FM TUNER SECTION
Frequency Range:
Input level is expressed as the reading in open-circuit
of 75-ohm source impedance signal generator.
1. Usable Sensitivity (Mono, 98MHz)
2. S/N Ratio (60dBµ, IHF wtd)
3. THD (60dBµ, L=R, 75KHz Dev. for AH, 40KHz Dev. for C)
4. IF Rejection (10.7MHz)
5. Image Rejection (119.4MHz)
6. Capture Ratio (40dBµ)
7. AM Suppression (60dBµ, 100%mod FM, 30%mod AM)
8. Pilot Suppression (60dBµ)
9. Frequency Response
(60dBµ, 20Hz - 15KHz in, 75µS for AH, 50µS for C and
Japan)
10. Channel Separation (60dBµ, IHF wtd)
11. Alternate Channel Selectivity (±400KHz, IHF)
12. Muting Level
13. Output
14. Blend on Separation (60dBµ IHF wtd)
15. RDS Decode Sensitivity
16. Auto-search Sensitivity
PHYSICAL SPECIFICATIONS
Dimensions (Width x Height x Depth)
Net weight
Shipping weight
AH 87.5 - 108 MHz
C 87.5 - 108 MHz
Mono
Stereo
Mono
Stereo
100Hz
1KHz
10KHz
OFF
ON
Step 50 KHz
Step 50 KHz
*C
≤15dBµ
≥72dB
≥66dB
≤0.3%
≤0.35%
≥78dB
≥85dB
≤3dB
≥48dB
≥60dB
0±1.5dB
≥30dB
≥38dB
≥30dB
≥60dB
18±3dBµ
750mV±150mV 500mV±100mV
6±2dB
≤26dBµ
≤15dBµ
≤24dBµ
435 x 109 x 305 mm
7.2 kg (15.87 lbs)
9.2 kg (20.5 lbs)
4
*AH
≤15dBµ
≥72dB
≥66dB
≤0.3%
≤0.35%
≥65dB
≥85dB
≤3dB
≥48dB
≥60dB
0±1.5dB
≥30dB
≥38dB
≥30dB
≥45dB
18±3dBµ
6±2dB
≤26dBµ
≤15dBµ
≤24dBµ
