Amana AGS730 Service Manual

Gas ranges

Hide thumbs Also See for AGS730:

Use and care manual (19 pages)

Table Of Contents

Table of Contents

Quick Links

Troubleshooting

Summary of Contents for Amana AGS730

Page 1 P1141253N RSK3700U P1141270N RSK3700U P1143310N This manual is to be used by qualified appliance technicians only. Amana does not assume any responsibility for property damage or personal injury for improper service procedures done by an unqualified person. RB231001 Revision 4...
Page 2 (such as exposure to electrical shock) may result. CAUTION Amana will not be responsible for any injury or property damage from improper service procedures. If performing service on your own product, assume responsibility for any personal injury or property damage which may result.
Page 3: Table Of Contents
History of Changes ..............................6 Burner Specifications ............................. 6 Electrical Specifications ............................6 General Features ..............................6 Amana Cooking Products Nomenclature ......................7 Caloric Cooking Products Nomenclature ....................... 7 Safety Precautions ..............................8 Installation Cabinet Cutout and Clearances ..........................9 Anti-Tip Bracket Installation ...........................
Page 4: Rb231001 Rev
Introduction Introduction Clock Timer Operation Operating Instructions for Analog Clock/Timer ....................21 Setting Time of Day ............................21 Setting Minute Timer ............................. 21 Setting Oven to Stop Automatically ......................21 Setting Oven to Start and Stop Automatically ....................21 Setting Self-Cleaning Cycle .......................... 21 Clock Switch Function Chart .........................
Page 5 Oven Burner Ignitor ............................. 43 Broil Burner Ignitor ............................... 43 Oven Electric Gas Valve ............................43 Broiler Burner ............................... 43 Bar Broil Burner (AGS730 models) ........................44 Oven Burner ................................ 44 Oven Bottom ............................... 44 Oven Lamp ................................44 Socket-Oven Lamp .............................. 44 Oven Sensor Probe .............................
Page 6: General Information
AGS751, AGS761, AGS781, RSF3410 authorized Amana service technicians to install and BTU Input Natural Gas LP Gas service Amana and Caloric free standing gas ranges. Large Burner 9,100 8,000 There may be, however, some parts which need fur- Small Burner...
Page 7: Amana Cooking Products Nomenclature
Introduction Amana Cooking Products Nomenclature Color Product Group Product Type Amana Features No Designator - Ebony A - Amana DG1 - Downdraft 2H - Halogen Range Features - Variable Gas Range Chrome Top Gas Cooktop, Smoothtop Cooktop Width Electric Range...
Page 8: Safety Precautions
Introduction Oven Safety Precautions 1. Use care when opening the oven door. Let hot air or General steam escape before removing or replacing food. 1. The range must be installed and properly grounded by a qualified installer or service technician. 2.
Page 9: Installation
Installation Cabinet Cutout and Clearances Prepare the cutout as shown below. • The range must be installed flush to the rear wall. It can be installed flush with the side cabinets if 5-1/8" desired. • The space between the side wall and the range top must be a minimum of three inches.
Page 10: Make The Gas Connection
Installation Location of the Gas Supply Stub Make the Gas Connection When using hard piping to connect the range to the Before connecting this appliance to the gas supply supply gas, the stub must be located as shown in the system, the installation must conform with local codes following diagram.
Page 11: Flexible Connector
Installation Flexible Connector Electrical Connection The gas connection can also be made with an AGA or The installation of this product must conform with local CGA design certified flexible connector, two adapters codes or in the absence of local codes, with the and a manual gas shut-off valve.
Page 12: Final Gas Connection
Installation Final Gas Connection Make the final gas connection as illustrated previously. When using hard piping, make the final connection at the union. When using flexible connector make the final connection at the adapter. Test for Gas Leaks 1. After making the gas connection, close all top burners valves and turn on the gas supply.
Page 13: Adjust Oven Burner Flame Shape
Installation ® ® Ultra-Ray , Insta-Broil Broiler Flame Top Burner Flame Appearance Adjusting the Shape of the Bar Broil Flame Adjust Oven Burner Flame Shape The flame should be 1/2-inch long with a dark blue 1. The flame should be approximately 1/2-inches inner cone and bluish-green outer cone.
Page 14: Converting From Natural Gas To Lp Gas
Converting from Natural Gas to LP Gas Example Two 1. Remove pressure regulator cap with an appropriate Amana and Caloric ranges are equipped to use either wrench. natural or LP gas. They are, however, set at the factory to use natural gas. Some components must be 2.
Page 15: Converting Top Burners
Installation Example Seven Example Four 1. Remove cap with screwdriver slot. 1. Remove cap marked “Nat.” 2. Remove spring and washer. Washer will be at 2. Reverse cap. “LP” now appears on cap. bottom of spring as illustrated below. 3. Reinsert cap. Do not disturb spring beneath the 3.
Page 16: Converting The Insta-Broil And Ultra-Ray Broilers
Installation Converting the Insta-Broil and Ultra-Ray Broilers Converting the Bar Broil Burner (Models at and After 1. The broiler burner orifice spud must be changed. Date Code 9409) The LP/propane gas spud is wired adjacent to the 1. Remove oven door. Locate bar broil burner in top pressure regulator.
Page 17: General Use
General Use Clock and Timer Using the Cooktop Analog Clock • Use the Proper Pan Size Setting Time of Day Use cooking utensils with flat bottoms large Push in set knob. enough to cover the flame. Correct-sized utensils improve cooking efficiency and promote safety. Rotate knob to desired time of day.
Page 18: Operating The Oven
General Use Operating the Oven Changing Oven Light Wear gloves to protect hands when changing the Oven operation for baking, broiling, timed bake and bulb. self-cleaning can be found in the Clock Timer Opera- tion section. Disconnect power to range. Remove oven door.
Page 19: Thermostat Adjustment
General Use Thermostat Adjustment Set controls to bake. Turn oven thermostat control to 350 degrees F. Allow oven to cycle for 25 to 30 min- About Oven Temperature Performance utes. Note the temperature at which the oven cycles The factory designs ovens to maintain an average on and off.
Page 20: Self-Clean Temperature Calibration, Clean Temperature Limits
ERC components. Record the overall average temperature obtained on the warranty claim form for reference and to assist the Amana warranty department. RB231001 Rev. 4...
Page 21: Operating Instructions For Analog Clock/Timer
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 22: Erc Iii Auto-Latch Features
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 23: Bake Function
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 24: Stop Time Function
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 25: Broil Function
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 26: Delayed Self-Clean Function
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 27: Service Information - Erc Iii With Auto Latch System
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 28: Erc Voltage Testing
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 29: Testing Procedures
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 30: Erc Voltage Testing - Erciii Manual Latch
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 31: Vac Test Points
Clock Timer Operation To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 32: Service Procedures
Service Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 33: Oven Thermostat
Service Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 34: Selector Switch
Service Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 35: Spark Module Testing
Service Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 36: Door Latch Mechanism
Service Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 37: Fluorescent Light System
Service Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 38: Sealed Burner Troubleshooting
Troubleshooting Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 39: All Models - Top Burner, Bake And Broil Burner Troubleshooting
Troubleshooting Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 40: Troubleshooting Procedures
Troubleshooting Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 41 Troubleshooting Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 42 Troubleshooting Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 43: Disassembly Procedures
Disassembly Procedures Disassembly Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 44: Bar Broil Burner (Ags730 Models)
Bar Broil Burner (AGS730 models) Oven Lamp 1. Disconnect electricity at main disconnect plug. 1. Disconnect electricity at main disconnect plug.
Page 45: Oven Sensor Probe
Disassembly Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 46: Fluorescent Lamp
5. Push in and turn starter counterclockwise to re- move. 4. Lift top burner venturi off top burner valve orifice. 6. Replace starter. Control Panel (AGS730 Models) Starter Socket 1. Turn off power to range. 1. Follow fluorescent light starter instructions, Steps 2.
Page 47: Spark Module
Disassembly Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 48: Oven Thermostat
Disassembly Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 49: Storage Drawer - Storage Drawer Tracks
Disassembly Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 50: Bottom Brace
Disassembly Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 51: Oven Door Gasket
Disassembly Procedures To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 52: Wiring Diagrams And Schematics
Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 53 Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 54 Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 55 Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 56 120VAC 3 SOCKET CAP 60HZ NOTES: W iring D iagram 309566 1. ALL WIRES 18GA. 150°C XL UNLESS OTHERWISE NOTED. AGS730 P1141258N, P1141263N, P1141268N, P1143301N RSSF3410 P1141257N, P1141269N, P1143309N RSF3300 P1141256N, P1141265N, P1141272N, P1143308N RSF3200 P1141255N, P1141264N, P1141271N,P1143307N RB231001 Rev. 4...
Page 57 CLOCK OFF, DOOR UNLATCHED. * CLOSED ONLY BETWEEN DENOTES OPTIONAL EQUIPMENT START TIME & STOP TIME AND RELATED WIRING NOT SETTINGS. SUPPLIED ON SOME MODELS. AGS730 P1141258N, P1141263N, P1141268N, P1143301N RSSF3410 P1141257N, P1141269N, P1143309N RSF3300 P1141256N, P1141265N, P1141272N, P1143308N RSF3200 P1141255N, P1141264N, P1141271N,P1143307N RB231001 Rev.
Page 58 Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 59 Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 60 Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
Page 61 Wiring Diagrams and Schematics To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power To avoid the risk of electric shock, personal injury or death, disconnect power WARNING...
