MAINTAINING YOUR VEHICLE
The Integrated Power Module is located in the engine compartment near the battery.
This center contains cartridge fuses and mini fuses. A description of each fuse and
component may be stamped on the inside cover, otherwise the cavity number of each
fuse is stamped on the inside cover that corresponds to the following chart.
Cavity Cartridge Fuse
J01 40 Amp Green
J02 30 Amp Pink
J04 25 Amp Natural
J05 25 Amp Natural
J06 40 Amp Green
J07 30 Amp Pink
J08 40 Amp Green
J09 40 Amp Green
J10 30 Amp Pink
J11 30 Amp Pink
J12 30 Amp Pink
J13 60 Amp Yellow
J14 20 Amp Blue
J15 40 Amp Green
J17 40 Amp Green
J19 60 Amp Yellow
J20 30 Amp Pink
J21 20 Amp Blue
J22 25 Amp Natural
M1
M5
M6
M7
M8
M9
M10
M11
M12
142
Mini Fuse
Trailer Tow
Electric Brake
Driver Door Node
Passenger Door Node
Antilock Brakes Pump/Stability
Control System
Antilock Brakes Valve/Stability
Control System
Power Seat
Flex Fuel
Sway Bar Equipped Module –
If Equipped
Transfer Case Module
Rear Defroster
Main Ignition Off Draw (IOD) Fuse
Trailer Tow Lamps/Park Lamps
Front Blower
Starter Motor Solenoid
Rad Fan Motor HI/Rad Fan
Motor Low
Front Wiper Ground/Low/High
Washer Control
Sunroof Module
15 Amp Blue Stop Switch Lamp
25 Amp Natural 115V AC Inverter
20 Amp Yellow Power Outlet (Instrument Panel or
Front Console)/Rain Snsr
20 Amp Yellow Power Outlet (Rear Console or
Center Seat)
20 Amp Yellow Front Heated Seat & Steering Wheel
20 Amp Yellow Rear Heated Seats
15 Amp Blue Hands Free Module/Vanity Lamp/
Universal Garage Door Opener
Module
10 Amp Red Climate Control System
30 Amp Green Radio/Amplifier
Description
