- Page 1 OTAL PEAKER OLUTIONS TSS-500 Owner’s Guide...
-
Page 2: Safety Precautions
MPORTANT AFETY RECAUTIONS Read First! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel. CAUTION: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to... - Page 3 TSS-500 O WNER ’ S UIDE Table of Contents Important Safety Precautions Introduction Unpacking the System Planning Your System Placement Wall-Mounting the Satellites and Center Channel Center and Satellite Speaker Connections Subwoofer Controls Subwoofer Connections Operation Maintenance and Service Specifications TSS-500...
-
Page 4: Planning Your System
NTRODUCTION Infinity Total Solutions ™ Infinity Total Solutions continues Infinity’s longstanding commitment to accurate sound reproduction. Our high-quality drivers, precision dividing networks and rigid, well-braced enclosures combine to deliver uncompromised performance in any multichannel home theater system. In addition, these speakers, except for the powered subwoofer, are magnetically shielded for safe placement adjacent to a television. -
Page 5: Center Channel
Should you have questions relating to installation, it is advisable to contact either your dealer or Infinity’s Customer Service Department for advice. The performance of the subwoofer is directly related to its placement in the listening room and how you align the subwoofer with the satellite speakers. - Page 6 OUNTING CONT Step 1. Satellites only: Detach shelf stand by removing screw in rear of speaker. Step 2. Mark the positions on the wall where you would like to place the mounting screws. Step 3. Place bracket against the wall and fasten four 1-1/2" #10 wood screws through the bracket’s screw holes into the wall.
-
Page 7: Satellite Speaker Connections
ENTER AND ATELLITE PEAKER Turn Off All Power After placing the speakers, you are ready to connect your system. First, turn off all audio-system power. Use high-quality speaker wire to make your connections. #18-gauge speaker wire with polarity coding is included. For longer distances, #16-gauge or heavier wire is recommended.The side of the wire with a ridge or other coding is usually considered positive polarity (i.e., +). -
Page 8: Rear Panel
TSS-Sub500 This area is designed to become quite warm This area is designed to become quite warm This area is designed to become quite warm during normal operation. during normal operation. during normal operation. ¡ Subwoofer Level Control ™ LFE Input £... - Page 9 UBWOOFER ONNECTIONS If you have a Dolby ® Digital or DTS ® processor with a low-frequency-effects (LFE) or subwoofer output: 15' (4.6m) subwoofer cable included SUBWOOFER OR LFE OUTPUT TSS-Sub500/230 receiver/ If your receiver/processor does not contain a Dolby Digital or DTS processor but has a subwoofer output: RECEIVER/PROCESSOR NOTE: If your receiver/processor has only one sub out,...
-
Page 10: Operation
If the problem appears in the opposite speaker, the cause is in another component or cable. In the event that your TSS-500 ever needs service, contact your local Infinity dealer or visit www.infinitysystems.com for a service center near you. -
Page 11: Specifications
(403mm x 346mm x 371mm) Weight: 31.7 lb (14.4kg) Infinity continually strives to update and improve existing products, as well as create new ones.The specifications and construction details in this and related Infinity publications are therefore subject to change without notice. - Page 12 © 2006 Harman International Industries, Incorporated. All rights reserved. Infinity Systems, 250 Crossways Park Drive, Woodbury, NY 11797 USA www.infinitysystems.com Infinity and Harman International are registered trademarks, and Total Solutions is a trademark, of Harman International Industries, Incorporated. Dolby and Pro Logic are registered trademarks of Dolby Laboratories.
