This manual explains how to install and use Windows printer drivers for SAMSUNG SRP-275 printers. These drivers make it possible for Windows applications to print to SAMSUNG BIXOLON SRP-275 printers. Please read this manual carefully so that you can take full advantage of the driver’s capabilities.
3. Installing the Driver 3.1 Download windows driver from website (1) Connect our website(http://www.samsungminiprinters.com) (2) Select language (3) Click “Download” tab of “Support & Service” (4) Download “Windows Driver” of SRP-275 section. 3.2 Install windows driver with autoinstaller (1) Double click “SRP-275_V3.1.1E.exe” file. (2) Installer program extract files to current folder and installation start.
Page 5
(4) Select OS Type and click “Next” button. SRP-275 PRINTER Impact Receipt Printer...
(5) Select port type and click “Next” button. When installation finished, you must reboot your system. 3.3 Printer Settings This section is explained the way of following Printer Settings. - Printer Resolution - Paper Size - Orientation In Windows 95/98/ME, this can be set in the printer’s “Properties” dialog. In Windows NT4.0, it can be set in the printer’s “Document Default”...
4. Main Specifications 4.1 Printer Fonts These drivers support use of printer fonts as well as Windows fonts. Use of printer fonts permits faster printing. Available printer fonts are listed below. “Built-in fonts of a printer” can be specified with the application programs. The “built-in fonts” are as follows.
4.2 Special Functions The SRP-275 Printer can be used to execute a variety of special non-printing functions, as indicated in the table below. You can execute these functions by selecting the printer’s special “FontControl” font and then sending the appropriate character code to the driver. ( Note that you cannot use the “FontControl”...
4.3 Resolutions The resolution settings supported by SRP-275 printer are as follows - 160 × 72 - 160 × 144 - 80 × 72 4.4 Paper Sizes The paper sizes supported by SRP-275 printer are as follows. - 76 × 3276 mm[275] - 69.5 ×...
5. Controlling the Printer from VB This section shows how you can control the SRP-275 Printer using Visual Basic(Version 6.0). Note that the SRP-275 Printer drivers include sample Visual Basic programs that provide additional examples. 5.1 Selecting the Printer Driver The following code establishes the specified printer driver as your "default printer."...
5.3 Opening the Cash Drawer The next example shows how to open the desired cash drawer at the desired speed. ♦ VISUAL BASIC 'Set up the control font. Printer.FontSize = 9 Printer.FontName = "FontControl" Printer.Print "A" ‘Use special-function character to open the cash drawer. ‘A: Open drawer 1 at 50ms ‘B: Open drawer 1 at 100ms ‘C: Open drawer 1 at 150ms...
6. Using the SRP-275 Printer from WordPad 6.1 WordPad Environment WordPad is more adequate to test printer than Microsoft Word. Make it sure that SRP-275 has been chosen as default printer and than go furtherwith WordPad like below. Start up WordPad, and enter appropriate settings for the follows. - Size [ Refer to Section 4.5, “Paper Sizes”] - Resolution...
6.3 Opening the Cash Drawer 1. Select the “FontControl” font from the font list. 2. Set the font size to 9 3. Type an “A” into the WordPad text-input area. 4. Open the File menu, and click on Print. Clicking on Print will cause cash drawer #1 to open at a drive speed of 50ms. By changing the character that you input at Step 3, you can select a different drive speed or open the other drawer.
6.4 Cutting the Paper 1. Select the “FontControl” font from the font list. 2. Set the font size to 9 3. Type in an “P” 4. Open the File menu, and click on Print. SRP-275 PRINTER Impact Receipt Printer...
7. Using the SRP-275 Printer Properties 7.1 Additional Commands Logo Printing Cut Receipt (partial cut) without paper feeding. Type the command to cut. ex) \x1D\x56\x01 = Cut Receipt Promotion printing Cut Receipt (partial cut). Type the command to cut. ex) \x1D\x56\x42 = Cut Receipt SRP-275 PRINTER Impact Receipt Printer...
Page 16
This is where you enter the number of line feeds that will be done after a document is printed. You can fire cash drawer 1 or 2. Whether to cut or not at the end of receipt. Cutting without paper feeding SRP-275 PRINTER Impact Receipt Printer...
