Icom IC-E90 Service Manual page 37

[AF UNIT]
REF ORDER
NO. NO.
J252 6450001680 CONNECTOR
J253 6450002250 CONNECTOR
S251 7600000210 ENCODER
W1 7030010040 S.JUMPER
W2 7030010040 S.JUMPER
W3 9014505003 WIRE
EP1 0910054435 PCB
EP3 6910012350 S.BEAD
EP4 6910012350 S.BEAD
EP5 6910012350 S.BEAD
EP6 6910013310 S.BEAD
EP7 6910013310 S.BEAD
EP8 6910013310 S.BEAD
[LOGIC UNIT]
REF ORDER
NO. NO.
IC1 1140010710 S.IC
IC2 1140009240 S.IC
IC5 1130006220 S.IC
IC91 1130007110 S.IC
IC92 1130007020 S.IC
IC141 1180002150 S.IC
IC142 1110005730 S.IC
IC241 1110003800 S.IC
Q1 1590001690 S.TRANSISTOR UN9115 (TX)
Q2 1590001690 S.TRANSISTOR UN9115 (TX)
Q3 1590001400 S.TRANSISTOR XP1214 (TX)
Q4 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q6 1590001400 S.TRANSISTOR XP1214 (TX)
Q8 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q9 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q10 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q11 1590001140 S.TRANSISTOR UN9210 (TX)
Q40 1590001860 S.TRANSISTOR UN9215 (TX)
Q91 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q141 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q142 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q145 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q146 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q147 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q151 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q201 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q202 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q301 1590002380 S.TRANSISTOR XP1115 (TX)
Q302 1520000430 S.TRANSISTOR 2SB1462-R (TX)
Q304 1550000010 S.FET
Q305 1550000010 S.FET
Q307 1590001440 S.TRANSISTOR UN9214 (TX)
Q310 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q311 1590001210 S.TRANSISTOR XP5601-(TX) .AB
Q312 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q342 1550000010 S.FET
Q343 1550000010 S.FET
Q451 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
D5 1790000860 S.DIODE
D6 1790000670 S.DIODE
D51 1790000820 S.DIODE
1790000830 S.DIODE
1790000850 S.DIODE
D52 1790000820 S.DIODE
1790000830 S.DIODE
1790000850 S.DIODE
D53 1790000850 S.DIODE
DESCRIPTION
HSJ1122-010010
HSJ1456-010320
TP70N00E20-15F-1903
ERJ2GE-JPW
ERJ2GE-JPW
22/07/070/W02/W02
B 5735E
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608D121B
MMZ1608D121B
MMZ1608D121B
DESCRIPTION
M30220MA-114RP
HN58X24128FPI
TC4W53FU (TE12L)
TC7W04FU (TE12L)
TC7S66FU (TE85R)
NJM2370U32-TE1
S-80928CNMC
NJM2904V-TE1
2SJ364-Q (TX)
2SJ364-Q (TX)
2SJ364-Q (TX)
2SJ364-Q (TX)
MA133 (TX)
SB07-03C-TB
MA132K (TX)
[EUR], [EUR-1], [ESP] only
MA132HK (TX) [UK] only
MA132WK (TX) [FRA] only
MA132K (TX) [ITR] only
MA132HK (TX) [FRA] only
MA132WK (TX) [ESP] only
MA132WK (TX)
[LOGIC UNIT]
REF ORDER
NO. NO.
D54 1790001250 S.DIODE
D56 1790001250 S.DIODE
D57 1790001250 S.DIODE
D58 1790001200 S.DIODE
D91 1790001560 S.DIODE
D141 1790001250 S.DIODE
D143 1790001250 S.DIODE
D152 1790001250 S.DIODE
D253 1790001250 S.DIODE
D300 1790001560 S.DIODE
D301 1790001560 S.DIODE
D302 1790001560 S.DIODE
X1 6050011080 S.XTAL
L24 6200003640 S.COIL
L140 6200003640 S.COIL
R1 7510001660 S.THRMISTOR NTCG16 4LH 473KT
R2 7030005090 S.RESISTOR
R4 7030008280 S.RESISTOR
R5 7030008280 S.RESISTOR
R8 7030005240 S.RESISTOR
R9 7030005310 S.RESISTOR
R10 7030005050 S.RESISTOR
R11 7030000150 S.RESISTOR
R12 7030005240 S.RESISTOR
R13 7030005240 S.RESISTOR
R14 7030005240 S.RESISTOR
R15 7030000150 S.RESISTOR
R16 7030005120 S.RESISTOR
R17 7030005120 S.RESISTOR
R18 7030010390 S.RESISTOR
R19 7030005050 S.RESISTOR
R20 7030010370 S.RESISTOR
R21 7030005120 S.RESISTOR
R22 7030004980 S.RESISTOR
R23 7030005120 S.RESISTOR
R24 7030004980 S.RESISTOR
R27 7030005240 S.RESISTOR
R28 7030005120 S.RESISTOR
R29 7030010380 S.RESISTOR
R32 7030004980 S.RESISTOR
R33 7030005120 S.RESISTOR
R34 7030004980 S.RESISTOR
R35 7030005120 S.RESISTOR
R38 7030005090 S.RESISTOR
R39 7030005240 S.RESISTOR
R40 7030008010 S.RESISTOR
R42 7030005010 S.RESISTOR
R43 7030009160 S.RESISTOR
R46 7030005710 S.RESISTOR
R47 7030005710 S.RESISTOR
R51 7030005160 S.RESISTOR
R53 7030005070 S.RESISTOR
R54 7030005050 S.RESISTOR
R55 7030008270 S.RESISTOR
R56 7030005040 S.RESISTOR
R61 7030005010 S.RESISTOR
R62 7030004990 S.RESISTOR
R63 7030005010 S.RESISTOR
R64 7030004990 S.RESISTOR
R65 7030005010 S.RESISTOR
R66 7030004990 S.RESISTOR
R67 7030005010 S.RESISTOR
R68 7030004990 S.RESISTOR
R69 7030005010 S.RESISTOR
R70 7030004990 S.RESISTOR
R71 7030005010 S.RESISTOR
R72 7030004990 S.RESISTOR
R73 7030005010 S.RESISTOR
R74 7030004990 S.RESISTOR
R75 7030005040 S.RESISTOR
R80 7030005080 S.RESISTOR
R81 7030005080 S.RESISTOR
R82 7030005720 S.RESISTOR
R83 7030005720 S.RESISTOR
R84 7030005310 S.RESISTOR
6 - 6
DESCRIPTION
MA2S111-(TX)
[EUR-1], [ESP], [FRA] only
MA2S111-(TX)
MA2S111-(TX) [EUR-1], [ESP] only
MA6S121 (TX)
1SS372 (TE85R)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
1SS372 (TE85R)
1SS372 (TE85R)
1SS372 (TE85R)
CR-687 (6.7584 MHz)
MLF1608E 100K-T
MLF1608E 100K-T
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 103 X (10 kΩ)
MCR10EZHJ 12 Ω (120)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
MCR10EZHJ 12 Ω (120)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERA3YED 821V
ERJ2GEJ 103 X (10 kΩ)
ERJ2RHD 561 X (560 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2RHD 471 X (470 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 181 X (180 Ω)
ERJ2GEJ 121 X (120 Ω)
ERJ2GEJ 121 X (120 Ω)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 103 X (10 kΩ)
RR0510R-104-D (100 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 124 X (120 kΩ)
S.=Surface mount
