Summary of Contents for EverFocus EQ500
- Page 1 EQ 500 User’s Manual Operation Instructions Version 1.0...
-
Page 2: Table Of Contents
Table of Content Notice ......................... 1 Safety Warning....................2 Introduction ....................... 3 Specification....................... 4 Chapter I Systems Connection ..............5 Chapter II Functional Setting ..............6 1. Set ......................6 2. Date, time, and on screen display setting............7 3. Alarm records display..................8 4. -
Page 3: Notice
Notice This manual is presented to the users of EQ500 by EverFocus Electronics Corp. With years of engineering researches, EverFocus has spared no effort to provide the high quality products to the worldwide users. For the policy of continual product improvement, EverFocus reserves the right to make changes to the product specifications and documentation without notice. -
Page 4: Safety Warning
Safety Warning 1. Do not expose the camera to humidity and dust. Moisture can damage the camera and cause the danger of electric shock. If the camera is mounted outdoor, a camera housing is required. 2. Do not disassemble it or place it on an unstable base. To prevent the electric shock, do not remove screws or covers. -
Page 5: Introduction
Introduction The EQ500 Series Day/Night Digital Color Camera introduces a new level of high quality picture. are compact , full performance , general purpose color DSP Cameras, which use high sensitive 1/3" interline transfer Super HAD CCDs (Charge Coupled Device). It delivers high resolution superior color images in bright light, and clear sharp monochrome pictures in low light. -
Page 6: Specification
Specification Pickup device: 1/3” interline transfer color CCD Video format: NTSC or PAL Picture element: NTSC:768 (H) x 494 (V) ; PAL: 752(H) x 582(V) Scanning system: NTSC:525 lines, PAL:625 lines(PAL) Horizontal resolution: 480 TV lines Sensitivity: 1.0 lux/F=1.2 S/N ratio: Over 48 dB Camera ID symbol: 9 characters title generator... - Page 7 Major Parts Names and their Functions Video Output Connector This connector is used to connect with the VIDEO IN connector of the monitor (Video Out: BNC type). Audio Output Connector This connector is used to connect with an audio device (Audio Out: RCA connector).
- Page 8 Tact Switcher for Down Cursor This tact switcher is used to move the cursor to the move the cursor downward for selecting the items of the selected item. Tact Switcher for Left Cursor This tact switcher is used to move the cursor to the left for adjusting the parameters of the selected item.
-
Page 9: Mounting The Lens
Mounting The Lens 1. Mount the lens by turning it clockwise on the lens mount of the camera. 2. If you use the Auto Iris lens, connecting the lens cable to the auto iris lens connector on the top of the camera. E v e r F o c u s E l e c t r o n i c s C o r p . - Page 10 1. Connecting the AC power cord to an electrical outlet of 90~265 VAC when you use the EQ500 with a power cord. 2. If you use the EQ500 with 24V AC input terminal, please connect the power cord to the terminal on the rear panel of the camera.
-
Page 11: Lock
Settings • • Opening the Set Up Menu Press the tact switcher to enter main menu shown as below: SWITCH SETUP EXPPOSURE LINELOCK DAY/NIGHT CAMERA ID xxxxxxxxx LOAD DEFAULT NEXT PAGE EXIT This page is just for you to set the main function of the camera. If you would like to do more settings, please go through the following pages. -
Page 12: Power
• • EXPOSURE 1. There are four modes of exposure for you to set on the screen. Use to select the mode. The modes are: Electronics Shutter(ES), Manual Exposure(ME), Flickerless(FL), and Auto Iris(AI). 2. You can do further setting on next page after selecting one of the modes. - Page 13 EXIT • • LOAD DEFAULT 1. Press to reset the camera to the factory settings. 2. As soon as the default is loaded, EverFocus VER 1.0 will be shown on the screen. Caution: 1. You can also press together to load default anywhere on the screen display mode.
- Page 14 Engineering Settings The second page is for you to do more settings of exposure. The further setting of each mode is described as below. • • EXPOSURE ES EXPOSURE ES LEVEL<IRE> RESPONSE SHUTTER LIM 1/500 BLC LEVEL AGC MAX AGC MIN NEXT PAGE EXIT 1.
- Page 15 5. AGC MAX Once the AGC is on, you can do further setting of maximum value of AGC. 6. AGC MIN Except the maximum value of AGC, you can also set the minimum value of AGC. 7. BLC Press to set ON or OFF of Back Light Compensation function.
- Page 16 • • EXPOSURE AI EXPOSURE AI D/D LEVEL AGC MAX AGC MIN NEXT PAGE EXIT D/D LEVEL This parameter is for you to adjust bright level of the video. The value is high, and then the video is bright. AGC MAX, AGC MIN, BLC, and AGC function is the same setting procedure as EXPOSURES ES.
- Page 17 • • VIDEO SETUP VIDEO SETUP BRIGHT CHROMA SHARPNESS L SHARPNESS H SHARPNESS V NEXT PAGE EXIT 1. BRIGHT This parameter is for you to adjust the bright of the video. 2. CHROMA 3. HUE These two items are used to adjust the color of the picture. 4.
- Page 18 • • VIDEO SETUP2 VIDEO SETUP2 Y GAMMA Y KNEE C GAMMA C KNEE PATTERN NEXT PAGE EXIT 1. Y GAMMA This parameter is for you to adjust the Y Gamma Correction Curve. 2. CHROMA 3. HUE These two items are used to adjust the color of the picture. 4.
- Page 19 EverFocus Electronics Corp. Head Office: 10F-6, No.79 Sec. 1 Shin-Tai Wu Road, Hsi-Chi, Taipei, Taiwan : 886-2-26982334 : 886-2-26982380 USA Office: Suite 102, 2975 Huntington Drive San Marino, CA. 91108 U.S.A. : (626) 844-8888 : (626) 844-8838 Toll free : 1-(888) 383-6287 or...
