- Page 1 COLOR TELEVISION XENTIA 72 FLAT MF 72-490 DOLBY ENGLISH...
-
Page 2: Table Of Contents
CONTENTS __________________________________________________________________________ XENTIA 72 Flat MF 72-490 DOLBY Special features of your TV set Scope of delivery Installation and Safety At a Glance The front of the TV set The back of the TV set The remote control Connection and Preparation... - Page 3 CONTENTS __________________________________________________________________________________ Programming the Remote Control Programming function levels Reset Customer Information Technical data Service information for the specialized dealer Contact assignment for the EURO-AV socket Correcting Problems Yourself...
-
Page 4: Xentia 72 Flat Mf 72-490 Dolby
XENTIA 72 FLAT MF 72-490 DOLBY __________________ Special features of your TV set Technology Super flat 72 cm colour picture tube (visible picture: 68 cm) 100 Hertz technology GRUNDIG Megalogic Megalogic possibilities: – Perfect compatibility with the Megalogic video recorder. No troublesome programming of channel positions. -
Page 5: Scope Of Delivery
XENTIA 72 FLAT MF 72-490 DOLBY ____________________________________ Scope of delivery TV set XENTIA 72 Flat MF 72-490 DOLBY Remote control 2 batteries, 1.5 V–, Mignon (AA) User manual Mains cable COLOR TELEVISION TV-GUIDE... -
Page 6: Installation And Safety
INSTALLATION AND SAFETY _______________________________ In order to assure that this high-quality and easy-to-use TV set will be able to provide you with good service and pleasure for a long time to come, it is impor- tant that you observe the following points when installing the set. This set has been designed for the reception and reproduction of picture and sound signals. - Page 7 INSTALLATION AND SAFETY ___________________________________________________ Do not open the TV set under any circumstance. The manufacturer will offer no liability for damage resulting from unauthorized tampering. Be sure that the mains cable is not damaged at any time. Storms represent a danger for every type of electrical device. Even if the set is switched off, it could be damaged by a lightning strike hitting the mains and/or the aerial lead.
-
Page 8: At A Glance
AT A GLANCE ___________________________________________________________________ The front of the TV set S-VIDEO VIDEO IN L AUDIO R S-VIDEO VIDEO IN L AUDIO R Switches the TV set on/off. – Volume – Select channel up/down. SVHS video input for camcorder. S-VIDEO Video input for camcorder. VIDEO IN L AUDIO R Audio input for camcorder. -
Page 9: The Back Of The Tv Set
AT A GLANCE _____________________________________________________________________________ The back of the TV set AUDIO IN Mains cable connection socket. PC connection socket. VGA / L AUDIO IN R Euro/AV socket. AV 1 Euro/AV socket. Output sockets for hifi system. R AUDIO L É Aerial input (for house aerial). -
Page 10: The Remote Control
AT A GLANCE _____________________________________________________________________________ The remote control You can use the TP 850 C remote control supplied not only with the TV set, but also with a video recorder, a satellite receiver and a DVD player. Note: Your TV set is equipped with a programmable remote control. Programming of the remote control is described from page 20. - Page 11 AT A GLANCE _____________________________________________________________________________ Picture settings, calls up the »PICTURE SETTINGS« menu. Clock time on/off. TV-GUIDE Still picture. Sound settings, calls up the »SOUND SETTINGS« menu. Colour contrast. Brightness. TV picture in teletext. Brief instructions Picture format switch-over Preselection button for various functions.
- Page 12 Stop Reverse picture search. Forward picture search. Fast reverse. Fast forward. Note: Just try out which functions of your GRUNDIG device can be controlled. Functions which cannot be controlled on your GRUNDIG device can easily be programmed (see page 20).
-
Page 13: Connection And Preparation
CONNECTION AND PREPARATION _______________ Sample connection with video recorder, satellite receiver and decoder AUDIO IN Videorecorder 2 EXTERNAL / DEC. - AV 2 AUDIO 1 EXTERNAL / EURO - AV 1 Satellitenreceiver Decoder PAY-TV 220-240 V EURO AV TV EURO AV DECODER EURO AV VCR 50-60 Hz INPUT-SAT... -
Page 14: Connecting A Pc
CONNECTION AND PREPARATION _______________________________________ Connecting a PC (VGA) You can use the TV set as a PC monitor. The television set can set itself to the following input signals: 640 x 480 Pixel, 60 Hz/31.5 kHz 640 x 400 Pixel, 70 Hz/31.5 kHz 640 x 350 Pixel, 70 Hz/31.5 kHz AUDIO IN Connect the VGA source (e.g. -
Page 15: Connecting A Hifi System Or Active Loudspeakers
CONNECTION AND PREPARATION _______________________________________ Connecting a hifi system or active loudspeakers Instead of using the television speakers as front speakers, you can use the loud- speakers of your hifi system or active front speakers. AUDIO IN Connect the hifi system or the active left/right speakers to the »L AUDIO R«... -
Page 16: Settings
SETTINGS ______________________________________________________________________________ Switching the TV set on/off An LED next to the mains switch indicates the current operating mode by a corresponding colour. Operation. Green Standby (EPG mode, copy mode). Yellow Standby (energy saving mode, timer programmed). Switching the TV set on Press »IO«... -
Page 17: Programming Tv Channels
SETTINGS ____________________________________________________________________________________ Programming TV channels The TV set is equipped with the automatic tuning system “ATS euro plus” which carries out channel position assignment for you. After switching on the TV set, select he »English« dialog language and con- firm with »OK«. Note: If the »Select dialog language«... -
Page 18: Easy Dialog System
EASY DIALOG SYSTEM _____________________________________________ The Easy Dialog System Your TV set is equipped with the Easy Dialog System. That means that operating instructions are not, as is usual, in a printed manual, but rather appear on the screen as dialog fields. The Dialog Centre The Dialog Centre is the control centre for your TV set. -
Page 19: Operating The Easy Dialog System
EASY DIALOG SYSTEM _____________________________________________________________ Operating the Easy Dialog System Move the yellow bar up/down. With two-paged menus, the second page will be turned to. Change settings. Calls up or confirms selected functions. Back to TV picture. Acces to the Dialog Centre (with » «... -
Page 20: Programming The Remote Control
DVD players (DVD). For this, you need the other appliance’s remote control. Note: The TV function level is programmed only for GRUNDIG TV sets and cannot be reprogrammed. In exceptional cases, it could happen that the TP 850 C can not learn the... -
Page 21: Programming Function Levels
PROGRAMMING THE REMOTE CONTROL ___________________________ Programming function levels Move the slide-switch to the function level (SAT, VCR, DVD) you want to programme. – The display of the selected function level lights up for about three seconds. Simultaneously press »AUX« and »3« until the display of the selected func- tion level lights continuously. -
Page 22: Reset
PROGRAMMING THE REMOTE CONTROL ___________________________ Reset You can reset the remote control back to the settings it was given in the factory. Resetting a function level Move the slide-switch to the function level (SAT, VCR, DVD) which is sup- posed to be reset. Simultaneously press »PIP«... -
Page 23: Customer Information
CUSTOMER INFORMATION __________________________________ Technical data Power supply voltage: 220 – 240 V, 50/60 Hz (control range of the power supply unit 190 … 264 V) Power consumption: in operation, 135 W, in standby 5 W Sound output stage: 2 x 20 Watt music (2 x 10 Watt sine) Reception ranges: C01 …... -
Page 24: Service Information For The Specialized Dealer
CUSTOMER INFORMATION _____________________________________________________ Service information for the specialized dealer: The TV set may be operated only using the mains cable set supplied. It prevents mains interference and is an integral part of the appliance approval. For replacement purposes, please order only the mains cable set with the designation “GWN 9.22/part number 8290.991-316”... -
Page 25: Contact Assignment For The Euro-Av Socket
CUSTOMER INFORMATION _____________________________________________________ Contact assignment for the EURO-AV socket If you want to connect an other appliance to the TV set (e.g. computer, amplifier), your specialist dealer can establish a proper connection using the following connection table: signal audio output right audio input right audio output left audio ground... -
Page 26: Correcting Problems Yourself
CORRECTING PROBLEMS YOURSELF ____________ If the remedies below do not lead to a good result, contact an authorised GRUNDIG dealer. Please consider that problems can also be caused by external appliances, such as video recorders and satellite receivers. Problem Possible cause... - Page 27 CORRECTING PROBLEMS YOURSELF ____________________________________ Problem Possible cause Remedy colors wrong, color spots strong magnetic field from increase distance of speaker speakers (or other) to TV set with permanent color spots, switch off the TV set with the mains switch and switch back on after after 10 minutes problem with terrestrial change appliance position...
- Page 28 Grundig AG Kurgartenstraße 37 D-90762 Fürth http://www.grundig.de • • •...
