Table 1. Front panel LED descriptions
LED Description
Power • Solid green. The startup is completed, and the router is ready.
• Blinking green. The firmware is corrupted (visit http://www.netgear.com/support).
• Blinking amber. The firmware is upgrading, or the Restore Factory Settings button was
pressed.
• Off. Power is not supplied to the router.
Internet
• Solid green. An IP address was received; the router is ready to transmit data.
• Solid amber. The router detected the Ethernet cable connection.
• Off. No Ethernet cable is connected to the router.
2.4 GHz WiFi
• Solid green. The WiFi interface is enabled.
• Blinking green. The WiFi network is communicating data.
• Off. The WiFi interface is turned off.
5 GHz WiFi
• Solid blue. The WiFi interface is enabled.
• Blinking green. The WiFi network is communicating data.
• Off. The WiFi interface is turned off.
Ethernet ports
• Solid green. The local port is connected to a 1000 Mbps device.
1–4
• Blinking green. Data is being transmitted at 1000 Mbps.
• Solid amber. The local port is connected to a 10/100 Mbps device.
• Blinking amber. Data is being transmitted at 10/100 Mbps.
• Off. No link is detected on this port.
USB
• Solid green. The USB device is accepted by the router and is ready to be used.
• Blinking green. A USB device is in use.
• Off. No USB device is connected, or the Safely Remove Hardware button was clicked
and it is now safe to remove the attached USB device.
WPS/FastLane • Solid green. A WPS-capable or FastLane-capable device is accepted by the router and
is ready to be used.
• Blinking green. The WPS-capable or FastLane-capable device can be associated with
the router within two minutes.
• Off. No WPS or FastLane connection exists.
The WiFi On/Off and WPS/FastLane buttons toggle the WiFi and WPS functions on and off,
as follows:
• WiFi On/Off button. Pressing and holding this button for two seconds turns the 2.4
GHz and 5 GHz WiFi radios on and off. If the WiFi LEDs are lit, the WiFi radios are on. If
the LEDs are off, the WiFi radios are turned off and you cannot connect wirelessly to the
router.
