43 GPIO_P11/I2C_MDA
44 GPIO_P10/I2C_MCL
45 NC
46 NC
47 NC
48 GPIO_P27/PWM1
49 VDDP
50 GND
51 VDDC
52 MODE[0]
53 MODE[1]
54 LVA3P
55 LVA3M
56 VDDP
57 GND
58 LVACKP
59 LVACKM
60 LVA2P
61 LVA2M
62 LVA1P
63 LVA1M
64 LVA0P
65 LVA0M
66 VDDC
67 LVB3P
68 LVB3M
69 LVBCKP
70 LVBCKM
71 LVB2P
72 LVB2M
73 LVB1P
74 LVB1M
75 VDDP
76 GND
77 LVB0P
78 LVB0M
79 GND
80 BYPASS
ViewSonic Corporation
General Purpose Input/Output; 4mA driving strength/I2C Master
I/O
Data
General Purpose Input/Output; 4mA driving strength/I2C Master
I/O
Clock
Not Connected
Not connected
Not connected
General Purpose Input/Output; 4mA driving strength/Pulse Width
I/O
Modulation Output; 4mA driving strength
I Digital Output Power
Ground
I Digital Core Power
I Chip Configuration Input
I Chip Configuration Input
O A-Link Positive LVDS Differential Data Output
O A-Link Negative LVDS Differential Data Output
I Digital Output Power
Ground
O A-Link Positive LVDS Differential Clock Output
O A-Link Negative LVDS Differential Clock Output
O A-Link Positive LVDS Differential Data Output
O A-Link Negative LVDS Differential Data Output
O A-Link Positive LVDS Differential Data Output
O A-Link Negative LVDS Differential Data Output
O A-Link Positive LVDS Differential Data Output
O A-Link Negative LVDS Differential Data Output
I Digital Core Power
O B-Link Positive LVDS Differential Data Output
O B-Link Negative LVDS Differential Data Output
O B-Link Positive LVDS Differential Clock Output
O B-Link Negative LVDS Differential Clock Output
O B-Link Positive LVDS Differential Data Output
O B-Link Negative LVDS Differential Data Output
O B-Link Positive LVDS Differential Data Output
O B-Link Negative LVDS Differential Data Output
I Digital Output Power
Ground
O B-Link Positive LVDS Differential Data Output
O B-Link Negative LVDS Differential Data Output
Ground
For External Bypass Capacitor
