- Page 1 Please read all instructions carefully before using this product Table of Contents Safety Notice Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model TSA-410 Retain This Manual for Reference 06-10-05 OWNER'S MANUAL IRON GRIP STRENGTH DELUXE CRUNCH BOARD TSA-410 IMPEX INC.
-
Page 2: Table Of Contents
BEFORE YOU BEGIN Thank you for selecting the IRON GRIP STRENGTH Deluxe Crunch Board TSA-410 by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. to provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory. -
Page 3: Important Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. -
Page 4: Warning Label Placement
WARNING LABEL PLACEMENT The Warning Label shown here has been placed on the Rear Base. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown. -
Page 5: Hardware Pack
HARDWARE PACK... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Main Frame (#3) to the Front & Rear Bases (#1 & #2). Secure each end with two M8 x 2”... - Page 7 STEP 2 (See Diagram 2) A.) Attach the Incline Support (#6) in between the two Seat Support Frames (#5). B.) Attach the pivot on the Seat Support Frames (#5) to the pivot on the Main Frame (#3). Secure them with one M12 x 6 7/8” Hex Bolt (#20) and M12 Aircraft Nut (#21). C.) Place the Seat Pad (#9) onto the Seat Support Frames (#5).
-
Page 8: Exploded Diagram
EXPLODED DIAGRAM... -
Page 9: Parts List
PARTS LIST KEY NO. DESCRIPTION Front Base Rear Base Main Frame Dumbbell Rack Seat Support Frame Incline Support Cross Tube Foam Tube Seat Pad Spacer Base End Cap Lock Knob Foam Roll Ø 1” End Cap 1” Square End Cap M8 x 4 3/8”... -
Page 10: Warranty
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
