PPTP Connection
The content of the Connection Status pop-up screen depends on the type of connection. The
Connect and Disconnect buttons in the Connection Status screen display only when the
connection mode is Manually Connect.
The following information displays for a PPTP connection:
• Connection Status. The status of the connection: Connected or Disconnected.
• IP Address. The IP address that is assigned to the router.
• Subnet Mask. The subnet mask that is assigned to the router.
To establish the PPTP connection manually:

1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net or http://www.routerlogin.com.
A login screen displays.
3. Enter the router user name and password.
The user name is admin. The default password is password. The user name and
password are case-sensitive.
The BASIC Home screen displays.
4. Click the ADVANCED tab.
1. In the Internet Port pane, click the Connection Status button.
2. Click the Connect button.
3. To close the Connection Status screen, click the Close Window button.
To terminate the PPTP connection manually:

1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net or http://www.routerlogin.com.
A login screen displays.
3. Enter the router user name and password.
The user name is admin. The default password is password. The user name and
password are case-sensitive.
The BASIC Home screen displays.
4. Click the ADVANCED tab.
5. In the Internet Port pane, click the Connection Status button.
6. Click the Disconnect button.
7. To close the Connection Status screen, click the Close Window button.
