2.7 AUDIO INTERFACE (SPEAKER SPECIFICATION)
Line input signal
Line input impedance
Maximum Amp power output (Watt)
Speaker Power rating(Ω/Watt)
THD
Signal to Noise Ratio
Frequency response
SPL.
Line input connection
Vibration
Screen image
Connector PC99 requirement Audio in
Cable type / length
Audio DPMS
LCD PANEL Type:
st
1 panel
Pixel Pitch
source
Color Filter
Glass
Viewing Angle
Contrast Ratio
1
Brightness
Response Time
Color Depth
Backlight Life
INPUT
Video
2. SIGNAL Sync
ViewSonic Corporation
1 Vrms
10 kOhm
2.0 W (RL=8Ω)
8Ω/2 W (typ.) ; 8Ω/ 3 W (max)
10% (Maxmum output @ 1KHZ)
75 dB
200 Hz – 20 Khz
82 ± 3 dB
3.5 mm stereo jacks
There should be no audible vibration resonance at
volume=100% & treble / bass in def. value
There should be no affect on the screen image stability under
any conditions
Lime Green pantone # 577C
3.5mm stereo cable / 1.8m length
Speakers stay Off when the rest of the monitor is in power
saving
Note: There is no guarantee <2 W at power consumption in
Active Off mode, when the Audio Cable is connected
INL 19" wide Color TFT Active Matrix WXGA LCD. (MT190AW01 V.0)
0.285mm (H) x0.285mm(V)
RGB Vertical Stripe
Anti-Glare treatment and hard-coating 3H
CR > 10 Horizontal = 140 Degrees (Min), Vertical = 140 Degrees (Min)
Horizontal = 160 Degrees (Typ), Vertical = 160 Degrees (Typ)
700:1 (Typ), 500:1 (Min)
300 cd/m2 (Typ), 230 cd/m2 (Min),
Tr = 1.5ms (Typ), Tf =3.5ms (Typ). Tr+Tf = Total = 5ms (Typ)
Tr = 6.5ms (Max), Tf = 8.5ms (Max) Tr+Tf = Total = 15ms (Max)
16.2 million colors (6 bits + 2 bits FRC)
40,000 Hrs (Min)
RGB Analog (75 ohms, 0.7 Vp-p); DVI-D
H/V Separated (TTL), Composite, SOG
F :30~82kHz, F
H
11
:50~85Hz
V
