OP E R A T ION MA NUA L
R e m o t e c o n t ro lle r
B R C 1D619

Advertisement

loading

Related Manuals for Daikin BRC1D619

Summary of Contents for Daikin BRC1D619

  • Page 1 OP E R A T ION MA NUA L R e m o t e c o n t ro lle r B R C 1D619...

  • Page 4: Table Of Contents

    BRC1D61 Remote controller Operation manual 1. Features and functions THANK YOU FOR PURCHASING THIS The BRC1D61 is a state of the art remote controller CONTROLLER. READ MANUAL that offers full control over your installation. ATTENTIVELY BEFORE USING INSTALLATION. AFTER READING THE BASIC REMOTE CONTROLLER MANUAL, STORE IT IN A SAFE PLACE FOR FUTURE USE.

  • Page 5: Name And Function Of Switches And Icons

    LEAVE HOME AIR CLEANING ICON The leave home function prevents the room This icon indicates that the air cleaning unit (option) is temperature from dropping when the occupants are operational. out for a longer period. If the room temperature drops below 10°C, heating is started automatically.
  • Page 6 MAXIMUM SET TEMPERATURE NOT AVAILABLE maximum temperature indicates is displayed whenever a non-installed option maximum set temperature when in limit operation. is addressed or a function is not available. MINIMUM SET TEMPERATURE FAN SPEED ICON The minimum set temperature indicates the minimum This icon indicates the set fan speed.

  • Page 7: Setting Up The Controller

    SCHEDULE TIMER BUTTON AIR FILTER CLEANING TIME ICON RESET BUTTON This button enables or disables the schedule timer. This button is used to reset the air filter cleaning time TIME ADJUST BUTTON icon. These buttons are used to adjust the clock or, when in 3.

  • Page 8: Description Of The Operation Modes

    4. Description of the operation modes Defrost (heat pump types only) In heating operation, freezing of the outdoor heat FAN ONLY OPERATION exchanger may occur. If so, the heating capacity of In this mode, air only circulates without heating or the system lowers and the system goes into defrost cooling.
  • Page 9 Use the button to select the desired operation AUTOMATIC OPERATION mode. User adjustable parameters: • Setpoint temperature, use the & Fan only operation buttons, Dry operation • Fan speed, use the button, Automatic operation • Air flow direction adjust, use the button, Cooling operation •...
  • Page 10 ADDITIONAL FEATURES OF THE CONTROLLER NOTE The schedule timer overrules the LEAVE HOME button, only use the button to enable or disable the schedule timer. The Press buttons schedule timer is enabled when the simultaneously to enable the LEAVE HOME function. icon is visible.

  • Page 11: Limit Operation

    What can the schedule timer do? • switch off the installation (the schedule timer The concept of the schedule timer is simple, remains enabled and reactivates the straightforward though powerful. installation as programmed); the operation The schedule timer can order 3 actions: lamp will turn off, 1 switch on the installation at a scheduled time, in •...
  • Page 12 button is used to exit browsing at once Continue pressing the button until the day of the (without having to scroll through all programmed week indicator displays the current day (not blinking), actions). you have now quit browsing. Press the button to enter the browse mode, the NOTE The number of times that the...

  • Page 13: Programming The Schedule Timer

    Getting started Programmed actions might overlap; due to the "last command overrules" logic, the last scheduled Programming the schedule timer is flexible (you can command will rule. add, remove or alter programmed actions whenever required) and straightforward (programming steps are limited to a minimum).
  • Page 14 Programming In this particular case, no actions have been program- med before, all schedule timer actions are idle. • Browse to Monday by pressing the button. THE SCHEDULE TIMER IS PROGRAMMED icon appears, will blink and one of FOR THE FIRST TIME icons might be displayed but all other fields remain blank, indicating that NOTE...
  • Page 15 If the action and the corresponding time are correct, Program mode is quit and depending on the choice you can proceed to the second schedule timer action. made, the programmed actions are saved for Monday This is done by pressing the button, the data is (and possibly Tuesday).

  • Page 16: Troubleshooting

    8. Troubleshooting I WANT TO DELETE ONE OR MORE PROGRAMMED ACTIONS The guidelines below might help to solve your Make sure you are not in program mode ( problem. If you cannot remedy the problem, consult blinking); if required, press to quit program your installer.
