Taking care of Air filter

Air filter should be maintained in time, especially in the dusty or sandy area
1. Open the seat and disassemble the tail bar.
2. First disassemble the left rim bar on the lower place of motorcycle.
3. Turn the screws off (1), disassemble the cover of air filter off (2), and
then take the filter out.
4. Put the filter in the clean washing oil for cleaning it, afterwards
let it totally dry.
5. Put the filter in the clean gear oil till it totally soaked; later
squeeze the superfluous oil out of filter.
6. Reassemble all the parts in the converse way.
Caution:
Gas and low burning point flux is easy to burn, and can not be used for cleaning filter

The modulation of head lamp

The modulating screw is under the head lamp, when modulating the lamp
light, we use cross-screwdriver to modulate the light by driver the screw left
or right.

The replacement of head lamp bulb

First disassemble the lamp cover; disassemble the head lamp plate, then take out the bulb, replace a new
one (same standard)

The replacement of front and rear turning light

Disassemble the turning light from motorbike, driver the screw on the cover off, move the cover, then
replace a same standard new bulb, and then reassemble the turning light
