Invacare Head and Torso Supports 1164 Installation And Operating Instructions

Head and Torso Supports
Assembly, Installation and Operating Instructions
Model Nos. 1164, 3040 (Torso Supports) and
Model Nos. 3045, 3046 (Head Supports)
WARNING/CAUTION notices as used in this manual apply to hazards or
unsafe practices which could result in personal injury or property damage.
The information contained in this document is subject to change without notice.
DO NOT install, maintain or operate this equipment without reading,
understanding and following the proper instructions otherwise injury or
damage may result.
Make certain ALL screws, bolts and nuts are tight at all times.
PARTS LIST
REF. PART NO.
NO. (BLACK)
1* 04529x040
2 1025716
3* 04529x043
4 03018x012
5 03018x016
6 1028841
7 1028758
7 1028759
8 03018x041
9 03018x042
10 1031026
11 1025730
12 03018x045
13 03018x044
NOTE: Items with (*), upholstery style and color MUST BE supplied with Part No. when ordering
replacement parts.
INSTALLATION
HEAD SUPPORTS MODEL NOS. 3045 AND 3046 (FIGURE 1)
1. Mount the headrest support to the back upright of the chair; which includes the
following items:
Headrest/Torso Pad Assembly (Item 1)
Panhead Screw (Item 2)
Pad Support Sub-Assembly (Item 12 or 13)
Socket Screw (Item 6)
Part No. 1026310
SAVE THESE INSTRUCTIONS
SAFETY SUMMARY
NOTICE
WARNING
PART NO.
(CHROME)
04529x040 Headrest/Torso Pad Assembly
40163x008 Panhead Screw
04529x043 Torso Bracket Cover
03018x012 Support Rod
03018x016 Torso Support Bracket
60284x001 Socket Screw
03018x043 Bracket Clamp (RH)
03018x046 Bracket Clamp (LH)
03018x041 Pad Support Sub-Assembly
03018x042 Adjustment Bracket Assembly
(Model No. 3045 Only)
11232x009 Lug Screw
60264x001 Locknut
03018x045 Pad Support Sub-Assembly
(Model No. 3045)
03018x044 Pad Support Sub-Assembly
(Model No. 3046)
1
DESCRIPTION
Head and Torso Supports
