Icom IC-7100 Service Manual page 9

Hf/vhf/uhf all mode transceiver
Hide thumbs Also See for IC-7100:
Table of Contents

Advertisement

SERIAL TO PARALLEL
CONVERTER
(IC751)
TX POWER AMP
(Q301)
TX POWER AMP
(Q302)
"T8V" LINE SWITCH
(Q492)
"T8V" LINE CONTROLLER
(Q292)
"14V" LINE SWITCH
(Q391)
• PA UNIT
HF/50 MHz/70 MHz BAND
TX POWER DETECT BUFFER
(IC960)
DRIVE AMP
(Q251)
2-4
144 MHz/430 MHz BAND
TX POWER DETECT BUFFER
(IC651)
