Brother MFC-250C Quick Setup Manual

Hide thumbs Also See for MFC-250C:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Software User Manual
Quick Setup Guide
Start Here
Before you can use the machine, read this Quick Setup Guide for the correct setup
and installation.
WARNING
Important
DO NOT connect the USB cable yet.
1
Unpack the machine and check the components
WARNING
Plastic bags are used in the packaging of your machine. To avoid danger of suffocation, please keep
these bags away from babies and children.
Illustrations in this Quick Setup Guide are based on MFC-290C.
a
Remove the protective tape and film covering the scanner glass.
b
Remove the plastic bag
c
Make sure you have all components.
Warnings tell you what to do to prevent possible personal injury.
containing the ink cartridges from on top of the paper tray.
a
MFC-250C
MFC-290C MFC-297C
1
EEU-ENG Version 0
1

Advertisement

Table of Contents
loading

Related Manuals for Brother MFC-250C

Summary of Contents for Brother MFC-250C

  • Page 1 Quick Setup Guide Start Here MFC-250C MFC-290C MFC-297C Before you can use the machine, read this Quick Setup Guide for the correct setup and installation. Warnings tell you what to do to prevent possible personal injury. WARNING Important DO NOT connect the USB cable yet.
  • Page 2 Fan the stack of paper well to avoid paper jams Load plain A4 paper and misfeeds. Check that the paper is flat in the tray. Important Do not push the paper in too far. Gently adjust the paper side guides to the paper with both hands.
  • Page 3 While holding the paper tray in place, pull out Connect the power cord the paper support until it clicks, and then unfold the paper support flap b. and telephone line Important DO NOT connect the USB cable yet. Connect the power cord. WARNING The machine must be fitted with an earthed plug.

  • Page 4: Install The Ink Cartridges

    Install the ink cartridges WARNING If ink gets in your eyes, wash them out with water at once, and if irritation occurs consult a doctor. No Cartridge Unpack the ink cartridge. Install each ink cartridge in the direction of the arrow on the label.

  • Page 5: Check The Print Quality

    If all lines are clear and visible, press 1 (Yes) on the dial pad to finish the quality check. If you can see missing short lines, press 2 (No) on the dial pad and go to d. Poor Note The machine will prepare the ink tube system for printing.

  • Page 6: Choosing Your Language

    Choosing your language Choose a Receive Mode Press Menu. Do you want to use the telephone features of your machine (if available) or an external telephone or Press 0. external telephone answering device connected on the same line as the machine? Press 0.

  • Page 7: Set The Date And Time

    Set the LCD contrast Enter personal (If needed) information (station ID) Press Menu. You should store your name and fax number to be printed on all fax pages that you send. Press 1. Press Menu. Press 7. Press 0. Press a or b to choose Dark or Light. Press 3.

  • Page 8: Set Tone Or Pulse Dialling Mode

    ® For Windows Users: Set tone or pulse dialling mode Now go to Page 9 Press Menu. Press 0. ® For Mac OS Users: Press 4. Now go to Press a or b to choose Pulse (or Tone). Press OK. Page 11 Press Stop/Exit.

  • Page 9: Before You Install

    Note If the Brother screen does not appear automatically, go to My Computer (Computer), double-click the CD-ROM icon, and then double-click start.exe. The CD-ROM main menu will appear. Click Install MFL-Pro Suite.

  • Page 10: Connect The Usb Cable

    ® Windows Connect the USB cable Connect the power cord Connect the power cord. The installation will continue automatically. The installation screens appear one after another. Important DO NOT cancel any of the screens during the installation. It may take a few seconds for all screens to appear.

  • Page 11: For Usb Interface Users

    Mac OS X 10.2.4 or greater. (For ® the latest information for Mac OS X, visit http://solutions.brother.com/) • Make sure there are no memory cards or a USB Flash memory drive inserted. Connect the USB cable Important • DO NOT connect the machine to a USB port on a keyboard or a non-powered USB hub.
  • Page 12 Please wait, it will take a few seconds for the software to install. After the installation, click Restart to finish installing the software. The Brother software will search for the Brother device. During this time the following screen will appear.

  • Page 13: Install Optional Applications

    Install Optional Applications ® Windows Install FaceFilter Studio Install FaceFilter Studio supported by Help Reallusion, Inc To run FaceFilter Studio, go to Important Start/All Programs/Reallusion/ FaceFilter Studio on your computer. • The machine must be ON and connected to the computer. Click the button on the upper right corner •...
  • Page 14 Install Optional Applications ® Windows Install BookScan&Whiteboard Suite supported by Reallusion, Inc Important • The machine must be ON and connected to the computer. • The computer must be connected to the Internet. Open the main menu again by ejecting and then reinserting the CD-ROM or by double- clicking the start.exe program from the root folder.

  • Page 15: Safety And Legal

    Safety and Legal Choosing a location Put your machine on a flat, stable surface that is free of vibration and shocks, such as a desk. Put the machine near a telephone socket and a standard grounded electrical socket. Choose a location where the temperature remains between 10°C and 35°C.

  • Page 16: To Use The Machine Safely

    Safety and Legal To use the machine safely Please keep these instructions for later reference and read them before attempting any maintenance. WARNING There are high voltage electrodes inside the machine. Before you clean the inside of the machine, make sure you have unplugged the telephone line cord first and then the power cord from the electrical socket.
  • Page 17 If the machine becomes hot, releases smoke, or generates any strong smells, immediately unplug the machine from the electrical socket. Call your Brother dealer or Brother Customer Service. If metal objects, water or other liquids get inside the machine, immediately unplug the machine from the electrical socket.
  • Page 18 11 Wait until pages have exited the machine before picking them up. 12 Unplug this product from the power socket and refer all servicing to Brother Authorized Service Personnel under the following conditions: If liquid has been spilled into the product.
  • Page 19 The purpose of the International ENERGY STAR Program is to promote the development and popularization of energy-efficient office equipment. ® As an ENERGY STAR Partner, Brother Industries, Ltd. has determined that this product meets the ® ENERGY STAR guidelines for energy efficiency.

  • Page 20: Legal Limitations For Copying

    Safety and Legal Legal limitations for copying It is an offence to make reproductions of certain items or documents with the intent to commit fraud. This memorandum is intended to be a guide rather than a complete list. We suggest you check with relevant legal authorities if in doubt about a particular item or document.
  • Page 21 The contents of this manual and the specifications of this product are subject to change without notice. Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.

This manual is also suitable for:

Mfc-290cMfc-297c
