[FRONT UNIT]
REF
ORDER
NO.
NO.
W1**
8900019300 OPC-2032 (P1N6L50)
W2**
8900018000 OPC-1344A (P1N10L70)
W3**
8900018000 OPC-1344A (P1N10L70)
W4**
8900018000 OPC-1344A (P1N10L70)
W5**
8900019300 OPC-2032 (P1N6L50)
W6**
8900019300 OPC-2032 (P1N6L50)
W7**
8900019300 OPC-2032 (P1N6L50)
EP1
0880002780 EX-3210 #01 (MAIN DIAL)
EP2
6910015650 S-G2218-3#01 (MOUNT PLATE) 0
EP3
6910015650 S-G2218-3#01 (MOUNT PLATE) 0
MP1
8210025750 3183 FRONT PANELASSEMBLY
MP2
8010021650 3183 SUB CHASSISASSEMBLY
MP4
8310074220 3183 WINDOW PLATE
MP5
8930079310 3183 KEYBOARD (SHJ)
MP6
8610014060 KNOB K-295
MP7
8610014050 KNOB K-294
MP9
8610014090 KNOB K-293
MP10
8610014020 KNOB K-290
MP11
8610014030 KNOB K-291
MP12
8610014040 KNOB K-292
MP13
8610014110 KNOB N-379 (A)
MP14
8610014080 KNOB K-297
MP15
8610014070 KNOB K-296
MP16
8610014100 KNOB N-378 (A)
MP18
8610013922 KNOB N-268ASSEMBLY (A)-2
MP20
8930076900 3073 D-RUBBER (TOP)
MP27
8930076910 3073 BRAKE BUTTON
MP28
8930077360 3073 BRAKE PAD
MP29
8610011830 KNOBN301
MP30
8610013290 KNOB N-361
MP31
8610014140 KNOB N-380ASSEMBLY (A)
MP32
8810008761 PHBT M2 X 8 NI-ZC3
MP34
8810008661 PHBT M3 X 8 NI-ZC3
MP35
8930081070 3183 WINDOW SHEET
MP38
8930082280 SPONGE (LB)
MP39
8930071490 2242 F-SPONGE
MP40
8930071490 2242 F-SPONGE
MP41
8930082320 SPONGE (LC)
MP42
8930082320 SPONGE (LC)
MP43
8950003640 COATING CLIP CS-2 (UL)
MP44** 8930025070 SPONGE (CW)
[DISPLAY UNIT]
REF
ORDER
NO.
NO.
R722*
7210003370 R0904N-B10KL-20KQ-R1080<SKD>
R724*
7210003370 R0904N-B10KL-20KQ-R1080<SKD>
R726*
7210003370 R0904N-B10KL-20KQ-R1080<SKD>
R728*
7210003370 R0904N-B10KL-20KQ-R1080<SKD>
J1*
6510020081 52808-2071 (2090)
J21*
6510019971 52808-1071
J31*
6510019971 52808-1071
J32*
6510015541 B4B-ZR-SM4-TF (LF) (SN)
J51*
6510019971 52808-1071
J61*
6510027290 52808-0671
J71*
6510027290 52808-0671
J81*
6510027290 52808-0671
J91*
6510027290 52808-0671
J101*
6510018971 B4B-PH-SM4-TB (LF) (SN)
J111
6510003401 B04B-EH-S (LF) (SN)
J281*
6510019971 52808-1071
J451*
6510027390 40FHY-RSM1-GAN-TF (LF) (SN)
J452*
6510027390 40FHY-RSM1-GAN-TF (LF) (SN)
J453*
6510027400 50FHY-RSM1-GAN-TF (LF) (SN)
J454*
6510027400 50FHY-RSM1-GAN-TF (LF) (SN)
J455*
6510027400 50FHY-RSM1-GAN-TF (LF) (SN)
DS111
5080000421 MBS 3 UA1W 70N ASSY
DS451
5030003350 TSC2G0369-E <SKD>
S601*
2260002740 LS8J2M-T
S602*
2260002740 LS8J2M-T
S603*
2260002740 LS8J2M-T
S604*
2260002740 LS8J2M-T
S611*
2260002740 LS8J2M-T
S612*
2260002740 LS8J2M-T
S613*
2260002740 LS8J2M-T
S614*
2260002740 LS8J2M-T
S621*
2260002740 LS8J2M-T
S622*
2260002740 LS8J2M-T
S623*
2260002740 LS8J2M-T
S624*
2260002740 LS8J2M-T
S631*
2260002740 LS8J2M-T
S632*
2260002740 LS8J2M-T
S633*
2260002740 LS8J2M-T
S634*
2260002740 LS8J2M-T
S641*
2260002740 LS8J2M-T
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[DISPLAY UNIT]
REF
ORDER
QTY.
NO.
NO.
1
S642*
2260002740 LS8J2M-T
1
S643*
2260002740 LS8J2M-T
1
S644*
2260002740 LS8J2M-T
1
S651*
2260002740 LS8J2M-T
1
S652*
2260002740 LS8J2M-T
1
S653*
2260002740 LS8J2M-T
1
S654*
2260002740 LS8J2M-T
S661*
2260002740 LS8J2M-T
1
S662*
2260002740 LS8J2M-T
1
S663*
2260002740 LS8J2M-T
1
S664*
2260002740 LS8J2M-T
S671*
2260002740 LS8J2M-T
1
S673*
2260002740 LS8J2M-T
1
S681*
2260002740 LS8J2M-T
1
S682*
2260002740 LS8J2M-T
1
S683*
2260002740 LS8J2M-T
1
S691*
2260002740 LS8J2M-T
1
S692*
2260002740 LS8J2M-T
1
S693*
2260002740 LS8J2M-T
1
S694*
2260002740 LS8J2M-T
1
S695*
2260002740 LS8J2M-T
1
S701*
2260002740 LS8J2M-T
3
S702*
2260002740 LS8J2M-T
1
S703*
2260002740 LS8J2M-T
1
S704*
2260002740 LS8J2M-T
2
S711*
2260002740 LS8J2M-T
1
S712*
2260002740 LS8J2M-T
1
S713*
2260002740 LS8J2M-T
1
S714*
2260002740 LS8J2M-T
2
S731*
2260002740 LS8J2M-T
3
S732*
2260002740 LS8J2M-T
2
S733*
2260002740 LS8J2M-T
1
S734*
2260002740 LS8J2M-T
17
S735*
2260002740 LS8J2M-T
10
S736*
2260002740 LS8J2M-T
1
1
T113*
5910001150 6373-T170 (CEPH145B)
1
1
MP111* 8510019770 3183 CFL CASE
1
MP112* 8930081100 THERMAL SHEET (BX)TC1000HS1.4 (6.8X13
1
MP451
8930079340 3183 LCD HOLDER
1
MP452
8930083250 3183 LCD A-SPONGE
1
MP453
8210025710 3183 REFLECTOR
MP454
8930079370 3183 WHITE SHEET
MP455
8930079730 3183 LCD FILTER
MP456
8930074720 SPONGE (JX)
QTY.
[VR-A UNIT]
1
1
REF
ORDER
1
NO.
NO.
1
J2*
6510027290 52808-0671
1
S1
2250000410 TP90D96E20-30F-2178-1
1
1
1
1
[VR-B UNIT]
1
1
REF
ORDER
1
NO.
NO.
1
1
J2*
6510019971 52808-1071
1
1
1
[PBT UNIT]
1
1
REF
ORDER
1
NO.
NO.
1
J1*
6510027290 52808-0671
1
1
S1
2250000410 TP90D96E20-30F-2178-1
1
1
1
[M-CH UNIT]
1
1
REF
ORDER
1
NO.
NO.
1
J1*
6510027290 52808-0671
1
1
S1
2250000410 TP90D96E20-30F-2178-1
1
1
1
[RIT UNIT]
1
1
REF
ORDER
1
1
NO.
NO.
1
J1*
6510027290 52808-0671
S1
2250000650 EVEGC2F2524B
