................. 29
Features ................................... 30
Remote Control .......................... 31
To Erase the Memory .................... 32
Maintenance .............................. 33
Diagnostic Chart ......................... 34
Warranty .................................. 35
www.chamberlain.com
The Chamberlain Group, Inc.
845 Larch Avenue
Elmhurst, Illinois 60126-1196

Advertisement

Table of Contents
loading

Summary of Contents for Chamberlain HD220

  • Page 1: Table Of Contents

    Preparation ......1-4 Chain Drive Assembly ......... 5-9 Garage Door Opener Installation ......10-17 Install the Door Control ..... 18-19 Models HD220, HD220C, Install the Protector System ® ..20-23 Power ........24-25 PD220, PD222, and LW260C Adjustments ......26-28 FOR RESIDENTIAL USE ONLY Operation........
  • Page 2: Preparation

    Preparation Safety Symbol and Signal Word Review Check the Door This garage door opener has been designed and tested to offer safe service provided it is installed, operated, maintained and tested in strict accordance with the instructions and warnings contained in this manual.
  • Page 3 Preparation Additional Items You May Need: Tools Needed Survey your garage area to see if you will need any of the following items: (2) 2X4 PIECES OF WOOD May be used to fasten the header bracket to the structural supports. Also used to position the garage door opener during installation and for testing the safety reversing sensors.
  • Page 4 Preparation Carton Inventory/Repair Parts Your garage door opener is packaged in one carton which contains the motor unit and all parts illustrated below. Accessories vary depending on the garage door opener model purchased. Depending on your model, other accessories may be included with your garage door opener. Instructions for these accessories will be attached to the accessory and are not included in this manual.
  • Page 5 Preparation Hardware 041A8068 ASSEMBLY INSTALLATION Self-Threading Screw Clevis Pin Lag Screw #14-10x1-1/2" (2) Lag Screw 5/16"-9x1-5/8" (2) 1/4"-20x1-3/4" (2) 5/16"x1-1/2" Clevis Pin 5/16"x1-1/2" Clevis Pin 5/16"x1" Clevis Pin 5/16"x1-1/4" Threaded Shaft Carriage Bolt Hex Nuts 5/16" (2) Hex Bolt 1/4"-20x3/4" (4) Self-Threading Screw 1/4"-20x1/2"...
  • Page 6: Assembly

    Assembly STEP 1 Assemble the rail and trolley SLIDE CHAIN SPREADER To prevent INJURY from pinching, keep hands and fingers away from the joints while assembling the ONTO RAIL Outer Trolley rail. Inner Trolley To avoid installation difficulties, do not run the garage door opener until instructed to do so. Chain The front rail has a cut out “window”...
  • Page 7 Assembly STEP 2 Fasten the rail to the motor unit IMPORTANT: Use ONLY the 1/4"-20x1-3/4" self-threading screws provided in a separate bag inside the hardware bag. To avoid SERIOUS damage to garage door opener, use ONLY the 1/4"-20x1-3/4" self-threading screws provided. 1.
  • Page 8 Assembly STEP 3 Install the pulley CORRECT 1. Lay the chain/cable beside the rail, as shown. Grasp the end with the cable loop and pass approximately 12" (30 cm) of cable through the window. Allow it to hang until Assembly Step 4. 2.
  • Page 9 Assembly STEP 4 Install the chain Figure 1 Figure 2 To avoid possible SERIOUS INJURY to finger from moving garage door opener: Sprocket ALWAYS keep hand clear of sprocket while operating opener. Securely attach chain spreader BEFORE operating. 1. Pull the cable around the idler pulley and toward the trolley. 2.
  • Page 10 Assembly STEP 5 Tighten the chain Trolley Outer Lock Threaded Washer Shaft To Tighten Outer Nut 1. Spin the inner nut and lock washer down the trolley threaded shaft, away from the trolley. 2. To tighten the chain, turn the outer nut in the direction shown. 3.
  • Page 11: Installation

    Installation IMPORTANT INSTALLATION INSTRUCTIONS To reduce the risk of SEVERE INJURY or DEATH: 1. READ AND FOLLOW ALL INSTALLATION WARNINGS AND INSTRUCTIONS. 8. NEVER wear watches, rings or loose clothing while installing or servicing opener. They could be 2. Install garage door opener ONLY on properly balanced and lubricated garage door. An caught in garage door or opener mechanisms.
  • Page 12 Installation STEP 1 Determine the header bracket location OPTIONAL CEILING MOUNT Header Wall FOR HEADER BRACKET Vertical Centerline of Garage Door Structural Supports Unfinished Ceiling To prevent possible SERIOUS INJURY or DEATH: Header bracket MUST be RIGIDLY fastened to structural support on header wall or ceiling, otherwise garage door might NOT reverse when required.
  • Page 13 Installation STEP 2 Install the header bracket OPTION B CEILING INSTALLATION You can attach the header bracket either to the wall above the garage door, or to the ceiling. Follow the instructions which will work best for your particular requirements. Do not install the header bracket over 1.
  • Page 14 Installation STEP 3 Attach the rail to the header bracket STEP 4 Position the garage door opener 1. Align the rail with the header bracket. Insert the clevis pin through the holes in the header bracket and rail. Secure with the ring fastener. NOTE: Use the packing material as a protective base for the garage door opener.
  • Page 15 Installation 1. On finished ceilings, use the #14-10x1-1/2" lag screws to attach a support bracket (not provided) STEP 5 Hang the garage door opener to the structural supports before installing the garage door opener. 2. Make sure the garage door opener is aligned with the header bracket. Measure the distance from each side of the garage door opener to the support bracket.
  • Page 16 Installation STEP 6 Install the light bulb STEP 7 Attach the emergency release rope and handle To prevent possible OVERHEATING of the end panel or light socket: To prevent possible SERIOUS INJURY or DEATH from a falling garage door: Use ONLY A19 incandescent (60W maximum) or compact fluorescent (23W maximum) light If possible, use emergency release handle to disengage trolley ONLY when garage door is bulbs.
  • Page 17 Installation Metal or light weight doors using a vertical angle iron brace between the door panel support and STEP 8 Install the door bracket the door bracket: Drill 3/16" fastening holes. Secure the door bracket using the two 1/4"-14x5/8" self threading screws.
  • Page 18 Installation STEP 9 Connect the door arm to the trolley CORRECT INCORRECT IMPORTANT: The groove on the straight door arm MUST face away from the curved door arm. Straight 1. Close the door. Disconnect the trolley by pulling the emergency release handle. Straight Door Curved...
  • Page 19: Install The Door Control

    Installation 1. Strip 1/4" (6 mm) of insulation from one end of the wire and separate the wires. STEP 10 Install the door control 2. Connect one wire to each of the two screws on the back of the door control. The wires can be connected to either screw.
  • Page 20 Installation STEP 11 Wire the door control to the garage door opener STEP 12 Attach the warning labels 1. Attach the entrapment warning label on the wall near the door control with tacks or staples. 2. Clean surface and attach the manual release/safety reverse test label in a visible location on the HARDWARE inside of the garage door.
  • Page 21: Install The Protector System

    Installation ® STEP 13 Install the Protector System HARDWARE Carriage Bolt Wing Nut 1/4"-20x1/2" 1/4"-20 Be sure power is NOT connected to the garage door opener BEFORE installing the safety reversing The safety reversing sensors can be attached to the door track, the wall, or the floor. The sensors should sensor.
  • Page 22 Installation ® STEP 13 Install the Protector System (continued) OPTION C FLOOR INSTALLATION OPTION B WALL INSTALLATION Use an extension bracket (not provided) or wood block to raise the sensor bracket if needed. If additional clearance is needed an extension bracket (not provided) or wood blocks can be used. Make 1.
  • Page 23 Installation STEP 14 Wire the Safety Reversing Sensors If your garage already has wires installed for the safety reversing sensors, proceed to page 23. Staple HARDWARE Insulated Staple 7/16" (11 mm) (Not Shown) OPTION A INSTALLATION WITHOUT PRE-WIRING 1. Run the wire from both sensors to the garage door opener. Attach the wire to the wall and ceiling with the staples.
  • Page 24 Installation STEP 14 Wire the Safety Reversing Sensors (continued) Pre-installed OPTION B PRE-WIRED INSTALLATION Safety reversing wires 7/16" sensor wires (11 mm) 1. Cut the end of the safety reversing sensor wire, making sure there is enough wire to reach the pre-installed wires from the wall.
  • Page 25: Power

    Installation STEP 15 Connect power OPTION B PERMANENT WIRING If permanent wiring is required by your local code, refer to the following procedure. To make a permanent connection through the 7/8 inch hole in the top of the motor unit (according to local code): To prevent possible SERIOUS INJURY or DEATH from electrocution or fire: 1.
  • Page 26 Installation STEP 16 Aligning the safety reversing sensors IF THE AMBER LED ON THE SENDING SENSOR IS NOT GLOWING: 1. Make sure there is power to the garage door opener. The door will not close if the sensors have not been installed and aligned correctly. 2.
  • Page 27: Adjustments

    Adjustments Introduction Programming Buttons Programming Buttons The programming buttons are located on the left side panel of the garage door opener and are used to program the travel. While programming, the UP and DOWN buttons can be used to move the door as needed.
  • Page 28: Program Travel

    Adjustments STEP 1 Program the Travel PROGRAMMING BUTTONS UP Button Adjustment Without a properly installed safety reversal system, persons (particularly small children) could be Button SERIOUSLY INJURED or KILLED by a closing garage door. Incorrect adjustment of garage door travel limits will interfere with proper operation of safety DOWN Button reversal system.
  • Page 29 Adjustments ® STEP 2 Test the Safety Reversal System STEP 3 Test the Protector System Without a properly installed safety reversal system, persons (particularly small children) could be Without a properly installed safety reversing sensor, persons (particularly small children) could be SERIOUSLY INJURED or KILLED by a closing garage door.
  • Page 30: Operation

    Operation IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of SEVERE INJURY or DEATH: 1. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS. 9. After ANY adjustments are made, the safety reversal system MUST be tested. 2. ALWAYS keep remote controls out of reach of children. NEVER permit children to operate or 10.
  • Page 31: Features

    Operation Features LIGHTS Your garage door opener is equipped with features to provide you with greater control over your garage The garage door opener light bulb(s) will turn on when the opener is initially plugged in; power is door operation. restored after interruption, or when the garage door opener is activated.
  • Page 32: Using Garage Door Opener

    Your remote control has been programmed at the factory to operate with your garage door opener. wireless keyless entry. Older Chamberlain remote controls are NOT compatible. Programming can be done through the learn When the door is closed and the garage door opener is activated the door will open. If the door senses button on the garage door opener.
  • Page 33: To Erase The Memory

    Operation To Erase the Memory To Open the Door Manually ERASE ALL REMOTE CONTROLS AND KEYLESS ENTRIES 1. Press and hold the LEARN button on garage door opener until the learn LED goes out (approximately 6 seconds). All remote control and keyless entry codes are now erased. Reprogram any accessory you wish to use.
  • Page 34: Maintenance

    Maintenance Maintenance Schedule Repair Parts EVERY MONTH Description Part No. • Manually operate door. If it is unbalanced or binding, call a trained door systems technician. • Check to be sure door opens and closes fully. Adjust if necessary, see page 26. 1 Logic board 047DCT •...
  • Page 35: Troubleshooting

    Troubleshooting Diagnostic Chart Your garage door opener is programmed with self-diagnostic capabilities. The UP and DOWN arrows on the garage door opener flash the diagnostic codes. NOTE: For troubleshooting questions, please visit www.chamberlain.com. SYMPTOM SOLUTION DIAGNOSTIC CODE Up Arrow Down Arrow...
  • Page 36: Warranty

    STOP! SIX-YEAR MOTOR LIMITED WARRANTY The Chamberlain Group, Inc. (“Seller”) warrants to the fi rst retail purchaser of this product, for the residence This garage door opener WILL NOT work until the in which this product is originally installed, that it is free from defect in materials and/or workmanship for safety reversing sensors are properly installed and aligned.
