Master Keypad Definitions
NOTE: The system functions described below are for reference only, and require additional key entries to
activate.
1.
DISPLAY WINDOW: Liquid Crystal Display
(LCD). Displays protection point identification
and system status, messages, and user instructions.
2.
ARMED INDICATOR: (RED) Lit when the
system has been armed (STAY, AWAY, NO
DELAY). Blinks when armed and fault exists.
3.
READY INDICATOR: When lit, indicates
system is ready to be armed; blinking indicates
system is not ready (a zone is open).
4.
KEY: Announces a user's message if
PLAY
one was previously recorded. See RECORD
function.
5.
KEY: Tests the system and alarm
TEST
sounder.
6.
KEY: Removes individual protection
BYPASS
zones from being monitored by the system.
Displays currently bypassed zones.
7.
KEY: Allows entry of additional user
CODE
codes that can be given to other system users.
8.
KEY: Turns the Chime mode on and
CHIME
off. When on, any entry through a protected delay
or perimeter zone while the system is disarmed
will cause a tone and voice descriptor to sound at
the keypad.
INTERNAL SOUNDER: Source of alarm
9.
sounds (see "Summary of Audible Notifications"
section).
10.
KEY: Allows alternate key
FUNCTION
functions.
KEY: Used with STAY or AWAY
11.
NO DELAY
function to eliminate the entry delay. Alarm
sounds immediately if entry is opened.
KEY: When pressed prior to arming,
12.
STATUS
the keypad will display all open zones, and will
announce system status.
13.
LIGHTS ON
lights or other devices on or off, if programmed
by the installer.
14.
KEY: Can be programmed to either
AUX
perform a predefined function or to send a preset
message to a pager.
15.
KEY: Arms the perimeter burglary
STAY
protection, guarding protected doors, windows
and other perimeter protection points, and sounds
an alarm if one is opened. Interior protection is
not armed, which allows movement within your
house without causing an alarm. Entrance can be
made through an entry delay zone without
causing an alarm if the system is disarmed before
the entry delay time expires.
KEY: Completely arms both perimeter
16.
AWAY
and interior burglary protection for backup
protection by sensing an intruder's movements
through protected interior areas as well as
guarding protected doors, windows, etc. Entrance
can be made through an entry delay zone without
causing an alarm if the system is disarmed before
the entry delay time expires.
17.
KEY: Disarms the burglary portion of
OFF
the system, silences alarms and audible trouble
indicators, and clears alarm trouble display after
the problem has been corrected.
18. MICROPHONE: Used to record personal
messages up to 20 seconds long.
19. SPEAKER: Source of audible internal warning
and confirmation sounds, status announcments,
as well as alarms (see "Summary of Audible
Notifications").
20. RECORD: Activates the recording function to
record personal messages.
21. VOLUME: Sets the volume of system
announcements and status beeps.
–– KEYS 0-9: Used to enter your individual
security access code(s).
– 8 –
/
KEYS: Turns
LIGHTS OFF
