OMRON
Digital Automatic Blood Pressure Monitor
HEM-907
Model
INSTRUCTION MANUAL
Thank you very much for purchasing the
OMRON Digital Automatic Blood Pressure
Monitor.
Please read this Instruction Manual thoroughly
to ensure safe and correct use of the monitor.
Please keep this Instruction Manual for future
reference.

Table of Contents

Be Sure to Read This Section
Notes on Safety..................................1
Know Your Unit
Features of the Product......................4
Components of the Product ...............5
Options ...........................................6
Names of the Parts.........................7
while the unit is in use ....................9
Preparations before Measurement
How to Apply the Cuff ......................11
of Battery Pack .............................14
How to Measure Blood Pressure
SINGLE Mode ..............................16
AVG. Mode ...................................18
MANU. Mode ................................20
CHECK Mode ...............................22
List of Error Codes ...........................24
Troubleshooting ...............................25
Specifications
Specifications ...................................26
Exemptions on warranty...................27
MEMO (Blank pages)..................28-30
13
............

Advertisement

Table of Contents
loading

Related Manuals for Omron HEM-907

Summary of Contents for Omron HEM-907

  • Page 1: Table Of Contents

    Model INSTRUCTION MANUAL Table of Contents Thank you very much for purchasing the Be Sure to Read This Section OMRON Digital Automatic Blood Pressure Notes on Safety........1 Monitor. Know Your Unit Features of the Product......4 Please read this Instruction Manual thoroughly to ensure safe and correct use of the monitor.

  • Page 2: Notes On Safety

    Notes on Safety Warning When a person other than the doctor or medical employee uses this monitor, self-diagnosis of the measured results or treatment is dangerous. Please consult and follow the instruction of the doctor. • Self-diagnosis may worsen the disease. If you encounter any problem during measurement such as inflation does not stop, remove the cuff or pull out the air tube from the main unit.
  • Page 3 Notes on Safety Caution In the following cases, check the readings with the stethoscope. (1) When an irregular pulse wave is displayed • The reading may be erroneous due to external vibration or patient's body movement. (2) When erroneous reading takes place or the measured value is doubtful •...
  • Page 4 Notes on Safety Caution Do not use a cellular phone near this unit. • This unit may malfunction. Do not use this unit in a moving vehicle. • This may result in erroneous measurement. Do not install parts and/or instrument that are not specified for this unit. •...

  • Page 5: Features Of The Product

    Features of the Product OMRON Digital Automatic Blood Pressure Monitor, Model HEM-907 is developed to measure blood pressure with accuracy and simple operation in the doctor's consultation room or at bedside. • One-push operation Just by wrapping the cuff and pushing the START Button (to start measurement), blood pressure and pulse rate can be measured.

  • Page 6: Components Of The Product

    Cuff / bladder set M * Model: HEM-970-CR19 Air tube 1.0m (39 1/3") Applicable arm circumference: 22 to 32 cm Model: HEM-TUBE-100 AC adapter Model: (Refer to OMRON dealer for the appropriate AC adapter). Note: Actual AC adapter may look different from illustration.

  • Page 7: Options

    Air tube 1.3 m * Air tube 1.0 m * AC adapter Battery pack (48H907N) * Model: HEM-TUBE-130 Model: HEM-TUBE-100 Model: (Refer to OMRON Model: HEM-907-PBAT dealer for the appropriate AC adapter). Stand exclusive for this unit * Wall-hanging kit *...

  • Page 8: Names And Functions Of The Parts

    Names and Functions of the Parts Names of the Parts Main unit 1. Display 6. ON/OFF (power) Button 2. HIDE (non-display) Button 7. START Button (to start measurement) 8. DEFLATION (deflation control) /Display Switch Button 3. DC jack 9. Air Connector 4.
  • Page 9 Names and Functions of the Parts Display Systolic blood pressure When the measurement is finished: Displays systolic blood pressure. When an error occurred: Displays error code. In the CHECK Mode: Displays pressures. Diastolic blood pressure Ready to Measure / During measurement: Displays pressures. Pulse rate synchronization When the measurement is finished: Displays diastolic blood pressure.

  • Page 10: Functions And Setting While The Unit Is In Use

    Names and Functions of the Parts Functions and setting while the unit is in use (1) Pressure setting function P - SET A function that can switch the pressure setting Inflation can be set by AUTO (automatic setting) method or the pressure value setting method. AUTO (Automatic setting): Can be used when the SINGLE, AVG., or MANU.
  • Page 11 Names and Functions of the Parts List of Functions for each Mode Measurement Single Average Auscultation Check Mode measurement (AVG.) (MANU.) (CHECK) Function (SINGLE) Pressure setting function Non-display function Manual deflation control function (4) Function setting You can set the number of measurements, the waiting time until the start of 1st measurement, and the measurement interval for the AVG.

  • Page 12: Digital Automatic Blood Pressure Monitor Hem

    How to Apply the Cuff The cuff of OMRON Digital Automatic Blood Pressure Monitor HEM-907 plays an important role of collecting the information on blood vessels. Please wrap the cuff correctly according to the procedure. Warning General advice Do not wrap the cuff over the arm to which •...
  • Page 13 How to Apply the Cuff 4. Place the right hand of the patient with the palm of hand facing upward. 5. Align the Artery Position Mark with the brachial artery. 6. Wrap the cuff snugly using both hands and securely fasten it with the Velcro tape.

  • Page 14: How To Use The Power Source

    • Be sure to operate the Buttons to check this unit for correct operation. Connect the AC adapter to the DC jack of the main unit [1] and the electric outlet [2]. • When using the optional battery pack 48H907N (Model: HEM-907-PBAT), the unit also function as the charger.

  • Page 15: Installation And Replacement Of Battery Pack

    How to Use the Power Source Installation and Replacement of Battery Pack (option) Warning Caution If the fluid in the battery gets into your eye, wash Do not short-circuit the polarities of the the eye with sufficient water without rubbing the optional battery pack with a metal object such eye, then immediately consult the doctor for as wire.

  • Page 16: How To Measure Blood Pressure

    How to Measure Blood Pressure Warning Caution In the following cases, check the readings If any abnormal matter occurs during the with the stethoscope. measurement such as inflation does not stop, (1) When an irregular pulse wave is displayed remove the cuff or pull out the air tube from •...

  • Page 17: Single Mode

    How to Measure Blood Pressure (in SINGLE Mode) 1. Push the ON/OFF (power) Button to turn on the power. ON/OFF START HIDE P - SET MODE SINGLE MANU. AVG. CHECK STOP AUTO 2. Set the MODE Selector to "SINGLE". mmHg ON/OFF START HIDE...
  • Page 18 How to Measure Blood Pressure (in SINGLE Mode) 5. Push the START Button to start the measurement. mmHg • Do not push the ON/OFF ON/OFF START Button without wrapping the cuff on START HIDE START the arm. HIDE P-SET MODE SINGLE AVG.

  • Page 19: Avg. Mode

    How to Measure Blood Pressure (in AVG. Mode) 1. Push the ON/OFF (power) Button to turn on the power. ON/OFF START HIDE P - SET MODE SINGLE AVG. MANU. CHECK STOP AUTO 2. Set the MODE Selector to "AVG.". The factory-set values are set as follows: mmHg ON/OFF •...
  • Page 20 How to Measure Blood Pressure (in AVG. Mode) 5. Push the START Button to start the measurement. The unit automatically starts measurement according to mmHg ON/OFF the waiting time until the start of 1st measurement. After displaying the results of 1st measurement, the monitor will measure blood pressure for the set number of START times automatically at the specified intervals.

  • Page 21: Manu. Mode

    How to Measure Blood Pressure (in MANU. Mode) 1. Push the ON/OFF (power) Button to turn on the power. ON/OFF START HIDE P - SET MODE SINGLE AVG. MANU. CHECK STOP AUTO 2. Set the MODE Selector to "MANU.". mmHg ON/OFF START HIDE...
  • Page 22 How to Measure Blood Pressure (in MANU. Mode) 5. Place the stethoscope on the patient's arm. ON/OFF START HIDE P-SET MODE SINGLE AVG. MANU. CHECK STOP AUTO 6. Push the START Button to start the measurement. • Do not push the START Button without wrapping the mmHg ON/OFF cuff on the arm.

  • Page 23: Check Mode

    (1) Generally, the test tolerance of blood pressure monitor (accuracy of pressure when shipped from the factory) should not exceed 4 mmHg. (2) If the CHECK result shows a difference of +/- 5 mmHg or more, contact the store where you purchased this unit or the nearest OMRON dealer.

  • Page 24: How To Clean The Unit After Use

    How to Clean the Unit after Use Caution General advice When cleaning this unit, please unplug the • Do not clean this unit with gasoline, paint thinner, or AC adapter from the electric outlet. high concentration alcohol. • You may suffer electric shock. •...

  • Page 25: List Of Error Codes

    • Pulse rate is not within the range of 30 to 199 beats/min. Device error • Contact the store where you purchased this • This is an indication of trouble of the main monitor or the nearest OMRON dealer. unit.

  • Page 26: Troubleshooting

    Troubleshooting If trouble occurs while using the unit, please check the following. Trouble What to inspect How to correct Wrap the cuff correctly, and Is the cuff wrapped correctly? measure again. (Refer to Page 11 and 12.) Ask the patient not to move Did the patient moved his/her arm his/her arm or body during The unit inflates to...

  • Page 27: Specifications

    Specifications Name: OMRON Digital Automatic Blood Pressure Monitor Model: HEM-907 Display: Digital display Measurement: Oscillometric method Measurement Range: Pressure; 0 to 299 mmHg Pulse rate; 30 to 199 beats/min Accuracy: Pressure; Within ±4 mmHg Pulse rate; Within ±5% of reading...

  • Page 28: Exemptions On Warranty

    1. When a trouble and/or damage occurs caused by the maintenance and/or repair conducted by a person other than OMRON or the dealer specified by OMRON 2. The trouble and/or damage of OMRON product caused by the product of other manufacturer not delivered by OMRON 3.

  • Page 29: Memo (Blank

    MEMO...
  • Page 30 MEMO...
  • Page 31 MEMO...
  • Page 32 OMRON HEALTHACARE SINGAPORE PTE LTD 83 Clemenceau Avenue, #11-01 UE Square Singapore 239920 1615641-2B...
