iOptron 9802 Quick Start Manual

Quick Start Guide

®
SmartStar -R80 GPS Telescope
#9801 (Pulsar Pink) & #9802 (Astro Blue)
®
SmartStar -R80 Telescope
#9501 (Pulsar Pink) & #9502 (Astro Blue)
FEATURES
•
Alt-Azimuth Mount– The Cube™-- The only mount of its kind for ultimate rotation
•
Includes the GoToNova
•
Over 5,000 object database.
•
Built-in 32-channel GPS (#9801 & #9802 only)
•
Large LCD screen with 4 lines and 21-character wide screen
•
Drive motor with 5-speed setting for better control.
•
Dual-axis Servomotor
•
Aluminum tripod
•
80mm achromatic refractor telescope
PACKAGE CONTENTS
®
•
SmartStar telescope mount
•
Built-in GPS receiver (#9801 & #9802
only)
•
80mm Refractor telescope
•
Tripod
ONLINE CONTENTS (click under "Support" menu button) www.iOptron.com
•
Full manual
(you can refer to the full manual for more details on set-up and operation).
•
Tips for operating
•
Reviews and feedback from other customers
•
Accessories information
Assembly Terms
1. Telescope tube
2. Dovetail lock
3. Hand controller
4. Altitude lock
5. Mount (shown with GPS)
6. Diagonal
7. Eyepiece
8. Height adjustment handle
9. Center Tripod Lock Knob
10. Leg Locks (3)
11. Tripod
12. Tripod height lock knob
13. Height Extender
iOptron Corp. | 6E Gill Street | Woburn, MA 01801 USA | (781) 569-0200 | Toll Free (866) 399-4587 | www.iOptron.com
TM
Controller. One of the most intuitive controllers on the market.
(including AC adapter, carry bag, and more)
•
#8405 Hand Controller
•
Controller Cable
•
3x Barlow lens
•
45º diagonal
•
K 10mm and K 25mm eyepieces
