Cambridge Audio 640A Service Manual page 24

AP PART DRAWING NO
No.
PD077
PY010
PY016
PY539
PY219
PY214
PY021
PY013
PY012
PY018
PY536
DESCRIPTION
4.7n CERAMIC 50/100V 5mm PITCH CAPACITOR
15n POLY 50/100V 5mm PITCH CAPACITOR
47n POLY 50/100V 5mm PITCH CAPACITOR
100n CERAMIC 50/100V 5mm PITCH CAPACITOR
10u 35V NON POLAR ELECTROLYTIC
CAPACITOR
100u 16V NON POLAR ELECTROLYTIC
CAPACITOR
1u 16V ELECTROLYTIC CAPACITOR
47u 16V ELECTROLYTIC CAPACITOR
47u 50V ELECTROLYTIC CAPACITOR
100u 16V ELECTROLYTIC CAPACITOR
100u 35V ELECTROLYTIC CAPACITOR
220u 16V ELECTROLYTIC CAPACITOR
220u 50V ELECTROLYTIC CAPACITOR
470u 35V ELECTROLYTIC CAPACITOR
2200u 50V ELECTROLYTIC CAPACITOR
NE5534 SINGLE OP AMP
SAP15NO POWER TRANSISTOR
SAP15PO POWER TRANSISTOR
LM393 DUAL COMPARATOR
7805 5V REGULATOR
7815 15V REGULATOR
7915 -15V REGULATOR
BC327 PNP TRANSISTOR
BC337 NPN TRANSISTOR
MPAS92/93 PNP TRANSISTOR
MPAS42/43 NPN TRANSISTOR
MJE340 NPN TRANSISTOR
MJE350 PNP TRANSISTOR
MPSA13 DARLINGTON NPN TRANSISTOR
1N4004 RECTIFIER DIODE
1N5402 RECTIFIER DIODE
1N4148 SIGNAL DIODE
3V3 400mW ZENER DIODE
4V7 400mW ZENER DIODE
10V 400mW ZENER DIODE
2 WAY JST CONNECTOR 2.54mm PITCH
3 WAY JST CONNECTOR 2.54mm PITCH
4 WAY JST CONNECTOR 2.54mm PITCH
8 WAY JST CONNECTOR 2.54mm PITCH
QTY DESIGNATOR
1 C27
2 C12, C14
10 C19, C20, C32, C40, C55,
C56, C57, C58, C67, C68
10 C3, C4, C24, C28, C31,
C36, C37, C46, C48, C52
4 C13, C18, C39, C47
2 C17, C41
1 C1
1 C59
2 C22, C42
2 C60, C61
1 C54
4 C70, C71, C74, C75
8 C7, C11, C33, C43, C45,
C64, C65, C66
1 C53
8 C21, C23, C25, C26, C29,
C30, C62, C63
2 U1, U6
2 U3, U5
2 U2, U4
1 U7
1 U8
1 U9
1 U10
2 Q1, Q2
4 Q3, Q4, Q5, Q6
9 Q7, Q8, Q15, Q16, Q21,
Q28, Q29, Q30, Q33
10 Q9, Q10, Q18, Q19, Q22,
Q26, Q27, Q32, Q35,
Q36
5 Q11, Q12, Q20, Q24,
Q25
2 Q14, Q31
2 Q13, Q23
10 D2, D4, D8, D10, D13,
D14, D15, D16, D31, D32
4 D17, D18, D19, D20
10 D6, D12, D21, D22, D23,
D24, D25, D26, D27, D28
2 D1, D9
1 D7
2 D29, D30
3 CN2, CN4, CN11
2 CN6, CN8
1 CN5
1 CN7
COMMENTS
MUST BE RAISED OFF PCB DUE TO
HEAT
24
