4.8 Key Parts Pin Assignment
4.8.1 IC802 (NCP1337, Power Control IC)
Pin
Symbol
1
BO
2
FB
3
CS
4
GND
5
DRV
6
Vcc
7
NC
8
HV
4.8.2 IC501 (OZ9938GN, CCFL inverter controller IC)
Pin No.
Symbol
1
DRV1
2
VDDA
3
TIMER
4
DIM
5
ISEN
6
VSEN
7
OVPT
8
NC
9
NC
10
ENC
11
LCT
12
SSTCMP
13
CT
14
GNDA
15
DRV2
16
PGND
4.8.3 U105(TSUM56AL-1)
Pin
Symbol
1
NC
2
GND
3
NC
4
NC
ViewSonic Corporation
I/O
Description
I
Brown−out and external triggering
I
Sets the peak current setpoint
I
Current sense input and overpower compensation adjustment
IC ground
O
Output driver
I
IC supply
N/A
N/A
I
High−voltage pin
I/O
O
Drive output
I
Supply voltage input
I
Timing capacitor to set striking time and shut down delay time
Analog dimming or Internal LPWM dimming or external PWM pulse input
I
for dimming function
I
Current sense feedback
I
Voltage sense feedback
I
Over-voltage/over-current protection threshold setting pin
I
ON/OFF control of IC
Timing capacitor to set internal PWM dimming frequency and also a pin for
I
analog dimming selection
I
Capacitor for soft start time and loop compensation
I
Timing resistor and capacitor for operation and striking frequency
Ground for analog signals
O
Drive output
Ground for power paths
I/O
Not connected
Ground
Not connected
Not connected
Description
Description
Confidential - Do Not Copy
29
VX1935wm-3
