Operating Instructions

Network Camera

WV-SW355, WV-SW352
Model No.
WV-SW355E, WV-SW352E
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic WV-SW355

Summary of Contents for Panasonic WV-SW355

  • Page 1: Operating Instructions

    Operating Instructions Network Camera WV-SW355, WV-SW352 Model No. WV-SW355E, WV-SW352E Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual.

  • Page 2: Table Of Contents

    [SD memory card] ......... 31 notification [Notification] ........73 Access copy images saved on the SD memory Configure the settings relating to Panasonic alarm card onto the PC [SD memory card images] ..36 protocol [Notification] ..........74 Configure the settings relating to the logs [Log] ... 41...
  • Page 3 Configure the settings relating to the authentication Maintenance of the camera [Maintenance] ..... 111 [User mng.] ..............77 Check the system log [System log] ..... 111 Configure the settings relating to the user Upgrade the firmware [Upgrade] ......112 authentication [User auth.] ........77 Check the status [Status] ........

  • Page 4: Preface

    Preface About the user manuals There are 2 sets of operating instructions for the WV-SW355, WV-SW352 (NTSC model), WV-SW355E, WV-SW352E (PAL model) as follows. • Installation Guide: Explains how to install and connect devices. When you use the WV-SW355 or WV-SW355E, refer to WV-SW355/WV-SW355E Installation Guide. When you use the WV-SW352 or WV-SW352E, refer to WV-SW352/WV-SW352E Installation Guide.

  • Page 5: Abbreviations

    Abbreviations The following abbreviations are used in these operating instructions. ® ® ® ® Microsoft Windows 7 Professional (64-bit) and Microsoft Windows 7 Professional (32-bit) are described as Windows 7. ® ® Microsoft Windows Vista Business SP1 (32-bit) is described as Windows Vista. ®...

  • Page 6: Monitor Images On A Pc

    Step 2 (Example: http://192.168.0.11:8080) Enter the IP address designated using the Panasonic IP • When the PC is in a local network, configure the setup software in the address box of the browser. proxy server setting of the web browser (under Example when entering an IPv4 address: "Internet Options…" under "Tools" of the menu bar)
  • Page 7 Important: • To enhance the security, change the password for the user name "admin". It is recommended to change this password periodically. • When displaying multiple H.264 (or MPEG-4) images on a PC, images may not be displayed depending on the performance of the PC. Note: • When "H.264" is selected for "Video encoding format", H.264 video will be displayed. When "MPEG-4" is selected, MPEG-4 images will be displayed. • The maximum number of concurrent access user is 14 including users who is receiving H.264 (or MPEG-4) images and users who are receiving JPEG images. Depending on the set values for "Bandwidth control (bit rate)" and "Max bit rate (per client)", the maximum concurrent access number may be 14 or less users. When 14 users are concurrently accessing, the access limit message will be displayed for users who subsequently attempt to access.

  • Page 8: About The "Live" Page

    About the "Live" page !4 !5 !6 q [Setup] button (*1) t [Stream] button Displays the setup menu. The button will turn green These buttons will be displayed only when an H.264 and the setup menu will be displayed. (or MPEG-4) image is displayed. [1] button: The letter "1"...
  • Page 9 [800x600] button : The letters "800x600" button: The adjusted brightness will return SW352 will turn green and images in the main area will to the default brightness (64). be displayed in 800 x 600 (pixels). (brighter) button: Image will be brighter. [640x360] button: The letters "640x360" will turn green and images in the main area will be dis- !0 [AUX] buttons (*2) played in 640 x 360 (pixels).
  • Page 10 !6 Snap shot button When "Interactive(Full-duplex)" is selected, the Click this button to take a picture (a still picture). transmission button is inoperable for other users. The picture will be displayed on a newly opened • Possible duration of audio transmission is up to 5 window. When right-clicking on the displayed minutes per transmission. When 5 minutes have image, the pop-up menu will be displayed. It is pos- passed, the audio transmission will automatically stop. To turn the audio transmission function on, sible to save the image on the PC by selecting click the [Audio output] button again. "Save" from the displayed pop-up menu. When "Print" is selected, printer output is enabled. • When the camera is restarted, the adjusted volume level (for both the audio transmission and reception) Note: will return to the level that had been set on the [Audio] tab on the setup menu. (☞ Page 64) • For the case of using Windows 7 or Windows Vista, • Actual volume level will change in three steps even the following settings may be required. Open Internet Explorer, click [Tools] in the menu bar, though the volume cursor can be adjusted minutely. click [Internet Options], click the [Security] tab, click [Trusted Sites], and click [Sites]. Register the cam- !9 SD recording status indicator era address on "Website" of the displayed trusted The status of the SD recording can be checked with this indicator.

  • Page 11: Monitor Images From Multiple Cameras

    4 groups (16 cameras) can be registered. (☞ Page 65) Important: • When displaying images on a 16-screen, panning, tilting and zooming operations become unavailable for images from the Panasonic PTZ cameras. • When displaying images on a 4-screen, panning, tilting and zooming operations become available only for images from the Panasonic PTZ cameras. Refer to the "Readme" file on the provided CD-ROM for further infor- mation about the compatible PTZ cameras and their versions.

  • Page 12: Monitor Images On A Cellular Phone

    Monitor images on a cellular phone It is possible to connect to the camera using a cellular phone via the Internet and monitor images (JPEG only) from the camera on the screen of the cellular phone. It is also possible to refresh images to display the latest image or perform panning, tilting and zooming operations.
  • Page 13 Functions Outline of functions Refresh Refreshes the camera images by pressing the dial key "5". Resolution control Changes the image capture size by pressing the dial key "0". * I mage in the aspect ratio of "4:3" Changes the image capture size between 320x240 (default) and 640x480. * Image in the aspect ratio of "16:9"...

  • Page 14: Record Images On The Sd Memory Card Manually

    Record images on the SD memory card manually Images displayed on the "Live" page can be recorded on the SD memory card manually. This button is operable only when "Manual" is selected for "Save trigger" on the [SD memory card] tab on the "Basic"...

  • Page 15: Action At An Alarm Occurrence

    This function is available only when a Panasonic device, such as the network disk recorder, is connected to the system. When "On" is selected for "Panasonic alarm protocol notification", the connected Panasonic device will be notified that the camera is in the alarm state. The settings for Panasonic alarm protocol can be configured in the Panasonic alarm protocol section of the [Notification] tab of the "Alarm" page. (☞ Page 74)

  • Page 16: Transmit Images Onto An Ftp Server

    Transmit images onto an FTP server Images can be transmitted to an FTP server. By configuring the following settings, transmission of images captured at an alarm occurrence or captured at a designated interval to an FTP server will become available. Important: • When using this function, set the user name and the password to access the FTP server to restrict users who can log into the FTP server.

  • Page 17: Save Images On The Sd Memory Card When Images Fail To Transmit Using The Ftp Periodic Image Transmission Function

    SD memory card. It is possible to select a trigger to save images on the SD memory card on the [SD memory card] tab of the "Basic" page. (☞ Page 32) To use the SD memory recording function featured in Panasonic network disk recorder, select "Off" for "FTP peri- odic image transmission" (☞ page 107) and "FTP error" for "Save trigger" (☞ page 32).

  • Page 18: Display The Log List

    Display the log list The setting items of the cameras will be displayed in list form. • Alarm log: L ogs of the alarm occurrences such as time and date of the alarm occurrences and the alarm type will be displayed. • Manual/Schedule log: L ogs filed when images have been recorded manually or during the period of the sched- ule on the SD memory card will be displayed. • FTP trans. error log: L ogs filed when the FTP periodic image transmission function has failed will be dis- played.
  • Page 19 [Prev. page] button [Event] Click this button to display the previous page of the log The event type will be displayed. The event types will list. be displayed only when displaying the alarm log list. TRM: Alarm by alarm input to Terminal 1 Note: VMD: Alarm by VMD alarm • When the mouse button is held down while placing...

  • Page 20: Playback Of Images On The Sd Memory Card

    Playback of images on the SD memory card When clicking a time and date listed on the log list window, the "Live" page will turn to the "Playback" page. When images associated with the clicked time and date are on the SD memory card, the first image of them will be displayed.
  • Page 21 [PLAY] button Note: When this button is clicked, images will be played in • When the mouse button is held down while the sequential order. mouse pointer is on this button, the image number will be incremented. [FF] button When the mouse button is released, the increment Each time the button is clicked, the playback speed will of the image number will stop and the image num- change.

  • Page 22: Download The Images (When "H.264" Is Selected For "Recording Format" Of The Sd Memory Card)

    Download the images (When "H.264" is selected for "Recording format" of the SD memory card) Important: • Depending on the network environment, download of video data may fail. To play back video data recorded on the SD memory card, download the desired data, and save the data on the PC. It is impossible to play back video data on the "Playback" page. For this reason, follow the procedure below. Step 1 Step 2 Click the time &...

  • Page 23: About The Network Security

    About the network security Equipped security functions The following security functions are featured in this camera. q Access restrictions by the host authentication and the user authentication It is possible to restrict users from accessing the camera by setting the host authentication and/or the user authentication to "On". (☞...

  • Page 24: Display The Setup Menu From A Pc

    Display the setup menu from a PC The settings of the camera can be configured on the setup menu. Important: • The setup menu is only operable by users whose access level is "1. Administrator". Refer to page 77 for how to configure the access level. How to display the setup menu Step 1 Step 3 Display the "Live" page. (☞ Page 6) Click the [OK] button after entering the user name and the password.

  • Page 25: How To Operate The Setup Menu

    How to operate the setup menu Important: • When there are two or more [Set] and [Execute] but- tons on the page, click the respective button to the edited setting item. <Example> Menu buttons Setup page Step 1 Click the desired button in the frame on the left of the When completing the setting items in field A, click window to display the respective setup menu.

  • Page 26: About The Setup Menu Window

    About the setup menu window q [Setup] button !4 Camera title w [Live] button e [Basic] button r [Image/Audio] button t [Multi-screen] button y [Alarm] button u [Advanced func.] button !5 Setup page i [User mng.] button o [Server] button !0 [Network] button !1 [Schedule] button !2 [Maintenance] button...
  • Page 27 !0 [Network] button Displays the "Network" page. The network settings and the settings relating to DDNS (Dynamic DNS), SNMP (Simple Network Management Protocol) and the FTP (File Transfer Protocol) periodic transmis- sion can be configured on the "Network" page. (☞ Page 83) !1 [Schedule] button Displays the "Schedule" page. On the "Schedule"...

  • Page 28: Configure The Basic Settings Of The Camera [Basic]

    Default: Varies as follows depending on the model in played on the left side of the displayed time and use. date. WV-SW355 Out: Does not apply summer time. WV-SW352 Auto: Applies summer time in accordance with the set- tings for "Start time & date" and "End time & date"...
  • Page 29 [Camera title on screen] [Indicator] Select "On" or "Off" to determine whether or not to dis- Determine whether or not to use the following indica- play the camera title on the screen. tors. Select "On" to use the following indicators to When "On" is selected, the character string entered for check the operational status by lighting them. Select "Camera title on screen (0-9, A-Z)" will be displayed at "Off" to turn off the indicators at all times.
  • Page 30 [Automatic installation of viewer software] Determine whether or not to install the viewer software from this camera. On: Installs the viewer software from the camera auto- matically. Off: The viewer software cannot be installed from the camera. Default: On Important: • It is impossible to display images and to receive/ transmit audio between the camera and the PC when the viewer software "Network Camera View 4S"...

  • Page 31: Configure The Settings Relating To The Sd Memory Card [Sd Memory Card]

    Configure the settings relating to the SD memory card [SD memory card] Click the [SD memory card] tab on the "Basic" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the SD memory card can be configured on this page. • When playing or downloading images saved on the SD memory card, it is necessary to select "On" for "Save logs"...
  • Page 32 Off: Stops saving images on the SD memory card when [Remaining capacity notification] the SD memory card becomes full. When the mail notification function or the Panasonic Default: Off alarm protocol function is used to provide notification of the remaining capacity of the SD memory card, select a Note: level to be notified at from the following.
  • Page 33 ■ JPEG recording [Image capture size] When "Manual" is selected for "Save trigger" and This setting is available only when "JPEG" is selected "JPEG" is selected for "Recording format", select the for "Recording format" of the SD memory card. image capture size of the images to be saved on the SD memory card from the following.
  • Page 34 [Frame rate*] ■ SD memory card information Select the frame rate for images to be recorded from [Remaining capacity] the following. Total capacity and remaining capacity of the SD mem- 1fps/ 3fps/ 5fps*/ 7.5fps*/ 10fps*/ 12 fps (PAL model)*/ ory card will be displayed. 15fps*/ 20fps*/ 30fps* Depending on the status of the SD memory card, the Default: 30fps*...
  • Page 35 • Save/obtain images recorded using the SD memory recording function of Panasonic net- work disk recorder • Play/download images on the SD memory card • When an SD memory card is formatted while another user is in operation, the operation will be canceled. • It is impossible to access the SD memory card dur- ing the process of formatting. • All data saved on the SD memory card will be deleted when the SD memory card is formatted.

  • Page 36: Access Copy Images Saved On The Sd Memory Card Onto The Pc [Sd Memory Card Images]

    Access copy images saved on the SD memory card onto the PC [SD memory card images] Click the [SD memory card] tab on the "Basic" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The following are descriptions of how to copy images saved on the SD memory card onto the PC. It is necessary in advance to select "Allow"...
  • Page 37 Possible number of images that can be saved on the SD memory card (as indications) For JPEG images Important: • The numbers on the following table are just indications. They are not actual numbers of images that can be saved on the SD memory card. Numbers will differ according to photographic subject to the SD memory card. Image capture size: 1 280 x 960 SW355 Capacity of SD/ Image quality...
  • Page 38 Image capture size: 800 x 600 SW352 Capacity of SD/ Image quality SDHC memory 0(Super fine) 1(Fine) card 32 GB Approx. 102 400 pics Approx. 160 000 pics Approx. 192 000 pics Approx. 243 200 pics Approx. 281 600 pics 16 GB Approx.
  • Page 39 Image capture size: 640 x 360 Capacity of SD/ Image quality SDHC memory 0(Super fine) 1(Fine) card 32 GB Approx. 192 000 pics Approx. 281 600 pics Approx. 332 800 pics Approx. 358 400 pics Approx. 409 600 pics 16 GB Approx.
  • Page 40 Image capture size: 320 x 180 Capacity of SD/ Image quality SDHC memory 0(Super fine) 1(Fine) card 32 GB Approx. 460 800 pics Approx. 524 800 pics Approx. 563 200 pics Approx. 576 000 pics Approx. 614 400 pics 16 GB Approx.

  • Page 41: Configure The Settings Relating To The Logs [Log]

    Configure the settings relating to the logs [Log] Click the [Log] tab on the "Basic" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the log list can be configured in this section. Note: • When "Recording format" is set to "H.264", "Save logs" is set to "On" or "Off" depending on the set- ting of "Save trigger". • Schedule saving is available only when "H.264" is selected for "Recording format".

  • Page 42: How The Logs And Images Are Saved Depending On The Settings For "Alarm

    How the logs and images are saved depending on the settings for "Alarm" [Log] tab [SD memory card] tab Logs and associated images Alarm: Save logs SD memory card Save trigger Logs: Up to 5 000 logs will be kept. When more than 5 000 event logs are filed, the older event logs will be over- written by the newer event logs.

  • Page 43: How The Logs And Images Are Saved Depending On The Settings For "Manual/Schedule

    How the logs and images are saved depending on the settings for "Manual/Schedule" [Log] tab [SD memory card] tab Manual/ SD memory Save trigger Overwrite Logs and associated images Schedule: card Save logs Logs: Up to 5 000 logs will be kept. When more than 5 000 logs are filed, the older logs will be overwritten by the newer logs.

  • Page 44: How The Logs And Images Are Saved Depending On The Settings For "Ftp Error

    How the logs and images are saved depending on the settings for "FTP error" [Log] tab [SD memory card] tab FTP error: Save Logs and associated images SD memory card Save trigger logs Logs: Up to 5 000 logs will be kept. When more than 5 000 logs are filed, no log will be filed newly anymore.

  • Page 45: Configure The Settings Relating To Images And Audio [Image/Audio]

    Configure the settings relating to images and audio [Image/Audio] The settings relating to JPEG, H.264 and MPEG-4 images such as the settings of image quality, audio, etc. can be configured on this page. The "Image/Audio" page has 4 tabs; the [JPEG/H.264] tab (or [JPEG/MPEG-4] tab), the [Image quality] tab and the [Audio] tab.
  • Page 46 [Image capture size] Select the image capture size to display the JPEG image on the "Live" page for the first time. When "4:3" is selected for "Aspect ratio" QVGA/ VGA/ 1280×960 SW355 QVGA/ VGA/ 800×600 SW352 When "16:9" is selected for "Aspect ratio" 320×180/ 640×360/ 1280×720 SW355 320×180/640×360 SW352 Default: 1280x960 SW355 SW352 [Image quality] Select the capture size of the JPEG image displayed...

  • Page 47: Configure The Settings Relating To H.264 Images [Jpeg/H.264]

    Configure the settings relating to H.264 images [JPEG/H.264] Click the [JPEG/H.24] tab on the "Image/Audio" page. (☞ Pages 24 and 25: How to display/operate the setup menu) [JPEG/H.264] tab will be displayed when "H.264" is selected for "Video encoding format". Configure the settings relating to H.264 image such as "Max bit rate (per client)", "Image capture size", "Image quality", etc.
  • Page 48 • When "On" is selected, H.264 images may not be Note: displayed depending on the number of the concur- • When "Frame rate" is selected for "Transmission rent access user and audio data availability, etc. priority", this setting is available. • When "On" is selected, only IPv4 access is avail- • "Frame rate*" is restricted by "Max bit rate (per cli- able. ent)*". For this reason, the frame rate may be lower than the specified value when any value marked [Image capture size] with an asterisk (*) is selected.
  • Page 49 Note: [Unicast port1(Image)]* • When "Constant bit rate" or "Best effort" is selected Enter the unicast port number (used to transmit images for "Transmission priority", this setting is available. from the camera). Available port number: 1024 - 50000 (Only even num- [Refresh interval] bers are available.) Select an interval (I-frame interval; 0.2 - 5 seconds) to Default: H .264(1): 32004 refresh the displayed H.264 images.
  • Page 50 Important: • When transmitting an H.264 image via a network, the transmitted image sometimes may not be dis- played depending on the settings of a proxy server or a firewall. In this case, refer to the network administrator. • When two or more network interface cards are installed on the PC in use, the network interface card(s) not used for receiving images should be invalidated when displaying images using the multi- cast port.

  • Page 51: Configure The Settings Relating To Mpeg-4 Images [Jpeg/Mpeg-4]

    Configure the settings relating to MPEG-4 images [JPEG/MPEG-4] Click the [JPEG/MPEG-4] tab on the "Image/Audio" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The "JPEG/MPEG-4" tab will be displayed when "MPEG-4" is selected for "Video encoding format". (☞ Page 47) Configure the settings relating to MPEG-4 image such as "Max bit rate (per client)*", "Image capture size", "Image quality", etc.
  • Page 52 Note: Note: • When "On" is selected, only "Unicast port (AUTO)" • When "Frame rate" is selected for "Transmission will be available for "Transmission type". priority", this setting is available. • When "On" is selected, it may take seconds to start • "Frame rate*" is restricted by "Max bit rate (per cli- displaying MPEG-4 images. ent)*". For this reason, the frame rate may be lower • When "On" is selected, MPEG-4 images may not be than the specified value when any value marked displayed depending on the number of the concur- with an asterisk (*) is selected.
  • Page 53 [Refresh interval] [Unicast port2(Audio)]* Select an interval (I-frame interval; 0.2 - 5 seconds) to Enter the unicast port number (used to transmit audio refresh the displayed MPEG-4 images. from the camera). If using under a network environment with frequent Available port number: 1024-50000 (Only even num- error occurrences, shorten the refresh interval for bers are available.) MPEG-4 to diminish image distortions.

  • Page 54: Configure The Settings Relating To Images, Extra Optical Zoom, Focus, Privacy Zone And Viqs [Image Quality]

    *1 It is necessary to designate the unicast port number when "Unicast port (MANUAL)" is selected for "Transmission type". *2 It is necessary to designate the multicast IP address when "Multicast" is selected for "Transmission type". Configure the settings relating to images, extra optical zoom, focus, privacy zone and VIQS [Image quality] Click the [Image quality] tab on the "Image/Audio"...

  • Page 55: Configure The Settings Relating To Image Quality ("Image Adjust" Setup Menu)

    Configure the settings relating to image quality ("Image adjust" setup menu) Click the [Setup >>] button of "Image adjust" on the [Image quality] tab of the "Image/Audio" page. (☞ Page 54) The settings relating to image quality can be configured with the setup menu displayed in a newly displayed win- dow.
  • Page 56 [Adaptive black stretch] Select 50 Hz or 60 Hz corresponding to the location Select "On" or "Off" to determine whether or not to where the camera is in use. Fix shutter: The selected value will be set as the fixed activate the darkness compensation function. The dark- ness compensation function can make darker parts of shutter speed.
  • Page 57 [Black & white mode] ATW2: Selects the automatic tracing white balance Select switching between the color mode and the black mode under a sodium lamp. The camera will adjust & white mode from the following. the white balance automatically under a sodium Off: The color mode is selected.
  • Page 58 [Chroma gain level] Adjusts the chroma level (color density). When the cursor is moved in the "+" direction, the col- ors will become thicker. When the cursor is moved in the "–" direction, the colors will be thinner. Click the [Reset] button to reset the color to the default. Default: 128 [Aperture level] Adjust the aperture level (outline compensation).

  • Page 59: Set Mask Areas

    Set mask areas When "Off" is selected for "Super Dynamic(SD)" and "Back light compensation(BLC)", it is possible to compensate for backlight by masking brighter areas. Step 1 Step 3 Display the "Image adjust" setup menu. (☞ Page 54) Click the divided areas to be masked. → The clicked areas will be masked and will become white.

  • Page 60: Adjust The Angular Field Of View Using The Extra Optical Zoom Function

    Adjust the angular field of view using the extra optical zoom function Click the [Setup >>] button of "Extra optical zoom" on the [Image quality] tab of the "Image/Audio" page. (☞ page It is possible to adjust the angular field of view using the extra optical zoom function. Important: • The extra optical zoom function may not be acti- vated on the appropriate position if the setting for...

  • Page 61: Configure The Settings Relating To The Privacy Zone (Privacy Zone Setup Menu)

    [Close] button Click this button to close the "Focus" setup menu. Configure the settings relating to the privacy zone (Privacy zone setup menu) Click the [Setup >>] button of "Privacy zone" on the [Image quality] tab of the "Image/Audio" page. (☞ Page 54) When there is a zone that you do not want to display, set the zone as a privacy zone not to be displayed.

  • Page 62: Configure The Viqs Area

    [VIQS(H.264(2))] Select "On" or "Off" to determine whether or not to activate the VIQS function for the transmitted (H.264(2)) images. Default: Off Important: • When the VIQS setting is activated and the setting value for "Aspect ratio" is changed from "4:3" to "16:9" on the [JPEG/H.264] tab, make sure that the VIQS setting value does not exceed the maximum designated range. Note: • Refer to the following for setting procedure of the VIQS area. [VIQS(H.264(1))] Select "On" or "Off" to determine whether or not to activate the VIQS function for the transmitted (H.264(1)) images.

  • Page 63: Configure The Settings Relating To Audio [Audio]

    Configure the settings relating to audio [Audio] Click the [Audio] tab on the "Image/Audio" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to audio can be configured on this page. Note: • Images and audio will not be synchronized. Therefore, images and audio may not always match. • Audio may be interrupted depending on the network environment. Note: • Howling may be generated depending on usage conditions. If howling is generated, prevent sound generated by the PC from entering the PC micro- phone.
  • Page 64 [Mic input volume (Camera to PC)] Note: Select a volume level on the PC to hear audio transmit- ted from the camera. • When a shorter interval is selected, the delay time Mic High: The volume level will become high. This set- will be shorter. When a longer interval is selected, ting will be applied when audio is input to the cam- audio interruption may be diminished even though era using a microphone.

  • Page 65: Configure The Multi-Screen Settings [Multi-Screen]

    Configure the multi-screen settings [Multi-screen] The cameras from which images are to be displayed on a multi-screen can be registered on the "Multi-screen" page. (☞ Pages 24 and 25: How to display/operate the setup menu) Note: • When using the host name, it is necessary to con- figure the DNS settings of the PC to be used for the multi-screen display.

  • Page 66: Configure The Alarm Settings [Alarm]

    "Alarm output terminal setup" receive the command alarm. (☞ page 69). The command alarm is the function that provides notifi- Off: Not used. cation of a Panasonic protocol alarm from the other Default: Off cameras. When "On" is selected, alarm actions will be performed between multiple cameras. [Terminal 3] Default: Off Determine how to use terminal 3.

  • Page 67: Configure The Settings Relating To The Alarm Image [Alarm]

    Configure the settings relating to the alarm image [Alarm] Click the [Alarm] tab on the "Alarm" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the alarm image to be transmitted to an FTP server can be configured in this section. The alarm image will be transmitted to an FTP server. To transmit alarm images to an FTP server, it is necessary to con- figure the settings in advance.

  • Page 68: Configure The Settings Relating To H.264 Recording [Alarm]

    [Image compression rate upon alarm detection] [Image quality upon alarm detection] Select "On" or "Off" to determine whether or not to Image quality can be changed upon an alarm occur- change the image quality 1 (☞ page 46) upon alarm rence. Select the image quality from the following. detection. 0 Super fine/ 1 Fine/ 2/ 3/ 4/ 5 Normal/ 6/ 7/ 8/ 9 Low On: Images will be transmitted with the image quality Default: 5 Normal...

  • Page 69: Configure The Settings Relating To The Alarm Output Terminal [Alarm]

    Configure the settings relating to the alarm output terminal [Alarm] Click the [Alarm] tab on the "Alarm" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the alarm output terminal can be configured in this section. [Pulse width] When "Pulse" is selected for "Alarm output terminal setup", select an alarm output terminal duration from the following.

  • Page 70: Change The Aux Name [Alarm]

    Change the AUX name [Alarm] Click the [Alarm] tab on the "Alarm" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The names of "AUX", "Open" and "Close" on the "Live" page can be changed. Note: • AUX is a camera terminal that allows users to oper- ate (Open/Close) arbitrarily from the "Live" page. For example, an operator can remotely control lights in a place where the camera is installed by connect- ing the terminal to the light controller. ■...
  • Page 71 1. (Subsequent areas will be num- The VMD information can be searched by some of Panasonic network disk recorders. Refer to the operat- bered in the order of selection.) ing instructions of the connected devices for further [Status] information about the functions and settings.

  • Page 72: Set The Vmd Areas [Vmd Area]

    Set the VMD areas [VMD area] Set the areas to activate the VMD function. Important: • When the settings are being configured on the setup menu, sometimes the VMD function may not work cor- rectly. Step 1 Step 3 Set the video motion detection area by dragging the Click the [Set] button after completing the settings. mouse on the screen. →...

  • Page 73: Configuration Of The Settings Relating To The Mail Notification [Notification]

    Configuration of the settings relating to the mail notification [Notification] Click the [Notification] tab on the "Alarm" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the alarm mail can be configured. It is necessary to configure the settings of the mail server to perform the mail notification.

  • Page 74: Configure The Settings Relating To Panasonic Alarm Protocol [Notification]

    Configure the settings relating to Panasonic alarm protocol [Notification] Click the [Notification] tab on the "Alarm" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to Panasonic alarm protocol can be configured in this section. [Retry times] Select a retry time for the Panasonic alarm protocol.

  • Page 75: Configure The Setting Relating To The Image Recognition [Advanced Func.]

    Configure the setting relating to the image recognition [Advanced func.] The setting relating to the XML notification, destinations of information about the face detection and the settings relating to the face detection can be configure on the "Advanced func." page. The "Advanced func."...

  • Page 76: Configuration Of The Settings Relating To The Face Detection [Face Detection]

    [Destination path name] [Password] Configure the settings for the destination directory to Enter a password. Available number of characters: 0 - 32 characters be used for the XML notification of the face detection. Default: None (blank) [User name] Enter a user name. Available number of characters: 0 - 32 characters Default: None (blank) Configuration of the settings relating to the face detection...

  • Page 77: Configure The Settings Relating To The Authentication [User Mng.]

    Configure the settings relating to the authentication [User mng.] The settings relating to the authentication such as users and PCs restrictions for accessing the camera can be con- figured on the "User mng." page. The "User mng." page has 3 tabs; the [User auth.] tab, the [Host auth.] tab and the [System] tab. Configure the settings relating to the user authentication [User auth.] Click the [User auth.] tab on the "User mng."...

  • Page 78: Configure The Settings Relating To The Host Authentication [Host Auth.]

    Configure the settings relating to the host authentication [Host auth.] Click the [Host auth.] tab on the "User mng." page. (☞ Pages 24 and 25: How to display/operate the setup menu) The restriction settings of PCs (IP address) from accessing the camera can be configured on this page. [Host check] By clicking [C] of "Host check", the registered host can be selected and the selected host’s IP address can be checked.

  • Page 79: Configure The Settings Relating To The Priority Stream [System]

    Configure the settings relating to the priority stream [System] Click the [System] tab on the "User mng." page. (☞ Pages 24 and 25: How to display/operate the setup menu) The description below is the configuration of the priority stream that can transmit images without deteriorating the image quality and refresh interval even when multiple users access concurrently. • When "Best effort" is selected for "Transmission pri- ority"...

  • Page 80: Configure The Settings Of The Servers [Server]

    Configure the settings of the servers [Server] The settings relating to the mail server, the FTP server and the NTP server can be configured on this page. The "Server" page has 3 tabs; the [Mail] tab, the [FTP] tab and the [NTP] tab. Configure the settings relating to the mail server [Mail] Click the [Mail] tab on the "Server"...

  • Page 81: Configure The Settings Relating To The Ftp Server [Ftp]

    Configure the settings relating to the FTP server [FTP] Click the [FTP] tab on the "Server" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the FTP server used to transmit the alarm images can be configured on this page. [FTP server address] Enter the IP address or the host name of the FTP server.

  • Page 82: Configure The Settings Relating To The Ntp Server [Ntp]

    Configure the settings relating to the NTP server [NTP] Click the [NTP] tab on the "Server" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the NTP server such as the NTP server address, port number, etc. can be configured on this page. Important: • Use an NTP server when the more accurate time & date setting is required for the system operation.

  • Page 83: Configuring The Network Settings [Network]

    Configuring the network settings [Network] The network settings and the settings relating to DDNS (Dynamic DNS) and SNMP (Simple Network management Protocol) can be configured on the "Network" page. The "Network" page has 4 tabs; the [Network] tab, the [DDNS] tab, the [SNMP] tab and the [FTP img. trans.] tab. Configure the network settings [Network] Click the [Network] tab on the "Network"...
  • Page 84 [IP address(IPv6)] Note: When "On" is selected for "Manual", manual entry of • Multiple IP addresses are unavailable even when the IPv6 address is required. using the DHCP function. Refer to the network Do not enter an address already in use. administrator for further information about the set- tings of the DHCP server. Note: • When connecting to the manually configured IPv6 [Subnet mask] address beyond the router, use an IPv6 compatible...
  • Page 85 10M-Full: 10 Mbps full-duplex Note: 10M-Half: 10 Mbps half-duplex • Due to port forwarding, the port number may some- Default: Auto times be changed. When the number is changed, it is necessary to change the port numbers registered [Max RTP packet size] in the PC and recorders, etc. Select "Unlimited(1500byte)"...
  • Page 86 ■ HTTPS [CA Certificate - Information] Displays the information of the server certificate. It is possible to enhance the network security by encrypting the access to cameras using the HTTPS When the [Confirm] button is clicked, the registered function. information of the installed server certificate will be dis- Refer to page 89 for how to configure the HTTPS set- played in the "CA Certificate - Confirm"...
  • Page 87 "Image quality setting" of "JPEG" lower. [Easy IP Setup accommodate period] Select "20min" or "Unlimited" to determine how long the network setting operation using the Panasonic IP setting software can be allowed since the camera starts 20min: The camera information display and the net-...
  • Page 88 Note: • Refer to the network administrator for the addresses of each server. • The port forwarding function changes a global IP address to a private IP address, and "Static IP masquerade" and "Network Address Translation (NAT)" have this function. This function is to be set in a router. • To access the camera via the Internet by connecting the camera to a router, it is necessary to assign a respec- tive HTTP port number for each camera and address translation by using the port forwarding function of the router.

  • Page 89: Configure The Https Settings

    Configure the HTTPS settings Click the [Network] tab on the "Network" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to the HTTPS protocol that can enhance the network security by encrypting the access to cameras on this page. The HTTPS settings will be configured in the following procedure. Generation of the CRT key (SSL encryption key) When using the self-signed certificate When using the server certificate...

  • Page 90: Generation Of The Crt Key (Ssl Encryption Key)

    Generation of the CRT key (SSL encryption key) Important: • When the self-signed certificate or server certificate is valid, it is impossible to generate the CRT key. • When the server certification is used, the available key size varies depending on the Caches the available key size in advance. • To generate the CRT key, it may take around 1 minute when the key size is 1024 bit and around 2 minutes when the key size is 2048 bit. Do not operate the web browser until the generation of CRT key is complete. While the CRT key is being generated, the refresh interval and line speed may be lower.

  • Page 91: Generation Of The Self-Signed Certificate (Security Certificate)

    Generation of the self-signed certificate (security certificate) Important: • If the CRT key is not generated, it is impossible to generate the self-signed certificate. Note: • The available characters for [Common Name], [State], [Locality], [Organization], [Organizational Unit] are 0-9, A-Z, a-z and the following marks. – . _ , + / ( ) • When the camera is connected to the Internet, enter the address name or host name to access via the Internet for "Common Name". In this case, the security alert window will be displayed each time the camera is locally accessed, even if the security certificate is installed.
  • Page 92 Common name of the self- The self-signed certificate has signed certificate already been generated and validated. • When the [Confirm] button is clicked, the registered information of the self-signed certificate (security certificate) will be displayed in the "Self-signed Certificate - Confirm" dialog box. • When the [Delete] button is clicked, the generated self-signed certificate (security certificate) will be deleted.

  • Page 93: Generation Of Csr (Certificate Signing Request)

    Generation of CSR (Certificate Signing Request) Important: • If the CRT key is not generated, it is impossible to generate the CSR. • Before generating the CSR file, configure the following settings on "Internet Options" of the web browser in ® advance. (Click "Internet Options…" under "Tools" of the menu bar of Internet Explorer , and then click the [Security] tab.) • Register the camera for "Trusted sites". • Click the [Custom Level...] button to open the "Security Setting" window, and check the [Enable] radio but- ton of "File Download" under "Downloads". • Click the [Custom Level...] button to open the "Security Setting" window, and check the [Enable] radio but- ton of "Automatic prompting for file downloads" under "Downloads". Item Description Available number...

  • Page 94: Installation Of The Server Certificate

    Installation of the server certificate Important: • If the CSR file is not generated, it is impossible to install the server certificate (security certificate). For the installation, the server certificate issued by CA is required. • When the [Delete] button is clicked, the installed Step 1 server certificate will be deleted. Click the [Browse...] button of "CA Certificate - CA • When "HTTPS" is selected for "Connection", it is Certificate install". impossible to delete the server certificate.

  • Page 95: Configuration Of The Connection Protocol

    Configuration of the connection protocol Step 1 Note: Select "HTTP" or "HTTPS" for "Connection" to deter- • The camera will restart after the connection setting mine the protocol used to access the camera. is changed. HTTP: Only the HTTP connection is available. • Notation when using the self-signed certificate: HTTPS: Only the HTTPS connection is available. If the camera is accessed using the HTTPS protocol for the first time, the warning window will be dis- Step 2 played.

  • Page 96: Access The Camera Using The Https Protocol

    Access the camera using the HTTPS protocol Step 1 Step 3 Start up the web browser. Press the [Enter] key on the keyboard. → The "Live" page will be displayed. Step 2 When the security alert window is displayed, install the security certificate.
  • Page 97 OS: Windows 7, Windows Vista, Windows XP Web browser: When using Internet Explorer 7, Internet Explorer 8 When using Internet Explorer 7 or Internet Explorer 8 with Windows XP, note that some of the displayed windows may differ from the following descriptions. Step 1 Step 4 Access the camera using the HTTPS protocol.
  • Page 98 Step 6 Step 9 Select "Place all certificates in the following store", and Click "Finish". click "Browse...". Step 10 Step 7 Click "Yes". Select "Trusted Root Certificate Authorities", and click "OK". Step 8 → When the import is successfully completed, the Click "Next".
  • Page 99 OS: Windows XP Web browser: When using Internet Explorer 6 Step 1 Step 4 Access the camera using the HTTPS protocol. Click "Next" according to the procedures displayed on the displayed on "Certificate Import Wizard". Step 2 Click "View Certificate". Note: • If this window is displayed when accessing a device other than the camera or a website, a security prob-...
  • Page 100 Step 6 When the security alert window is displayed, click "Yes". → When the import is successfully completed, the screen "The import was successful." will be dis- played. Step 7 Click "OK". → When the browser is restarted after the certificate is imported, "Certificate Error"...

  • Page 101: Configure The Settings Relating To Ddns [Ddns]

    Refer to the DDNS service providers for the selection and configuration of the DDNS services other than the "Viewnetcam" service. Note: • "Viewnetcam" is a Dynamic DNS service designed for use with Panasonic Network Cameras. Refer to the "Viewnetcam" website (http://www.viewnetcam.com/) for further information about the service. About DDNS services (IPv4/IPv6) By using a DDNS service, it becomes possible to view camera images via the Internet The DDNS service associates dynamic global addresses and domain names.

  • Page 102: Configuration Of The Ddns Service (Example Of The "Viewnetcam" Service)

    Configuration of the DDNS service (Example of the "Viewnetcam" service) e Current global address is automatically "Viewnetcam" registered via "*****.viewnetcam.com". service server DNS server Provider w "*****.viewnetcam.com" and the Internet r Global address is current global address is obtained via the URL automatically registered.

  • Page 103: When Using The "Viewnetcam" Service

    When using the "Viewnetcam" service [Personal(Camera) URL] The URL of the camera registered for "Viewnetcam". When performing the initial settings, the temporary URL will be displayed by clicking the [Set] button. [Your Account Link] When the displayed URL is clicked, the registration window for the "Viewnetcam"...

  • Page 104: Procedure To Register Information For The "Viewnetcam" Service

    Procedure to register information for the "Viewnetcam" service Note: Step 1 • When the registration for the "Viewnetcam" service Click the displayed URL "https://**********" of "Your is completed, the URL of the camera registered for Account Link". "Personal(Camera) URL". It may take up to around → The registration window for "Viewnetcam" will be 30 minutes until the URL of the registered camera is displayed in a newly opened window.

  • Page 105: When Using "Dynamic Dns Update

    When using "Dynamic DNS Update" [Access interval] Select the interval to access the Dynamic DNS Update service server to check the IP address and the host name from the following. 10min/ 20min/ 30min/ 40min/ 50min/ 1h/ 6h/ 24h Default: 24h [Host name] Enter the host name to be used for the Dynamic DNS Update service.

  • Page 106: Configure The Settings Relating To Snmp [Snmp]

    Configure the settings relating to SNMP [SNMP] Click the [SNMP] tab on the "Network" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings relating to SNMP can be configured on this page. It is possible to check the status of the camera by connecting to the SNMP manager. When using the SNMP function, contact the network administrator. [System name] Enter a system name to be used to manage the camera with the SNMP function.
  • Page 107 [Transmission interval] Select the interval for the FTP periodic image transmis- sion from the following. 1s/ 2s/ 3s/ 4s/ 5s/ 6s/ 10s/ 15s/ 20s/ 30s/ 1min/ 2min/ 3min/ 4min/ 5min/ 6min/ 10min/ 15min/ 20min/ 30min/ 1h/ 1.5 h/ 2h/ 3h/ 4h/ 6h/ 12h/ 24 h Default: 1s [Image capture size] Select the capture size of images to be transmitted...

  • Page 108: Configure The Schedule Settings Of The Ftp Periodic Image Transmission [Ftp Img. Trans.]

    Configure the schedule settings of the FTP periodic image transmission [FTP img. trans.] Click the [FTP img. trans.] tab on the "Network" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The schedule settings of the FTP periodic image transmission can be configured in this section. Refer to page 107 for further information about the settings relating to the FTP periodic image transmission.

  • Page 109: How To Delete The Set Schedule

    How to delete the set schedule Step 1 Uncheck the check box of the set day of the week. Step 2 Click the [Set] button after completing the settings. → The schedule of the selected day of the week is deleted.

  • Page 110: Configure The Settings Relating To The Schedules [Schedule]

    Configure the settings relating to the schedules [Schedule] On the "Schedule" page, it is possible to configure the settings relating to schedules as follows. • Alarm permission (Alarm input will be received only in the specified schedule.) • VMD permission (Video motion detection will be active only in the specified schedule.) • Access permission (Access to the camera will be allowed only in the specified schedule.) • H.264 recording (SD recording will be performed only in the specified schedule.) The "Schedule" page has only the [Schedule] tab. Up to 5 schedules can be set. H.264 recording: The SD recording will be performed at the designated time in the schedule.

  • Page 111: Maintenance Of The Camera [Maintenance]

    Maintenance of the camera [Maintenance] System log check, firmware upgrade, status check and initialization of the setup menu can be performed on this page. The "Maintenance" page has 4 tabs; the [System log] tab, the [Upgrade] tab, [Status] tab and the [Default reset] tab.

  • Page 112: Upgrade The Firmware [Upgrade]

    Upgrade the firmware [Upgrade] Click the [Upgrade] tab of the "Maintenance" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The current firmware can be checked and upgraded to the latest version on this page. Contact the dealer for further information about the firmware upgrade. Step 3 Click the radio button respective to the desired option to determine whether or not to initialize the settings after completing the firmware upgrade.
  • Page 113 Important: • After completing the upgrade, delete temporary internet files. (☞ Page 124) • Upgrade the firmware using a PC in the same sub- net as the unit. • Follow the instructions from the dealer when upgrading the firmware. • Application software upgrade Use the designated file (extension: img) for the firm- ware upgrade. The name of the firmware to be used for the upgrade should be "model name (Use small letters. "WV"...

  • Page 114: Check The Status [Status]

    Note: • Refer to the "Readme" file on the provided CD-ROM for further information about the contents of the dis- played statuses (relating to the "Viewnetcam" ser- vice, the UPnP function, or the self check). Or refer to our website (http://panasonic.net/pss/security/ support/info.html) for further information. [Viewnetcam] Server: The URL of the "Viewnetcam" service server will be displayed. Status: The registration status for the "Viewnetcam"...

  • Page 115: Reset The Settings/Reboot The Camera [Default Reset]

    Reset the settings/Reboot the camera [Default reset] Click the [Default reset] tab of the "Maintenance" page. (☞ Pages 24 and 25: How to display/operate the setup menu) The settings and the HTML data of the camera can be initialized and reboot of the camera can be performed on this page. Note: • To initialize the network settings (☞...

  • Page 116: Viewing Help

    Viewing Help If you want to know anything about operation or setup methods on screen, display the "Help" screen. Displaying the Help screen Step 1 Step 2 Click the [Setup] button. Click the [Help] button. → The setup screen is displayed. →...

  • Page 117: About The Displayed System Log

    About the displayed system log Error indications relating to SMTP Category Indication Description POP3 server error Authentication error. • E ntered user name or password may be incor- rect. Check if the mail settings are configured correctly. Failed to find the POP3 server. • T he IP address of the server may be incorrect. Check if the IP address of the server is config- ured correctly.
  • Page 118 Error indications relating to "Viewnetcam" Category Indication Description Viewnetcam server error Failed to resolve the Viewnetcam • T he designated IP address of the DNS may be server address from DNS. incorrect. Check if the DNS settings are config- ured correctly. • T he DNS server may be down. Ask the network administrator. Connection error No response from the Viewnetcam • T he "Viewnetcam" server may be down. Ask the server.
  • Page 119 Log indications relating to HTTPS Category Indication Description HTTPS Self-signed Certificate - Generated • G eneration of the self-signed certificate is com- plete. Self-signed Certificate - Deleted • D eletion of the self-signed certificate is complete. Certificate Signing Request - • G eneration of the CSR (Certificate Signing Generated Request) is complete. CA Certificate - Installed • I nstallation of the server certificate is complete. CA Certificate - Deleted • D eletion of the server certificate is complete.

  • Page 120: Troubleshooting

    Cannot access from the web mal. browser. If not, proceed either of the following. • Reboot the camera and change the IP address by using the Panasonic IP setup software within 20 min- utes after the restart. • Reboot the camera while holding the [INITIAL SET] Installation button on the camera. The camera will be initialized...
  • Page 121 Reference Symptom Cause/solution pages • Is the same IP address provided to other devices? Are there contradictions between the address and the network subnet to be accessed? <When the camera and the PC are connected in the same subnet> Are the IP addresses of the camera and the PC set in a common subnet? Or is "Use Proxy Server" for the settings of the web browser checked? –...
  • Page 122 Reference Symptom Cause/solution pages • Are the network settings of the camera correct? Set the default gateway or DNS server address correctly. To use the DDNS service, check that the settings are cor- rect. • Is the setting for "Default gateway" on the "Network" 83, 84 page configured? Or is the setting correct? When communicating using IPv4 Configure the setting for "Default gateway" of "IPv4 net- work"...
  • Page 123 Reference Symptom Cause/solution pages • Is the user name and password changed? While accessing the camera, when changing the user name and password of another user logging into the cam- Authentication window is dis- – era on another web browser, the authentication window played repeatedly. will be displayed each time the screen is changed or refreshed.
  • Page 124 Reference Symptom Cause/solution pages • Is "Allow" selected for "FTP access to camera" on the [Network] tab of "Network" page? It is necessary in advance to select "Allow" for "FTP access to camera" on the [Network] tab of the "Network" Cannot obtain images on the SD page. memory card. • Is the entered password correct? Restart the web browser and enter the password again. • Access to the SD memory card may be failed. Restart the – web browser and retry to obtain images. • Is the viewer software installed on the PC? Install the viewer software on a PC. • Is the version of DirectX 9.0c or later? Check the version of DirectX as follows. ® (1) Select "Run…" from the start menu of Windows – (2) Enter "dxdiag" in the displayed dialog box and click the [OK] button. No image is displayed. If the version of DirectX is older than 9.0c, upgrade it.
  • Page 125 Failed to write/read data on the Format the SD memory card. SD memory card. • Is any recognition error received when the "Diag." of "Mail notification" or "Panasonic alarm protocol" is used? 34, 73, 74 Format the SD memory card. • Isn't the SD memory card out of order? There are limited times to overwrite on an SD memory card. When frequently overwritten, it may be at the end of –...
  • Page 126 Reference Symptom Cause/solution pages • Is the viewer software installed on the PC? The alarm occurrence indication Confirm that the viewer software "Network Camera View button, the [AUX] buttons and 4S" is installed. the SD recording status indica- tor on the "Live" page do not • Is "Real time" selected for "Alarm status update mode"? display the current status in real time.
  • Page 127 Reference Symptom Cause/solution pages • This may occur due to the display adapter and driver combination. When this has occurred, first update the driver of the dis- play adapter to the latest version. If updating the driver does not solve the problem, adjust the hardware acceleration as follows. The following are descriptions for when Windows XP is installed on the PC in use.
  • Page 128 "Install" button on the displayed "Security Warning" lowing Active X control – window. 'nwcv4Ssetup.exe' from 'Panasonic System Networks Co.,Ltd.'. Click here to install..." • Click "Internet Options…" under "Tools" of the menu bar of Internet Explorer, and then click the [Security] tab. Click "Internet" in the "Select a Web content zone to specify its security settings:" section. Then, click the [Custom...

  • Page 129: Directory Structure Of Drive B

    (Ex.img_1001010123000001.jpg) 10010112.02 Destination where images are to be saved by the SD memory PULL recording function of Panasonic network disk recorder Destination where log files are to be saved (for the system administration) 10000001 M_ALARM Video saved at the alarm occurrence (Approx. 2 MB per file) (Ex.10000001_101224193826_A.mp4)
  • Page 130 Panasonic System Networks Company of America, Unit of Panasonic Corporation of North America http://panasonic.net www.panasonic.com/business/ For customer support, call 1.800.528.6747 Importer's name and address to follow EU rules: Three Panasonic Way, Secaucus, New Jersey 07094 U.S.A. Panasonic Testing Centre Panasonic Canada Inc. Panasonic Marketing Europe GmbH 5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada Winsbergring 15, 22525 Hamburg F.R.Germany (905)624-5010 www.panasonic.ca...

This manual is also suitable for:

Wv-sw355eWv-sw352eWv-sw352

Table of Contents
