Omron HEM-9200T Instruction Manual

EN Do not take measurements more than necessary. It may cause bruising
due to blood flow interference.
Remove the arm cuff if it does not start deflating during the measurement.
Do not use this device on infants or persons who cannot express their
intentions.
Do not use the device for any purpose other than measuring blood
Blood Pressure Monitor pressure.
Use only the approved arm cuff for this device. Use of other arm cuffs
may result in incorrect measurement results.
Model HEM-9200T
Do not use a mobile phone or other devices that emit electromagnetic
Instruction Manual fields, near the device. This may result in incorrect operation of the
device.
Do not disassemble the monitor or arm cuff. This may cause an
5130713-0A
inaccurate reading.
Do not use in a location with moisture, or a location where water may
Introduction
splash on the device. This may damage the device.
Do not use the device in a moving vehicle (car, airplane).
Intended Use
Read "What to do if your systolic pressure is more than 210 mmHg" of this
This device is a digital monitor intended for use in measuring blood pressure
instruction manual, if your systolic pressure is known to be more than 210
and pulse rate in adult patient population. The device detects the
mmHg. Inflating to a higher pressure than necessary may result in
appearance of irregular heartbeats during measurement and gives a
bruising where the arm cuff is applied.
warning signal with the measurement result.
AC Adapter (optional accessory)
Please read this instruction manual thoroughly before using the device.
Fully insert the power plug into the outlet.
Please keep for future reference. For specific information about your
When disconnecting the power plug from the outlet, do not pull the power
own blood pressure, CONSULT YOUR PHYSICIAN.
cord. Be sure to pull from the power plug safely.
When handling the power cord, take care not to do the following:
Important Safety Information
Do not damage.
Do not tamper with it. Do not forcibly bend or pull.
Warning: Indicates a potentially hazardous situation which, if not
Do not twist.
avoided, could result in death or serious injury.
Do not pinch.
General Usage Wipe the dust off from the power plug.
DO NOT adjust medication based on measurement results from this Unplug monitor when not in use.
blood pressure monitor. Take medication as prescribed by your physician.
Disconnect the power plug before cleaning.
Only a physician is qualified to diagnose and treat High Blood Pressure.
Use only an OMRON AC adapter designed for this device. Use of
This device is not intended to be a diagnostic device.
unsupported adapters may damage and/or may be hazardous to the
Consult your physician before using the device for any of the following
device.
conditions: common arrhythmias such as atrial or ventricular premature
Battery Usage
beats or atrial fibrillation, arterial sclerosis, poor perfusion, diabetes, age,
Do not insert the batteries with their polarities incorrectly aligned.
pregnancy, pre-eclampsia, renal diseases.
Use only 4 "AA" alkaline or manganese batteries with this device. Do not
Note that PATIENT motion, trembling, shivering may affect the
use other types of batteries. Do not use new and used batteries together.
measurement reading.
Remove the batteries if the device will not be used for three months or
Do not use the device on the injured arm or the arm under medical
more.
treatment.
General Precautions
Do not apply the arm cuff on the arm while being on an intravenous drip
• Do not forcibly crease the arm cuff or the air tube excessively.
or blood transfusion.
• Do not press the air tube while taking a measurement.
Consult your physician before using the device on the arm with an
• To unplug the air plug, pull on the air plug at the connection with the
arterio-venous (A-V) shunt.
monitor, not the tube itself.
Do not use the device with other medical electrical (ME) equipment
• Do not drop the monitor or subject device to strong shocks or vibrations.
simultaneously.
• Do not inflate the arm cuff when it is not wrapped around your arm.
Do not use the device in the area the HF surgical equipment, MRI, or CT
• Do not use the device outside the specified environment. It may cause an
scanner exists, or in the oxygen rich environment.
inaccurate reading.
The air tube or the AC adapter cable may cause accidental strangulation
• Dispose of the device, components and optional accessories according to
in infants.
applicable local regulations. Unlawful disposal may cause environmental
Contains small parts that may cause a choking hazard if swallowed by
pollution.
infants.
Keep the battery out of reach of children.
1. Know Your Device
Data Transmission
Do not use this product on aircraft or in hospitals. Please remove the Contents:
battery from the unit. This product emits radio frequencies (RF) in the
Monitor, arm cuff, 4 "AA" batteries, instruction manual, quick start
2.4 GHz band, use of this product in locations where RF is restricted is
guide
not recommended.
Monitor:
The use of RF in this product is licensed for use by the FCC, for further
information on any potential restrictions refer to documentation on
®
Bluetooth usage by the FCC.
AC Adapter (optional accessory)
Do not use the AC adapter if the device or the power cord is damaged.
Turn off the power and unplug the power cord immediately.
Plug the AC adapter into the appropriate voltage outlet. Do not use in a
multi-outlet plug.
Never plug in or unplug the power cord from the electric outlet with wet
hands.
A. Display
Caution: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury to the user B. START/STOP button
or patient or damage to the equipment or other property.
General Usage
Always consult your physician. Self-diagnosis of measurement results Arm cuff:
and self-treatment are dangerous.
Consult your physician before using the device for any of the following
conditions:
•If you have had a mastectomy.
•People with severe blood flow problems or blood disorders as cuff
inflation can cause bruising.
Display:
I
J
K
L
M
N
L O
I. SYNC symbol
J. Connection symbol
K. OK symbol
L. Systolic blood pressure
M. Diastolic blood pressure
N. Battery symbol (low/depleted)
O. Heartbeat symbol
(Flashes during measurement.)
1.1 Display symbols
Irregular Heartbeat Symbol (
Do not break it.
When the monitor detects an
irregular rhythm two or more times
Do not bundle during use.
during the measurement, the
Do not place under heavy objects.
irregular heartbeat symbol will
appear on the display with the
measurement values.
An irregular heartbeat rhythm is
defined as a rhythm that is 25%
less or 25% more than the average
rhythm detected while the monitor
is measuring the systolic and diastolic blood pressure.
If the irregular heartbeat symbol displays with your measurement
results, we recommend you consult your physician. Follow the
directions of your physician.
Movement Error Symbol (
The movement error symbol is displayed if you move your body during
the measurement. Please remove the arm cuff, and wait 2 - 3 minutes.
Take another measurement, remain still during measurement.
SYNC Symbol ( )
The SYNC symbol (
Telehealth service receiver or when data is not transmitted
successfully. Please see "Connecting failure. Data is not being
transmitted." in section 4.2.
1.2 Wireless Function
Before use, thoroughly read the instruction manual included with the
Telehealth service receiver (in some cases, receiver maybe your smart
phone) being used with this blood pressure monitor for instruction
about your monitor to Telehealth service receiver, and receiver
transmission range. It will be necessary for the blood pressure monitor
to be within the receiver's transmission range to successfully transfer
data. This Omron blood pressure monitor is designed to connect to
®
specific Bluetooth Smart receivers, and is not guaranteed to connect
A C
®
to all Bluetooth Smart compatible devices and Telehealth service
receiver. "Omron Healthcare, Inc. shall not be liable for loss of use
or any other special, incidental, consequential or indirect costs,
E expenses or damages due to improper usage of this monitor."
D 1.3 Before Taking a Measurement
To help ensure an accurate reading, follow these directions:
B
1. Avoid bathing, drinking alcohol or caffeine, smoking, exercising and
C. Battery compartment eating for 30 minutes before taking a measurement. Rest for at
least 5 minutes before taking the measurement.
D. Air jack
2. Stress raises blood pressure. Avoid taking measurements during
E. AC adapter jack
stressful times.
(for optional AC adapter)
3. Measurements should be taken in a quiet place.
Arm circumference 9" - 17" (22 - 42 cm)
4. Remove tight-fitting clothing from your arm.
F F. Arm cuff
G. Air plug
H. Air tube
G
H
2. Preparation
Battery Installation
P
Below procedures are ONLY done at inserting batteries.
Q 1.
Remove the battery cover.
2.
Insert 4 "AA" batteries as
R
indicated in the battery
compartment.
S
3.
Put back the battery cover.
P. Movement error symbol
Q. Irregular heartbeat symbol Notes:
R. Deflation symbol • When the depleted battery symbol (
S. Pulse display the monitor off, then replace all batteries at the same time. Long life
alkaline batteries are recommended.
• The measurement values continue to be stored in memory even after
the batteries are replaced.
• The supplied batteries may have a shorter life.
• Dispose of the device, components and optional accessories
according to applicable local regulations. Unlawful disposal may
cause environmental pollution.
)
4.
Connect the device to the Telehealth service receiver.
Normal Heartbeat As soon as insert batteries, it will automatically start the connection
Pulse
process, as below.
Blood pressure
Irregular Heartbeat
Short Long
Pulse
Blood pressure
When the display shown above is not appeared, see "Connecting
failure." in section 4.2 first.
To retry connecting the Telehealth service receiver, remove
)
batteries and press START/STOP button for 2-3 times. Then start
with step 2 again.
Note: If your Telehealth service receiver asks for PIN code, enter 6
digits of PIN code on the rating label at the bottom of the device
to complete.
) is displayed if device is not connected to
5.
Confirm if the device is successfully connected.
If the device is connected successfully to the Telehealth service
receiver, OK symbol will appear on the display, as below.
When "Err" appears, see "Connecting failure." in section 4.2 for
more detail.
Notes:
• We recommend to keep batteries all the time, even if you chose to
use AC adapter.
• If only AC adapter is used without keeping batteries, above device
connection process (step 4 and 5) is necessary each time you unplug
and plug back the AC adapter.
3. Using the Device
3.1 Applying the Arm Cuff
Remove tight-fitting clothing or tight rolled up sleeve from your left
upper arm.
Don't place the arm cuff over thick clothes.
1.
Connect cuff plug to the unit.
) appears on the display, turn 2.
Wrap the arm cuff firmly
in place around your left
upper arm.
The bottom edge of the arm
cuff should be 1/2 inch (1 to 2
cm) above the elbow. Air tube
is on the inside of your arm
and aligned with your middle
finger.
3.
Secure closed with
the fabric fastener.
Notes:
• When you take a measurement on the
right arm, the air tube will be at the
side of your elbow. Be careful not to
rest your arm on the air tube.
• The blood pressure can differ between the right arm and the left arm,
and the measured blood pressure values can be different. OMRON
recommends to always use the same arm for measurement. If the
values between both arms differ substantially, please check with your
physician which arm to use for your measurements.
3.2 How to Sit Correctly
To take a measurement, you need
to be relaxed and comfortably
seated, under comfortable room
temperature.
• Sit on a chair with your legs uncrossed
and your feet flat on the floor.
• Sit upright with your back straight.
• Sit with your back and arm being
supported.
• The arm cuff should be placed on your
arm at the same level as your heart.
3.3 Taking a Measurement
Notes:
• To stop the measurement, press the START/STOP button once to
deflate the arm cuff.
• Remain still and do not talk while taking a measurement.
• The memory cannot view on the display.
1.
Press the START/STOP button.
The arm cuff will start to inflate automatically.
START INFLATE DEFLATE COMPLETE
What to do if your systolic pressure is more
than 210 mmHg
After the arm cuff starts to inflate, press and hold the
1/2 inch
START/STOP button until the monitor inflates 30 to 40 mmHg
(1 - 2 cm)
higher than your expected systolic pressure.
Notes:
• The monitor will not inflate above 299 mmHg.
Inflating to a higher pressure than necessary may result in
bruising where the arm cuff is applied.
2.
Transferring measured data.
As soon as the measurement is completed, the data transfer will start
automatically, as below.
When the connection symbol ( ) is not appeared, see
"Data is not being transmitted." in section 4.2 for more detail.
3.
After data transfer is completed, press the START/STOP
button to turn the monitor off.
It will automatically turn off after 2 minutes.
Note: Wait 2-3 minutes before taking another measurement. Waiting
between measurements allows the arteries to return to the
condition prior to taking a measurement.
4.
Remove the arm cuff.
DO NOT adjust medication based on measurement results from this
blood pressure monitor. Take medication as prescribed by your physician.
Only a physician is qualified to diagnose and treat High Blood Pressure.
This device is not intended to be a diagnostic device.
Always consult your physician. Self-diagnosis of measurement results
and self-treatment are dangerous.
Inflating to a higher pressure than necessary may result in bruising where
the arm cuff is applied.
