Icom IC-7100 Service Manual page 55

[PA UNIT]
REF ORDER
NO. NO.
J101 6510028210 SJ050010 (TMP-J01X-V6)
J701* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J711* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J741* 6510018971 B4B-PH-SM4-TB (LF) (SN)
J791* 6510019371 B3B-ZR-SM4-TF (LF) (SN)
F1* 5220000341 FHA010-03F
F2* 5210000940 1205
EP3* 6910020710 OT-047 M3
EP4* 6910020710 OT-047 M3
MP301* 8930075440 3015 RUG SPRING Y1115
MP302* 8930075440 3015 RUG SPRING Y1115
MP381* 8930004071 EARTH SPRING (C)-1 (SX-166)
MP502* 8930062580 SHIELD TAPE (Q)
MP503* 8930088820 3393 EARTH SPRING Y1308
8930088820 3393 EARTH SPRING Y1308
8930088820 3393 EARTH SPRING Y1308
8930088820 3393 EARTH SPRING Y1308
8930088820 3393 EARTH SPRING Y1308
MP504* 8930063270 2590 EARTH SPRING Y733
8930063270 2590 EARTH SPRING Y733
8930063270 2590 EARTH SPRING Y733
8930063270 2590 EARTH SPRING Y733
8930063270 2590 EARTH SPRING Y733
MP601* 8930075430 3015 ANT SPRING Y1091
MP602* 8930062740 2590 M-SPRING
MP711* 8930071160 2427 F-EARTH SPRING Y896
MP712* 8930071160 2427 F-EARTH SPRING Y896
MP871* 8930071160 2427 F-EARTH SPRING Y896
MP872* 8930071160 2427 F-EARTH SPRING Y896
MP901* 8930075430 3015 ANT SPRING Y1091
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
[EUR]
[EUR-01]
[ITR]
[ESP]
[FRA]
[EUR]
[EUR-01]
[ITR]
[ESP]
[FRA]
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[CONTROL UNIT]
REF ORDER
QTY.
NO. NO.
1 DS1 5030003680 CMF2P2117-E <SKD>
1
1 SP1 2510001720 4050P0803
1
W1** 8900013541 OPC-1410A (P0.5N14L50)
1
W2 8600037390 SX3183 P1121CH
1
1 EP1 0880003480 EX-2832
EP2 6910023900 WT5036-E <SKD>
1
1 MP1 8210028251 3393 FRONT PANEL-1 ASSEMBLY
8210028741 3393 FRONT PANEL (A)-1 ASSEMBLY
1 8210028741 3393 FRONT PANEL (A)-1 ASSEMBLY
1 8210028741 3393 FRONT PANEL (A)-1 ASSEMBLY
1 8210028741 3393 FRONT PANEL (A)-1 ASSEMBLY
1 8210028251 3393 FRONT PANEL-1 ASSEMBLY
1 8210028251 3393 FRONT PANEL-1 ASSEMBLY
1 8210028251 3393 FRONT PANEL-1 ASSEMBLY
1 8210028741 3393 FRONT PANEL (A)-1 ASSEMBLY
1 8210028251 3393 FRONT PANEL-1 ASSEMBLY
1 MP2 8210028260 3393 REAR PANEL ASSEMBLY
1
1 MP3 8930086230 3393 STAND
MP6 8610014530 KNOB N-406
1
1 MP7 8610014540 KNOB N-406 COVER (TOT)
1 MP8 8610014550 KNOB N-407
1 MP9 8610014560 KNOB N-408
1 MP10 8610014570 KNOB N-409
1 MP11 8610014580 KNOB N-410
1 MP12 8930086270 3393 KEY <YAM>
1 MP13 8930086871 3393 RUBBER-1 TOP
1 MP15 8930086260 3393 BRAKE BUTTON
1 MP16 8010022570 3393 SUB CHASSIS Y2166
MP17 8930086310 3393 SPRING
MP19 8930086300 3393 SP HOLDER
MP20 8930086960 3393 LCD SPONGE
MP21 8930087880 3393 LCD PLATE Y1293
MP22 8930086360 LEG CUSHION (L)
MP24 8850003230 PLAIN WASHER (AT)
MP25 8930086981 3393 SHEET-1
MP26 8850002610 PLAIN WASHER (AI)
MP29 8830002441 2427 NUT-1 ROHS
MP30 8930036740 1691 BRAKE PAD
MP31 8810003560 M4 X 6 SUS
MP32 8810009991 PHBT M3 X 8 NI-ZK3
MP33 8810009181 BT M2 X 5 NI-ZC3
MP34 8810009561 PHBT M2 X 6 NI-ZK3
MP35 8810000101 PH M2 X 4 ZK3
MP36 8810004431 PH M3 X 6 ZK3
MP37 8930086990 3393 MODULAR SPONGE
MP41 8930088310 SPONGE (MM)
MP42 8930088440 HIMELON SHEET (DC)
MP43 8930088350 HIMELON SHEET (DB)
MP44 8930088600 HIMELON SHEET (DE)
MP45 8930088610 HIMELON SHEET (DF)
MP46 8930088620 HIMELON SHEET (DG)
MP47 8930088640 HIMELON SHEET (DI)
MP48 8930088630 HIMELON SHEET (DH)
MP49 8930088650 SPONGE (MQ)
6-2
DESCRIPTION QTY.
[USA]
[EUR]
[EUR-01]
[ITR]
[ESP]
[TPE]
[KOR]
[CHN]
[FRA]
[EXP]
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
2
1
1
2
1
6
4
5
5
1
1
2
1
1
2
2
1
1
1
1
